Electronic Stability Program Suzuki Grand Vitara II рестайлинг

Precautions in Diagnosing Troubles

To ensure that the trouble diagnosis is done accurately and smoothly, observe the following and follow ELECTRONIC STABILITY PROGRAM CHECK .

Scheme 1

1. Diagnostic information stored in ESP® control module memory can be cleared as well as checked by using SUZUKI scan tool. Before using scan tool, read its Operator's (Instruction) Manual carefully to have good understanding as to what functions are available and how to use it.
2. If the vehicles was operated in any of the following ways, ESP® warning light may light momentarily but this does not indicate anything abnormal in ESP®. The vehicle was driven with parking brake pulled. The vehicle was driven with brake dragging. The vehicle was stuck in mud, sand, etc. Wheel spin occurred while driving. Wheel(s) was rotated while the vehicle was jacked up.
3. Be sure to read «PRECAUTION FOR CAN COMMUNICATION SYSTEM»(/suzuki/grand-vitara/ii-2008-2012/remont/oem-general-information/#precautions) before inspection and observe what is written there.
4. Be sure to use the trouble diagnosis procedure as described in «ELECTRONIC STABILITY PROGRAM CHECK»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program) . Failure to follow it may result in incorrect diagnosis. (Some other diagnosis trouble code may be stored by mistake in the memory of ESP® control module during inspection.)
5. When disconnecting ESP® control module connector (1), pull up lock lever (2) of connector. When connecting, set the connector on ESP® hydraulic unit/control module assembly and pull down the lock lever (2) until it locks.
6. Communication of ECM, TCM (for A/T model), BCM, ESP® (ABS) control module, 4WD control module (if equipped), keyless start control module (if equipped), HVAC control module, SDM (Advanced air bag model), ID controller (if equipped), combination meter and steering angle sensor is established by CAN (Controller Area Network). For more detail of CAN communication, refer to «CAN COMMUNICATION SYSTEM DESCRIPTION»(/suzuki/grand-vitara/ii-2008-2012/remont/communication-devices/#communication-system) . Therefore, be sure to read «PRECAUTIONS FOR INSTALLING MOBILE COMMUNICATION EQUIPMENT»(/suzuki/grand-vitara/ii-2008-2012/remont/oem-general-information/#precautions) before inspection and handling CAN communication line.

Precautions in On-Vehicle Service

When connector is connected to ESP® hydraulic unit/control module assembly, do not disconnect connectors of sensors with ignition switch ON. Otherwise, DTC will be set in ESP® control module.

Precautions in ESP® Hydraulic Unit Operation Check

ESP® hydraulic unit/control module assembly function is checked by correct wheel lock/release condition when brake pressure is pressurized/depressurized using SUZUKI scan tool. The hydraulic unit operation check referring to ESP® HYDRAULIC UNIT OPERATION CHECK should be performed to confirm the correct brake pipe connection in the following cases.

1. ESP® hydraulic unit/control module assembly was replaced.
2. Brake pipe and/or hose were replaced.

Precautions in Sensor Calibration

ESP® control module stores calibration points data of yaw rate/G sensor assembly and master cylinder pressure sensor. Steering angle sensor stores calibration point data of itself.

Traction control system, stability control system, hill descent control (if equipped) and hill hold control (if equipped) use these sets of data.

When the following operation is done, calibration should be performed since the original calibration points are deleted.

SENSOR CALIBRATION REFERENCE CHART

Perform sensor calibration according to SENSOR CALIBRATION OF ESP® COMPONENTS .

Precautions in Speedometer Test or Other Tests

When performing speedometer or a bench test while rotating a tire, ESP® function must be kept at stop. It is possible to stop ESP® function temporarily by ESP® OFF switch. In this case, however, the function is forced to come back to work when the speed exceeds 30 km/h (18.5 mph) and may hinder accurate testing.

There are two ways to stop the ESP® function completely as described bellow.

