Specifications
| Item | Specifications | |||
|---|---|---|---|---|
| Torque converter | Type | 3-element, 1-step, 2-phase type (with TCC (lock-up) mechanism) | ||
| Oil pump | Type | Internal gear type oil pump | ||
| Drive system | Engine driven | |||
| Gear change device | Type | Forward 4-step, reverse 1-step planetary gear type | ||
| Shift position | "P" range | Gear in neutral, output shaft fixed, engine start | ||
| "R" range | Reverse | |||
| "N" range | Gear in neutral, engine start | |||
| "D" range | Forward 1st. 2nd. 3rd. 4th automatic gear change | |||
| "3" range | Forward 1st. 2nd. 3rd. 4th automatic gear change | |||
| "2" range | Forward 1st. 2nd. 3rd automatic gear change | |||
| "L" range | Forward 1st. 2nd reduction, and fixed at 1st gear | |||
| Gear ratio | 1st | 3.672 | ||
| 2nd | 2.098 | |||
| 3rd | 1.391 | |||
| 4th (overdrive gear) | 1.000 | |||
| Reverse (reverse gear) | 4.021 | |||
| Control elements | Wet type multi-disc clutch... 3 sets Band type brake... 1 set Wet type multi-disc brake... 3 sets One-way clutch... 3 sets | |||
| Reduction gear ratio | 0.982 | |||
| Final gear reduction ratio | 2.863 | |||
| Lubrication | Lubrication system | Forced feed system by oil pump | ||
| Cooling | Cooling system | Radiator assisted cooling (water-cooled) | ||
| Fluid used | An equivalent of DEXRON®-III | |||
ITEM SPECIFICATIONS
Scheme 1
TCC solenoid (COM) (command signal of torque converter clutch solenoid valve) (ON, OFF)
ON: ON command being outputted to TCC solenoid valve.
OFF: ON command not being outputted to TCC solenoid valve.
TCC solenoid (Mon) (monitor signal of torque converter clutch solenoid valve) (ON, OFF)
ON: Electricity being passed to TCC solenoid valve.
OFF: Electricity not being passed to TCC solenoid valve.
Tightening Torque Specifications
| Fastening part | Tightening torque | Note | ||
|---|---|---|---|---|
| N.m | Kgf-m | Lb-ft | ||
| A/T fluid drain plug | 40 | 4.0 | 29.0 | |
| Transmission range sensor bolt | 25 | 2.5 | 18.0 | |
| Transmission range sensor nut | 7.5 | 0.75 | 5.5 | |
| Output shaft speed sensor bolt | 5.5 | 0.55 | 4.0 | |
| Input shaft speed sensor bolt | 5.5 | 0.55 | 4.0 | |
| Transmission fluid temperature sensor | 10 | 1.0 | 7.5 | |
| Shift solenoid bolts | 7.0 | 0.7 | 5.0 | |
| Pressure control solenoid bolt | 7.0 | 0.7 | 5.0 | |
| Valve body bolt | 10.0 | 1.0 | 7.5 | |
| Transaxle side cover bolts | 13 | 1.3 | 9.40 | |
| Transaxle to engine bolts and nut | 85 | 8.5 | 61.5 | |
| Drive plate to torque converter bolts | 23 | 2.3 | 16.5 | |
| Clutch housing plate bolt (M6) | 11 | 1.1 | 8.0 | |
| Clutch housing plate bolt (M10) | 30 | 3.0 | 21.5 | |
| Oil pump cover bolts | 6.5 | 0.65 | 4.7 | |
| Oil pump cover bolts | 12 | 1.2 | 8.7 | |
| Transaxle housing bolts | 30 | 3.0 | 22 | |
| Final gear bolts | 99 | 9.9 | 72.0 | |
| Transaxle housing bolts | 30 | 3.0 | 22.0 | |
| Forward clutch accumulator bolts | 10 | 1.0 | 7.5 | |
| Underdrive brake accumulator bracket bolt(s) | 10 | 1.0 | 7.5 | |
| Underdrive brake band anchor bolt | 170 | 17.0 | 123.0 | |
| Underdrive brake oil plug bolt | 7.5 | 0.75 | 5.5 | |
| Manual detent spring bolt No.1 | 10 | 1.0 | 7.5 | |
| Manual detent spring bolt No.2 | 5.5 | 0.55 | 4.0 | |
| Tube clamp torx® bolt | 9 | 0.9 | 6.5 | |
| Transaxle rear cover bolts | 10 | 1.0 | 7.5 | |
| Transaxle rear cover bolts | 24 | 2.4 | 17.5 | |
| Transaxle lubrication tube bolt | 5.5 | 0.55 | 4.0 | |
| Oil reservoir RH plate bolt | 5.5 | 0.55 | 4.0 | |
| Oil reservoir LH plate bolts | 5.5 | 0.55 | 4.0 | |
| Oil strainer bolt | 5.5 | 0.55 | 4.0 | |
| Transaxle case bolt | 29 | 2.9 | 20.98 | |
| Oil pump body bolt | 25 | 2.5 | 18.08 | |
| Valve body bolt | 10 | 1.0 | 7.5 | |
| Transaxle side cover bolts | 13 | 1.3 | 9.5 | |
| Transmission fluid temperature sensor | 10 | 1.0 | 7.2 | |
| Transmission range sensor lock nut | 7.0 | 0.7 | 5.0 | |
| Manual select lever nut | 12 | 1.2 | 8.7 | |
TIGHTENING TORQUE SPECIFICATIONS
Note. The specified tightening torque is also described in the following: SELECT CABLE COMPONENTS, AUTOMATIC TRANSAXLE UNIT COMPONENTS, AUTOMATIC TRANSAXLE ASSEMBLY COMPONENTS, VALVE BODY ASSEMBLY COMPONENTS, DIFFERENTIAL COMPONENTS and TRANSAXLE REAR COVER COMPONENTS
Reference
For the tightening torque of fastener not specified in this article, refer to FASTENERS INFORMATION.
