DRL System Description (If Equipped)

The DRL system is controlled by BCM (1). It lights headlights when following three conditions are met.

Conditions for DRL operation

Scheme 1

1. The engine is running
2. The lighting switch is at "OFF" position
3. The parking brake is not applied.

Scheme 2

Scheme 3

DRL Operation Inspection (If Equipped)

1. Confirm that lighting switch is in OFF position.
2. Confirm that dimmer and passing switch is in low beam position and parking brake is released.
3. Check DRL for operation as follows. Turn ignition switch to ON position and check headlights remain OFF. Start engine and run it at idle speed. Check headlights turn ON at low beam. Switch dimmer and passing switch to high beam position and check headlights remain turning ON at low beam.
4. If check result is not as satisfied, go to «DRL SYSTEM SYMPTOM DIAGNOSIS (IF EQUIPPED)»(ref-514574-S35052128012012112100000).