1. Connect the SUZUKI scan tool, select to the "ESP® Function Setting" through the "Utility", them select the "Deactivation" to stop the ESP® function. Refer to SUZUKI scan tool operators manual for further details.
2. Disconnect the connector of the steering angle sensor, and ESP® function is forced to enter the failsafe mode, then ESP® function is stopped. However, when this method is used, DTC remains in the memory of the ESP® control module. Therefore, after the test, re-connect the connector, clear DTC in the memory of the ESP® control module. And calibrate steering angle sensor. Refer to «SENSOR CALIBRATION OF ESP® COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program__sensor-calibration-of-espr-components) .

Electronic Stability Program (ESP®) has the following main functions.

1. ABS/EBD ABS is that four wheel brake forces are independently varied with referring each wheel slip condition. EBD is that front and rear wheel braking forces are varied with referring loading distribution of the vehicle. ABS improves the vehicle stability, controllability and braking performance. For the details, refer to «ABS DESCRIPTION»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#antilock-brake-system-abs__abs-description) .
2. Traction control system Traction control system function is that engine torque is controlled and brake is applied with referring wheel spin condition during vehicle starting and accelerating.
3. Stability control system Stability control system is that engine torque is controlled and brake is applied with referring vehicle condition (over steering, under steering) during cornering.
4. Hill descent control (If equipped) This function controls running of the vehicle on the down-slope stably at a constant low speed without tires being locked. The ESP® control module activates the pump motor and each solenoid valves to operate to increase, retain or reduce the brake pressure applied to 4 wheels. This function enables the vehicle to run on the down-slope with such large gradient where the engine brake alone cannot provide enough deceleration, or where the road surface is rough or slippery, without driver's brake operation.
5. Hill hold control (If equipped) This function prevents occurrence of creeping down which may occur at the driver's foot shift from the brake pedal to the accelerator pedal operation when starting the vehicle parked on the up-slope. The ESP® control module activates each solenoid valve to operate to keep the brake pressure provided by the driver's brake operation. The vehicle can be stopped by this function for no more than 2 seconds. NOTE: ESP is a registered trademark of Daimler AG.

ESP® Hydraulic Unit/Control Module Assembly Description

ESP® control module is a component of ESP® hydraulic unit/control module assembly and has the following functions.

Self-Diagnosis Function

ESP® control module monitors each input and output signals. When ESP® control module detects any malfunction, some of ABS warning light (1), EBD warning light (brake warning light) (2), ESP® warning light (3), SLIP indicator light (4), ESP® OFF light (5), hill descent control indicator light (if equipped) (6) are turned ON and indicate the abnormality to driver.

Scheme 2

1. When ignition switch is turned ON, ABS warning light, EBD warning light, ESP® warning light, SLIP indicator light, ESP® OFF light and hill descent control indicator light (if equipped) light for 2 seconds to check its circuit.
2. When no abnormality is detected (the system is in good condition), ABS warning light, EBD warning light, ESP® warning light, SLIP indicator light, ESP® OFF light and hill descent control indicator light (if equipped) turn OFF after 2 seconds.
3. When an abnormality in the system is detected, some of ABS warning light, EBD warning light (brake warning light), ESP® warning light, SLIP indicator light, ESP® OFF light and/or hill descent control indicator light (if equipped) are turned ON and the area where that abnormality lies is stored in the memory in ESP® control module.

Fail-Safe Mode

When ESP® control module detects abnormality, the system goes into fail-safe mode. And some of functions of ABS, traction control system, stability control system hill descent control (if equipped), hill hold control (if equipped) are shut down. For details of fail safe mode, refer to FAIL-SAFE TABLE .

Warning Light, Indicator Light, Information Display Description

There are six types of warning light, indicator light and information display in instrument cluster, which are controlled by ESP® control module. They give warning/indication to driver by changing the modes light ON/blinking/light OFF, and also show the warning/indication message up on the information display at the same time.

Scheme 3

The followings are the condition and operation of warning lights and indicator lights.

WARNING LIGHT/INDICATOR LIGHT REFERENCE CHART

The following are the condition and display color of message.

MESSAGE DISPLAY CHART

CAN Communication System Description

Refer to CAN COMMUNICATION SYSTEM DESCRIPTION for CAN communication system description. ESP® control module communicates control data with each control module. Refer to CAN COMMUNICATION SYSTEM TRANSMITTING AND RECEIVING DATA TABLE .

