Power distribution — Power distribution circuit Suzuki Sidekick I
All systems — 33 systems
- Air conditioning 2
- Anti-lock brakes 1.6l
- Anti-lock brakes 1.8l
- Computer data lines 1.6l
- Computer data lines 1.8l
- Cooling fan
- Cruise control 1.6l
- Cruise control 1.8l
- Defoggers
- Engine performance 1.6l
- Engine performance 1.8l
- Exterior lights 1.6l 2
- Exterior lights 1.8l 2
- Ground distribution
- Headlights 1.6l
- Headlights 1.8l
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks 1.6l
- Power door locks 1.8l
- Power mirrors
- Power windows 2
- Radio
- Shift interlocks 3
- Starting/charging 2
- Supplemental restraints
- Transmission 1.6l 2
- Transmission 1.8l
- Warning systems
- Wiper/washer 1.6l 2
- Wiper/washer 1.8l 2
Components on these wiring diagrams 16
Click a component to highlight it on every diagram it appears on.
