Removal & Installation: Overview Suzuki Vitara I

Automatic Trans 10 illustrations ~416 words

Scheme 174

Scheme 174: In cabin

Scheme 175

Scheme 175

Scheme 176

Scheme 176

Scheme 177

Scheme 177
  1. Remove console box. NOTE: To remove clip, push in its center pin first.
  2. Remove boot cover (2) and boot No.2 (1) (if equipped).
  3. Remove boot clamp (1) and then remove boot No. 1 (2) from transfer gear sift lever case (if equipped).
  4. With transfer shift control case cover (1) pushed down with fingers, turn it so counterclockwise and take out shift control lever (2) (if equipped).

Scheme 178

Scheme 178: In engine room
  1. Remove battery, dipstick and oil filler tube.
  2. Disconnect A/T throttle cable (1) from throttle cam and bracket.
  3. Remove starter motor. But Don't disconnect its wiring harness.
  4. Remove transmission to engine bolt and nut.

Scheme 179

Scheme 179: On lift

Scheme 180

Scheme 180

Scheme 181

Scheme 181

Scheme 182

Scheme 182

Scheme 183

Scheme 183
  1. Remove transfer skid plate (if equipped).
  2. Drain transfer oil for 2WD vehicle or A/T fluid for 2WD vehicle. NOTE: If 4WD automatic transmission is overhauled later on, draining A/T fluid at this point will facilitate work. Tightening torque Transfer oil drain drug and level/filler plug (a): 23 N.m (2.3 kg-m, 17.0 lb-ft) A/T fluid drain plug (b): 20 N.m (2.0 kg-m, 14.5 lb-ft)
  3. Before removing propeller shaft, give match marks (1) on joint flange and propeller shaft as shown in the figure.
  4. Remove universal joint flange bolts and take out rear propeller shaft.
  5. Likewise, take out front propeller shaft. (if equipped)
  6. Remove nut from the end of select cable bracket to set cable free.
  7. Remove select cable bracket by removing its 2 bolts.
  8. Remove exhaust No. 1 and No.2 pipe.
  9. Remove transmission stiffener (1) (right side), if equipped.
  10. Unclamp and disconnect oil cooler hoses from pipes. NOTE: To avoid leakage of transmission fluid, plug open ends of oil cooler pipes and hoses right after they are disconnected.
  11. Remove torque converter housing lower plate.
  12. Holding drive stationary with special tool or the like, remove torque converter mounting bolts with wrench. Special tool (A): 09927-56010
  13. Remove engine to transmission nuts.
  14. Disconnect connectors from VSS, output speed sensor, input speed sensor, TR switch, shift & TCC solenoid valves and other electrical parts, and release their wire harness from clamps.
  15. Apply transmission jack (1) and take off rear mounting member by removing its bolts.
  16. With transmission (and transfer if equipped) assembly held up on jack (1), move them to the rear and lower them including torque converter. WARNING: Transmission (and transfer if equipped) assembly may tilt rearward on jack (1). It is recommended to use an auxiliary arm (2) of jack (1) for the purpose of safety.