There is CAN communication system only for ESP® control module (1) and yaw rate/G sensor assembly (2).

This CAN communication system is independent from other control modules.

Scheme 4

ESP® communicates control data with yaw rate/G sensor assembly as follows.

ESP® Transmission Data to Yaw Rate/G Sensor Assembly

1. Longitudinal G neutral position
2. Lateral G neutral position

ESP® Reception Data from Yaw Rate/G Sensor Assembly

1. Vehicle yaw rate signal
2. Vehicle longitudinal G signal
3. Vehicle lateral G signal
4. Yaw rate/G sensor assembly related malfunction

Scheme 5

Scheme 6

Scheme 7

TERMINAL REFERENCE CHART

Scheme 8

Refer to the following items for the details of each step.

DIAGNOSIS PROCEDURE

Customer complaint analysis

Record details of the problem (failure, complaint) and how it occurred as described by the customer. For this purpose, use of such a questionnaire form as shown in the following will facilitate collecting information to the point required for proper analysis and diagnosis.

Scheme 9

Problem symptom confirmation

If symptom in "Customer Questionnaire" is found or reproduced in the vehicle, confirm the symptom is problem or not. (This step should be done with the customer if possible.) Check warning lights related to brake system referring to EBD WARNING LIGHT (BRAKE WARNING LIGHT) CHECK , ABS WARNING LIGHT CHECK and ESP® WARNING LIGHT CHECK .

DTC check, record and clearance

Perform DTC CHECK procedure, record it and then clear it referring to DTC CLEARANCE .

Recheck DTC referring to DTC CHECK .

When DTC which is recorded at DTC check procedure is detected again after performing DTC clearance, go to STEP 4: ESP® CHECK to proceed the diagnosis.

When DTC which is recorded at DTC check procedure is not indicated anymore after performing DTC clearance, ESP® control module does not perform the system diagnosis, or temporary abnormality may occur, therefore go to STEP 2: DRIVING TEST to proceed the diagnosis.

Step 2: Driving Test

Test the vehicle at 40 km/h for more than a minute including left and right turns and check if any trouble symptom (such as ESP® warning light and/or ABS warning light) exists.

If the malfunction DTC is confirmed at ignition switch ON, proceed to STEP 3 .

If the malfunction DTC is not confirmed at ignition switch ON, proceed to STEP 6 .

Step 3: DTC Check

Recheck DTC referring to DTC CHECK .

Step 4: ESP® Check

According to ESP® Check for the DTC confirmation in STEP 3 , locate the cause of the trouble, namely in a sensor, switch, wire harness, connector, actuator assembly or other part and repair or replace faulty parts.

Step 5: Brakes Diagnosis

Check the parts or system suspected as a possible cause referring to BRAKES SYMPTOM DIAGNOSIS and based on symptoms appearing on the vehicle (symptom obtained through STEPS 1 MALFUNCTION ANALYSIS and 2 DRIVING TEST and repair or replace faulty parts, if any).

Step 6: Intermittent Problem Check

Check parts where an intermittent trouble is easy to occur (e.g., wire harness, connector, etc.), referring to INTERMITTENT AND POOR CONNECTION INSPECTION and related circuit of trouble code recorded in Step 1 to 3.

Step 7: Final Confirmation Test

Confirm that the problem symptom has gone and the ESP® is free from any abnormal conditions. If what has been repaired is related to the malfunction DTC, clear the DTC once referring to DTC CLEARANCE and perform test driving and confirm that no DTC is indicated.

Scheme 10

1. Turn ignition switch ON.
2. Check that ESP® warning light (1) comes ON for about 2 seconds and then goes off. If any faulty condition is found, advance to «ESP® WARNING LIGHT DOES NOT COME ON AT IGNITION SWITCH ON»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program) or «ESP® WARNING LIGHT COMES ON STEADY»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program) .

ABS Warning Light Check

Refer to ABS WARNING LIGHT CHECK .

EBD Warning Light (Brake Warning Light) Check

Refer to EBD WARNING LIGHT (BRAKE WARNING LIGHT) CHECK .

