Engine Lubrication System (n32a) Suzuki Grand Vitara II рестайлинг

Lubrication System 33 illustrations ~1966 words

Engine Lubrication Description

The oil pump is a trochoid rotor pump that rotates with the crankshaft. The pump draws up oil from the oil pan through the oil pump strainer. The oil delivered from the pump flows through the oil filter.

The filtered oil flows through the two paths in the cylinder block.

Through the first path, the oil reaches the crankshaft main bearings. After lubricating the crankshaft main bearings, the oil is supplied to the connecting rod bearings by way of the passages formed in the crankshaft and then injected through the oil jets to lubricate the pistons, piston rings and cylinder walls.

Through the second path, the oil goes up to the cylinder head and flows in the passages formed inside the camshafts to lubricate them and the valve mechanisms.

The oil pump has an oil relief valve. The valve opens when the oil pressure exceeds the preset limit to release it.

Oil Pressure Check

WARNINGTo avoid danger of being burned, do not touch exhaust system when it is hot. Any service on exhaust system should be performed when it is cool.

Note. Prior to checking oil pressure, check the following. Oil level in oil pan If oil level is too low, add oil up to full level mark (hole) on oil level gauge. See ENGINE OIL AND FILTER CHANGE . Oil quality If oil is discolored or deteriorated, change it. For particular oil to be used. See ENGINE OIL AND FILTER CHANGE . Oil leaks If leak is found, repair it.

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64
  1. With hose connected, detach P/S pump from its bracket. See «P/S PUMP REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system__ps-pump-removal-and-installation) .
  2. Remove P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  3. Remove OCV connector. CAUTION: After OCV connector installation, check DTC. When DTC is displayed, be sure to clear DTC. See «DTC CLEARANCE»(/suzuki/grand-vitara/ii-2008-2012/remont/testing-diagnostics/#engine-general-information-and-diagnosis-n32a) .
  4. Disconnect oil pressure switch connector (1).
  5. Remove oil pressure switch (2) from cylinder block.
  6. Install special tools (oil pressure gauge) to threaded hole from which oil pressure switch was removed. Special Tool (A): 09915-77311 (B): 09915-78211
  7. Install P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  8. Install P/S pump. See «P/S PUMP REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system__ps-pump-removal-and-installation) .
  9. Start engine and warm engine up to normal operating temperature. NOTE: Be sure to shift select lever to "P" range, set parking brake and block drive wheels.
  10. Raise engine speed to 4,000 RPM and measure oil pressure. Oil pressure specification More than 300 - 500 kPa (3.1 - 5.1 kgf/cm 2 , 43.5 - 72.5 psi) at 4,000 RPM .
  11. With hose connected, detach P/S pump from its bracket. See «P/S PUMP REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system__ps-pump-removal-and-installation) .
  12. Remove P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  13. Remove special tool from cylinder block.
  14. Before reinstalling oil pressure switch (2), be sure to wrap its screw threads with sealing tape (1) and tighten switch to specified torque. NOTE: If sealing tape edge extend beyond screw threads of switch, cut it off to threads width. Tightening torque Oil pressure switch (a): 13 N.m (1.3 kg-m, 9.5 lbf-ft)
  15. Connect oil pressure switch connector (1).
  16. Install P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  17. Install P/S pump. See «P/S PUMP REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system__ps-pump-removal-and-installation) .
  18. Connect OCV connector.
  19. Clearance for DTC.
  20. Start engine and check oil pressure switch for oil leakage. If oil leakage is found, repair it.
  21. Check for DTC.

Engine Oil and Filter Change

WARNINGNew and used engine oil can be hazardous. Be sure to read "WARNING" in GENERAL PRECAUTIONS and observe what is written there. Steps 1) - 7) below must be performed with ENGINE NOT RUNNING. For Step 8), be sure to have adequate ventilation while engine is running.

Before draining engine oil, check engine for oil leakage.

If any sign of leakage is found, make sure to correct defective part before proceeding to the following procedure.

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70
  1. Remove engine rear under cover.
  2. Drain engine oil by removing drain plug.
  3. Reinstall new drain plug with new gasket and tighten it to specified torque. Tightening torque Engine oil drain plug (a): 35 N.m (3.6 kg-m, 26.0 lbf-ft)
  4. Loosen oil filter (1) using oil filter wrench (special tool). Special Tool (A): 09915-46520 NOTE: Before fitting new oil filter, be sure to apply engine to oil its O-ring.
  5. Install oil filter (1) using oil filter wrench (special tool). Special Tool (A): 09915-46520 Tightening torque Oil filter (b): 30 N.m (3.1 kg-m, 22.5 lbf-ft) (for reference)
  6. Replenish oil until oil level is brought to FULL level mark (hole) on oil level gauge (oil pan and oil filter capacity). The filter inlet is at the top of cylinder head cover. Use only engine oil with American Petroleum Institute (API) Certified For Gasoline Engine "Starburst" symbol. It is highly recommended to use SAE 5W-30 oil. NOTE: Engine oil capacity is specified as follows. However, note that the amount of oil required when actually changing oil may somewhat differ from the data depending on various conditions (temperature, viscosity, etc.). Engine oil specification (N32A) Oil pan capacity: About 5.5 liters (11.62/9.68 US/Imp pt.) Oil filter capacity: About 0.5 liter (1.06/0.88 US/Imp pt.) Others: About 0.2 liter (0.42/0.35 US/Imp pt.) Total: About 6.2 liters (13.10/10.91 US/Imp pt.)
  7. Check oil filter and drain plug for oil leakage.
  8. Start engine and run it for 3 minutes. Stop it and wait another 5 minutes before checking oil level. If necessary, add oil up to FULL level mark (hole) (1) on oil level gauge.

