Fusible Link Identification
- A - 60 Amp (Yellow) Main Supply
- B - 50 Amp (Red) Cigarette Lighter, Ignition Coil, Gauges, Wiper/Washer, Rear Defroster, Turn Signals, Back-Up Lights & Heater, Radio (1992-94)
- C - 40 Amp (Green) Head & Taillights, Dome Light, Stoplights, Horn & Hazard Warning
- D - 30 Amp (Pink) PTC Heater (Auto. Trans. Only) (1989-91), Rear Wheel Anti-Lock Brake System (1992-94)
Scheme 1
Scheme 1: FUSE PANEL IDENTIFICATION
Fuse & Circuit Breaker Identification
- 1 - 10 Amp (1989-91)
- 1 - 15 Amp (1992-94) Right Headlight
- 2 - 10 Amp (1989-91)
- 2 - 15 Amp (1992-94) Left Headlight, High Beam Indicator
- 3 - 15 Amp Dome, Parking, Marker & License Lights, Instrument Panel Illumination
- 4 - 15 Amp Stoplights & Horn
- 5 - 15 Amp Hazard Warning Circuit
- 6 - 20 Amp Clock & Radio (1989-91), Cigarette Lighter, Door Lock Control (1992-94)
- 7 - Blank (1989-91)
- 7 - 20 Amp (1992-94) Cigarette Lighter, Radio
- 8 - 15 Amp Ignition Circuit & Engine Circuits, Gauges & Indicators
- 9 - 10 Amp Turn Signal Flashers, Back-Up Lights
- 10 - 15 Amp Wiper/Washer Circuits
- 11 - 15 Amp Rear Defogger
- 12 - 20 Amp Heater Control Circuit
- 12 - 25 Amp (1991-94)
- 13 - Blank (1989-90)
- 13 - 20 Amp - (1991-94) Door Lock Control (1991), Rear Wheel Anti-Lock Brake System (1992-94)
- 14 - Blank (1989-91)
- 15 Amp (1992-94) Electronic Fuel Injection System
IN-LINE FUSE IDENTIFICATION
- 20 Amp - Not Shown A/C Circuits
Scheme 2
Scheme 2: UNDERHOOD FUSIBLE LINK BOX IDENTIFICATION (1989-90)
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- A - 60 Amp Alternator
- B - 40 Amp Main Switch
- C - 30 Amp Fuse Box
Scheme 3
Scheme 3: FUSE PANEL IDENTIFICATION (1991-96 Models)
- 1 - 15 Amp HEAD R (Blue) Right Headlight
- 2 - 15 Amp HEAD L (Blue) Left Headlight/Hi Beam
- 3 - 15 Amp TAIL/DOME (Blue) Taillights, Interior Light, Side Marker/Instrument Cluster Lights, Radio Clock, Radio Illumination, Radio Memory, Spot Lamp, Engine Control Module (ECM), License Plate Light, Ignition Key Warning Switch, Electronic Brake Control Module, (EBCM) (W/ABS), Rear Wheel Antilock (RWAL) Brake Data Link Connector (DLC) (W/ABS)
- 4 - 15 Amp STOP/HORN (Blue) Stoplights, Horn Relay
- 5 - 15 Amp HAZARD (Blue) Hazard Lights
- 6 - 20 Amp DOOR LOCK (Yellow) Door Lock
- 7 - 20 Amp CIGAR/RADIO (Yellow) Cigarette Lighter, Radio Power Input
- 8 - 15 Amp IG-COIL (Blue) Ignition System, Indicator Lights, EFI Controller, Generator, Fuel/Temp Gauges, Audio Alarm Module, MAIN Relay, Daytime Running Lights (DRL) Controller, Fuel Pump Relay, Heated Oxygen Sensor (HO2S), Stoplamp Switch (Auto Trans), Noise Suppressor Condenser (1.6L VIN U) (1991-96), Noise Suppressor Filter (1.6L VIN 6) (1994-96)
- 9 - 15 Amp TURN/BACK (Blue) Turn Signal, Back-Up Lights
- 10 - 15 Amp WIP (Blue) Front Wiper/Washer, Rear Wiper/Washer (Hardtop), Shift Lock Relay (Automatic Transmission)
- 11 - 15 Amp DFOG (Blue) Rear Defogger, Rear Wheel Antilock Brake Relay (RWAL)
- 12 - 25 Amp HTR A/C Amplifier, Blower Speed Selector Switch, Dual Pressure Switch
- 13 - 20 Amp RWAL (Yellow) Rear Wheel Anti-Lock Main Relay (RWAL)
- 14 - 15 Amp FI (Blue) Electronic Fuel Injection Main Relay
Scheme 4
Scheme 4: UNDERHOOD FUSIBLE LINK BOX IDENTIFICATION
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- A - 60 Amp (Blue) Battery (Main Circuit)
- B - 50 Amp (Red) Ignition Switch, Fuse Block
- C - 40 Amp (Amber) Lamps Fuse - Tail, Stop, Headlight, Hazard, Door Lock
- D - 30 Amp (Green) ABS System Relay (If Equipped)