DTC Check

Refer to DTC CHECK .

DTC Table

DTC REFERENCE CHART

DTC Clearance

After repair or replace malfunction part(s), clear all DTCs by performing the following procedure or using SUZUKI scan tool.

1. Connect SUZUKI scan tool to data link connector in the same manner as when making this connection for DTC check.
2. Turn ignition switch to ON position.
3. Erase DTC according to instructions displayed on scan tool. Refer to scan tool operators manual for further details. NOTE: For DTC C1022, C1026, C1032, C1036 and C1061, confirm that ABS warning light turns off after performing Step 2 of "Test Driving" under «ELECTRONIC STABILITY PROGRAM CHECK»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program) , and then clear the DTCs.
4. After completing the clearance, turn ignition switch OFF and disconnect scan tool from data link connector.
5. Perform "DRIVING TEST" (Step 2 of «ELECTRONIC STABILITY PROGRAM CHECK»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program) ) and «DTC CHECK»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program__dtc-check) and confirm that NO DTC is displayed on scan tool.

Fail-Safe Table

When any of the following DTC(s) is detected, ESP® system is in fail-safe mode per its DTC and ABS, EBD, traction control system/stability control system and/or hill descent control (if equipped)/hill hold control (if equipped) functions are deactivated until the resolution is applied.

FAIL-SAFE REFERENCE CHART

ESP® Control Module

As the data values are standard values estimated on the basis of values obtained from the normally operating vehicles by using a scan tool, use them as reference values. Even when the vehicle is in good condition, there may be cases where the checked value does not fall within each specified data range. Therefore, judgment as abnormal should not be made by checking with these data alone.

SCAN TOOL DATA REFERENCE

Scan Tool Data Definition

SCAN TOOL DATA DEFINITION REFERENCE

Scheme 11

Circuit Description

Operation (ON/OFF) of ESP® warning light is controlled by ESP® control module through light driver module in combination meter.

If ESP® system is in good condition, ESP® control module turns ESP® warning light ON at the ignition switch ON, keeps it ON for 2 seconds and then turns it OFF. If an abnormality in the system is detected, ESP® warning light is turned ON continuously by ESP® control module. Also, it is turned ON continuously by light driver module when the connector of ESP® control module is disconnected.

Troubleshooting

DIAGNOSIS PROCEDURE

Wiring Diagram

Refer to ESP® WARNING LIGHT DOES NOT COME ON AT IGNITION SWITCH ON .

Operation (ON/OFF) of ESP® warning light is controlled by ESP® control module through light driver module in combination meter.

If ESP® system is in good condition, ESP® control module turns ESP® warning light ON at the ignition switch ON, keeps it ON for 2 seconds and then turns it OFF. If an abnormality in the system is detected, ESP® warning light is turned ON continuously by ESP® control module. Also, it is turned ON continuously by light driver module when the connector of ESP® control module is disconnected.

DIAGNOSIS PROCEDURE

DTC INDEX

DIAGNOSTIC TROUBLE CODE DEFINITIONS

DTC Detecting Condition and Trouble Area

DTC DETECTING CONDITION CHART

DTC Troubleshooting

DIAGNOSIS PROCEDURE

Scheme 12

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

Scheme 13

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

1. Turn ignition switch to OFF position.
2. Check for proper connection from harness to ESP® control module.
3. If OK, substitute an ESP® hydraulic unit/control module assembly with correct part number.
4. Recheck system.

DTC C1021, C1022/C1025, C1026/C1031, C1032/C1035, C1036: Right-Front/Left-Front/Right-Rear/Left-Rear Wheel Speed Sensor Circuit or Encoder Failure

Refer to DTC C1021, C1022/C1025, C1026/C1031, C1032/C1035, C1036: RIGHT-FRONT/LEFT-FRONT/RIGHT-REAR/LEFT-REAR WHEEL SPEED SENSOR CIRCUIT OR ENCODER FAILURE .

