Audio System: Overview Suzuki Verona I

Entertainment Systems 1 illustration ~265 words

Stereo Cassette AM/FM Radio Description

There are 3 audio systems offered. The stereo digital logic cassette AM/FM radio with electronic tape ejection is offered in standard and deluxe models. Both models feature RDS (radio data system) which automatically selects the best station within the chain of RDS stations currently being listened to. A trunk mounted CD changer is also available.

Speakers Description

All audio systems use 6 speakers: 2 speakers mounted in the front doors, 2 speakers mounted in the rear deck lid sill plate and 2 tweeter speakers mounted on the top side of the instrument panel.

Tape Player and Cassette Care Description

The head and the capstan are the 2 parts of the tape player that should be cleaned. This service should be performed every 100 hours of cassette operation.

To clean the head and the capstan, use a cotton swab dipped in rubbing alcohol.

A cassette cleaning kit may also be used to clean the head and the capstan. Follow the cleaning kit instructions to clean the tape player.

Do not touch the tape head with magnetized tools. If the head becomes magnetized, it will degrade cassettes played in the player. No service is performed on the cassettes. The cassette manufacturer handles warranties of the cassettes. Store cassettes away from extreme heat and direct sunlight.

Compact Disc Care Description

Handle discs carefully. Store the discs in protective cases away from the sun, heat and dust. If the surface is soiled, dampen a clean, soft cloth in a solution of mild neutral detergent and wipe the disc clean.

Scheme 1

Scheme 1: Audio System Circuit Diagram