Scheme 71

Scheme 71: Oil Pressure Switch On-Vehicle Inspection
Scheme 71: Oil Pressure Switch On-Vehicle Inspection
  1. With hose connected, detach P/S pump from its bracket. See «P/S PUMP REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system__ps-pump-removal-and-installation) .
  2. Remove P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  3. Disconnect oil pressure switch connector (1).
  4. Install P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  5. Install P/S pump. See «P/S PUMP REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system__ps-pump-removal-and-installation) .
  6. Check for continuity between oil pressure switch terminal (2) and cylinder block (3) as shown. If check result is not as specified, replace oil pressure switch (4). Oil pressure sensor specification During engine running: No continuity At engine stop: Continuity

Oil Pan and Oil Pump Strainer Components

Note. For oil pan bolt tightening sequence, see OIL PAN AND OIL PUMP STRAINER REMOVAL AND INSTALLATION

Scheme 72

Scheme 72: Oil Pan and Oil Pump Strainer Components
Scheme 72: Oil Pan and Oil Pump Strainer Components

Oil Pan and Oil Pump Strainer Removal and Installation

Scheme 73

Scheme 73: Removal
Scheme 73: Removal

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78
  1. Remove engine assembly from vehicle. See «ENGINE ASSEMBLY REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .
  2. Remove cylinder head cover. See «CYLINDER HEAD COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .
  3. Remove generator bracket. See «GENERATOR REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/charging-system/#charging-system) .
  4. Remove timing chain cover. See «TIMING CHAIN COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a__timing-chain-cover-removal-and-installation) .
  5. Remove oil level gauge.
  6. Remove lower oil pan bolts (1).
  7. Remove lower oil pan (1) from upper oil pan using plastic hammer.
  8. Remove upper oil pan bolts No. 1 (1), upper oil pan bolts No. 2 (2) and upper oil pan bolt No. 3 (3).
  9. Remove upper oil pan (1) from cylinder block using plastic hammer.
  10. If necessary, remove baffle plate (1) from upper oil pan.
  11. If necessary, remove oil pump strainer (1) from upper oil pan.

Scheme 79

Scheme 79: Installation
Scheme 79: Installation

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86
  1. If removed, install new gasket (1) to oil pump strainer (2).
  2. Install oil pump strainer (2) to upper oil pan (3). CAUTION: Be sure to use new oil pump strainer bolt when assembling. Tightening torque Oil pump strainer bolt (a): 10 N.m (1.0 kg-m, 7.5 lbf-ft)
  3. If removed, install baffle plate (1) to upper oil pan (2). CAUTION: Be sure to use new baffle plate bolt when assembling. Tightening torque Baffle plate bolt (a): 10 N.m (1.0 kg-m, 7.5 lbf-ft)
  4. Install dowel pin (1) to cylinder block.
  5. Install special tool to cylinder block. Special Tool (A): Engine front cover installation guide pins (EN-46109)
  6. Clean mating surfaces of upper oil pan and cylinder block.
  7. Apply sealant to oil pan mating surface as shown in figure. "A": Sealant 99000-31290 (SUZUKI Bond No. 1217F) Sealant bead size Width "a": 3 mm (0.12 in.) Height "b": 2 mm (0.08 in.)
  8. Install upper oil pan to cylinder block and tighten upper oil pan bolts No. 1, upper oil pan bolts No. 2 and upper oil pan bolt No. 3 by hand.
  9. Tighten upper oil pan bolts No. 1 ("1" - "4", "6" and "8" - "12"), upper oil pan bolts No. 2 ("5" and "7") and upper oil pan bolt No. 3 ("13") in numerical order as shown in figure to specified torques. Tightening torque Upper oil pan bolt No. 1* (a): 25 N.m (2.5 kg-m, 18.5 lbf-ft) Upper oil pan bolt No. 2* (b): 10 N.m (1.0 kg-m, 7.5 lbf-ft) Upper oil pan bolt No. 3* (c): 10 N.m (1.0 kg-m, 7.5 lbf-ft)
  10. Clean mating surfaces of upper oil pan and cylinder block.
  11. Apply sealant to oil pan mating surface as shown in figure. "A": Sealant 99000-31290 (SUZUKI Bond No. 1217F) Sealant bead size Width "a": 3 mm (0.12 in.) Height "b": 2 mm (0.08 in.)
  12. Install lower oil pan to upper oil pan and tighten lower oil pan bolts by hand.
  13. Tighten lower oil pan bolts ("1" - "10") in numerical order as shown in figure to specified torque. Tightening torque Lower oil pan bolt* (a): 10 N.m (1.0 kg-m, 7.5 lbf-ft)
  14. Install timing chain cover. See «TIMING CHAIN COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a__timing-chain-cover-removal-and-installation) .
  15. Install generator bracket. See «GENERATOR REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/charging-system/#charging-system) .
  16. Install belt idler arm to generator bracket. See «TENSIONER AND IDLER PULLEY REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/charging-system/#charging-system) .
  17. Install OCV. «OCV REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/engine-control-systems/#engine-electrical-devices-n32a__ocv-removal-and-installation) .
  18. Install P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  19. Install cylinder head cover. See «CYLINDER HEAD COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .
  20. Install accessory drive belt. See «ACCESSORY DRIVE BELT REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/charging-system/#charging-system) .
  21. Install engine assembly from vehicle. See «ENGINE ASSEMBLY REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .