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

Scheme 14

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

Scheme 15

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

Scheme 16

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC C1041/C1042/C1043/C1044/C1045/C1046/C1051/C1052/C1053/C1054/C1055/C1056: Inlet Solenoid Circuit Failure, Outlet Solenoid Circuit Failure, Master Cylinder Cut Solenoid Circuit Failure, Low Pressure Solenoid Circuit Failure (DTC C1041/C1045/C1051/C1055: Right-Front/Left-Front/Right-Rear/Left-Rear Inlet Solenoid Circuit Failure) (DTC C1042/C1046/C1052/C1056: Right-Front/Left-Front/Right-Rear/Left-Rear Outlet Solenoid Circuit Failure) (DTC C1043/C1044: Master Cylinder Cut Solenoid Circuit No. 1/No. 2 Failure) (DTC C1053/C1054: Low Pressure Solenoid Circuit No. 1/No. 2 Failure)

Refer to DTC C1041/C1042/C1043/C1044/C1045/C1046/C1051/C1052/C1053/C1054/C1055/C1056: INLET SOLENOID CIRCUIT FAILURE, OUTLET SOLENOID CIRCUIT FAILURE, MASTER CYLINDER CUT SOLENOID CIRCUIT FAILURE, LOW PRESSURE SOLENOID CIRCUIT FAILURE; (DTC C1041/C1045/C1051/C1055 .

DTC C1057: ESP® (ABS) control module power supply circuit failure

Refer to DTC C1057: ABS (ESP®) CONTROL MODULE POWER SUPPLY CIRCUIT FAILURE .

DTC C1061: Pump Motor and/or Motor Driver Circuit Failure

Refer to DTC C1061: PUMP MOTOR AND/OR MOTOR DRIVER CIRCUIT .

DTC C1063: Solenoid Valve Power Supply Driver Circuit Failure

Refer to DTC C1063: SOLENOID VALVE POWER SUPPLY DRIVER CIRCUIT FAILURE .

Scheme 17

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC C1071: ESP® (ABS) Control Module Internal Defect

Refer to DTC C1071: ABS (ESP®) CONTROL MODULE INTERNAL DEFECT .

Scheme 18

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC DETECTING CONDITION CHART

DIAGNOSIS PROCEDURE

DTC U0073: Control Module Communication Bus Off

Refer to CAN DTC (LOST COMMUNICATION AND COMMUNICATION BUS OFF) TABLE .

DTC U0100: Lost Communication with ECM (Reception Error)

Refer to CAN DTC (LOST COMMUNICATION AND COMMUNICATION BUS OFF) TABLE .

DTC U0101: Lost Communication with TCM (Reception Error)

Refer to CAN DTC (LOST COMMUNICATION AND COMMUNICATION BUS OFF) TABLE .

DTC U0114: Lost Communication with 4WD Control Module (Reception Error)

Refer to CAN DTC (LOST COMMUNICATION AND COMMUNICATION BUS OFF) TABLE .

DTC U0126: Lost Communication with Steering Angle Sensor (Reception Error)

Refer to CAN DTC (LOST COMMUNICATION AND COMMUNICATION BUS OFF) TABLE .

DTC U1140: Lost Communication with BCM (Reception Error)

Refer to CAN DTC (LOST COMMUNICATION AND COMMUNICATION BUS OFF) TABLE .

ESP® Hydraulic Unit Operation Check

Note. Operation check must be performed by 2 persons. Be sure to perform SENSOR CALIBRATION OF ESP® COMPONENTS before performing hydraulic unit operation check.

Scheme 19

Scheme 20

1. Turn ignition switch to OFF position.
2. Connect SUZUKI scan tool to data link connector (1) located on underside of instrument panel at driver's seat side. Special Tool (A): SUZUKI scan tool (SUZUKI-SDT)
3. Hoist vehicle until tire can be rotated.
4. Set transmission to neutral and release parking brake.
5. Turn ignition switch to ON position and select menu press/depress in "HYDRAULIC CONTROL TEST" under "Utility" of SUZUKI scan tool. Refer to SUZUKI scan tool operators manual for further details.
6. Perform the following checks with help of another person. Depressurization check Step on brake pedal (1) and then select testing wheel by SUZUKI scan tool and the wheel (2) should be turned by another person's hand. At this time, check whether the wheel rotates freely due to brake depressurization. Pressurization check Step off brake pedal (1) and then select testing wheel by SUZUKI scan tool and the wheel (2) should be turned by another person's hand. At this time, check whether the wheel locks due to brake pressurization. NOTE: Pressurization/Depressurization by SUZUKI scan tool is available for 0.5 second.
7. Check for all 4-wheels condition respectively. If a faulty condition is found, replace hydraulic unit/control module assembly.
8. After completing the check, turn ignition switch to OFF position and disconnect SUZUKI scan tool from DLC.

