Special Tool
SPECIAL TOOL SPECIFICATION 09900-06107 Snap ring pliers (opening type) 09990-06020 Manifold gauge set (R134a) 1. Manifold gauge 2. Charging hoses 3. Quick connector 4. Refrigerant container tap valve 5. Refrigerant container T joint 6. Packing sets 7. Case 09990-86012 Gas leak detector This kit includes following items.1. Gas leak detector, 2. Instruction manual, 3. Filter, 4. Sensor, 5. Dri-sell battery (size D) 09991-06310 Armature plate holder
Scheme 99
Scheme 100
Scheme 101
A/C System Major Components Location
Refer to A/C SYSTEM MAJOR COMPONENTS LOCATION: MANUAL TYPE .
Scheme 102
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | Customer complaint analysis Perform STEP 1. CUSTOMER COMPLAINT ANALYSIS . Was customer complaint analysis performed? | Go to Step 2. | Perform STEP 1. CUSTOMER COMPLAINT ANALYSIS . |
| 2 | Visual inspection Perform VISUAL INSPECTION . Is there any faulty condition? | Repair or replace malfunction part. | Go to Step 3. |
| 3 | DTC check Perform DTC CHECK . Is there any DTC code? | Go to Step 4. | Go to Step 5. |
| 4 | DTC troubleshooting Perform DTC TROUBLESHOOTING . Is there any faulty condition? | Repair or replace malfunction part, and go to Step 7. | Go to Step 5. |
| 5 | A/C system performance inspection Perform A/C SYSTEM PERFORMANCE INSPECTION . Is there any faulty condition? | Repair or replace malfunction part, and go to Step 8. | Go to Step 6. |
| 6 | Perform A/C SYSTEM SYMPTOM DIAGNOSIS Inspect and repair, referring to A/C SYSTEM SYMPTOM DIAGNOSIS: AUTOMATIC TYPE . Is there any faulty condition? | Repair or replace malfunction part, and go to Step 7. | Go to Step 8. |
| 7 | Check for intermittent problem Check for intermittent troubles, referring to INTERMITTENT AND POOR CONNECTION INSPECTION . Is there any faulty condition? | Repair or replace malfunction part, and go to Step 8. | Go to Step 8. |
| 8 | Final confirmation test Perform STEP 8. FINAL CONFIRMATION TEST . Is there any malfunction code? | Go to Step 4. | End. |
DIAGNOSIS PROCEDURE
SPECIAL TOOL SPECIFICATION SUZUKI scan tool - This kit includes following items. 1. Tech 2, 2. PCMCIA card, 3. DLC cable, 4. SAE 16/19 adapter, 5. Cigarette cable, 6. DLC loop back adapter, 7. Battery power cable, 8. RS232 cable, 9. RS232 adapter, 10. RS232 loop back connector, 11. Storage case, 12. Power supply