Scheme 87

Scheme 87: Removal
Scheme 87: Removal
  1. Remove engine assembly from vehicle. See «ENGINE ASSEMBLY REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .
  2. Remove cylinder head cover. See «CYLINDER HEAD COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .
  3. Remove generator bracket. See «GENERATOR REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/charging-system/#charging-system) .
  4. Remove timing chain cover. See «TIMING CHAIN COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a__timing-chain-cover-removal-and-installation) .
  5. Remove 1st timing chain, timing chain lower guide and crankshaft timing sprocket. See «1ST TIMING CHAIN AND TIMING CHAIN TENSIONER ADJUSTER NO. 2 REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a__1st-timing-chain-and-timing-chain) .
  6. Remove oil pump (1).

Scheme 88

Scheme 88: Installation
Scheme 88: Installation
  1. Install oil pump (1). Tightening torque Oil pump bolt (a): 23 N.m (2.3 kg-m, 17.0 lbf-ft)
  2. Install 1st timing chain. See «1ST TIMING CHAIN AND TIMING CHAIN TENSIONER ADJUSTER NO. 2 REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a__1st-timing-chain-and-timing-chain) .
  3. Install timing chain cover. See «TIMING CHAIN COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a__timing-chain-cover-removal-and-installation) .
  4. Install generator bracket. See «GENERATOR REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/charging-system/#charging-system) .
  5. Install OCV. «OCV REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/engine-control-systems/#engine-electrical-devices-n32a__ocv-removal-and-installation) .
  6. Install P/S pump bracket. See «P/S HOSE/PIPE COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/accessory-drive-belts/#power-assisted-steering-system) .
  7. Install cylinder head cover. See «CYLINDER HEAD COVER REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .
  8. Install accessory drive belt. See «ACCESSORY DRIVE BELT REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/charging-system/#charging-system) .
  9. Install engine assembly from vehicle. See «ENGINE ASSEMBLY REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical/#engine-mechanical-n32a) .

Oil Pump Inspection

Check to be sure that inner rotor turn smoothly by hand.

If pump does not rotate smoothly or makes abnormal noise, replace it.

Scheme 89

Scheme 89: Oil Pump Inspection
Scheme 89: Oil Pump Inspection

Tightening Torque Specifications

CAUTIONFor fastener with * (asterisk) below, be sure to tighten it according to specified procedure in "Repair Instructions".
Fastening partTightening torque
N.mKgf-mLbf-ft
Oil pressure switch131.39.5
Engine oil drain plug353.626.0
Oil filter303.122.5
Oil pump strainer bolt101.07.5
Baffle plate bolt101.07.5
Upper oil pan bolt No. 1*252.518.5
Upper oil pan bolt No. 2*101.07.5
Upper oil pan bolt No. 3*101.07.5
Lower oil pan bolt*101.07.5
Oil pump bolt232.317.0

TIGHTENING TORQUE SPECIFICATIONS

Note. The specified tightening torque is described in the following. OIL PAN AND OIL PUMP STRAINER COMPONENTS

Reference

For the tightening torque of fastener not specified in this information, refer to FASTENER INFORMATION .

Recommended Service Material

MaterialSUZUKI recommended product or Specification
SealantSUZUKI Bond No. 1217FP/No.: 99000-31290

SPECIAL TOOLS REFERENCE

Note. Required service material is also described in the following. OIL PAN AND OIL PUMP STRAINER COMPONENTS

Special Tool

SPECIAL TOOLS REFERENCE 09915-46520 Wrench, Oil Filter 09915-77311 Oil pressure gauge 09915-78211 Oil pressure gauge attachment Engine front cover installation guide pins - EN-46109

Scheme 90

Scheme 90: Special Tool
Scheme 90: Special Tool

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93