Sensor Calibration of ESP® Components

Note. Steering angle sensor calibration is needed when battery, dome fuse or the steering angle sensor is removed. This sensor calibration can be done with/without SUZUKI Scan Tool. When ESP® control module and/or yaw rate/G sensor assembly is removed, sensor calibration is needed with SUZUKI Scan Tool.

Scheme 21

1. Set steering wheel in straight-ahead position.
2. Connect SUZUKI scan tool to data link connector (DLC) (1) with ignition switch OFF. Special Tool (A): SUZUKI scan tool (SUZUKI-SDT)
3. Turn ignition switch to ON position and confirm that only any of DTC(s) C1075, C1076, C1077 and/or C1078 is detected. If any other DTC are detected, repair the detected DTC.
4. Park and level the vehicle with parking brake, stop engine with ignition switch ON, set steering in straight and without stepping on the brake pedal. CAUTION: Hold the above condition in Step 4 ) to calibrate sensor correctly until sensor calibration is completed.
5. Select menu "SENSOR CALIBRATION" under "Utility" of SUZUKI scan tool and calibrate sensor. Refer to scan tool operators manual for further details.
6. After completing the calibration, turn ignition switch to OFF position and disconnect SUZUKI scan tool from DLC.

Steering Angle Sensor Calibration (Not Using SUZUKI Scan Tool)

Scheme 22

1. Set steering wheel in straight-ahead position.
2. Connect battery terminals and/or fuse and start engine. CAUTION: When power is not supplied to the steering angle sensor by removing battery or fuse, DTC C1075 is detected and SLIP indicator light (1) flashes. If DTC other than C1075 is detected, SLIP indicator light flushes and other indicator illuminate. In that case, repair the detected DTC first.
3. Drive vehicle straight on level ground at 15 km/h (9.5 mph) or above for few seconds without spinning wheels. And confirm that SLIP indicator light is OFF.

ESP® Hydraulic Unit/Control Module Assembly On-Vehicle Inspection

Refer to ABS (ESP®) HYDRAULIC UNIT/CONTROL MODULE ASSEMBLY ON-VEHICLE INSPECTION .

ESP® Hydraulic Unit/Control Module Assembly Removal and Installation

Refer to ABS (ESP®) HYDRAULIC UNIT/CONTROL MODULE ASSEMBLY REMOVAL AND INSTALLATION .

Front Wheel Speed Sensor On-Vehicle Inspection

Refer to FRONT AND REAR WHEEL SPEED SENSOR ON-VEHICLE INSPECTION .

Front Wheel Speed Sensor Removal and Installation

Refer to FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION .

Front Wheel Speed Sensor Inspection

Refer to FRONT AND REAR WHEEL SPEED SENSOR INSPECTION .

Rear Wheel Speed Sensor On-Vehicle Inspection

Refer to FRONT WHEEL SPEED SENSOR ON-VEHICLE INSPECTION since rear wheel speed sensor is the same as front wheel speed sensor.

Rear Wheel Speed Sensor Removal and Installation

Refer to REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION .

Rear Wheel Speed Sensor Inspection

Reference: REAR WHEEL SPEED SENSOR REMOVAL AND INSTALLATION

Refer to FRONT WHEEL SPEED SENSOR INSPECTION since rear wheel speed sensor is the same as front wheel speed sensor.

Front Wheel Encoder On-Vehicle Inspection

Refer to FRONT WHEEL ENCODER ON-VEHICLE INSPECTION .

Front Wheel Encoder Removal and Installation

Reference: FRONT WHEEL ENCODER ON-VEHICLE INSPECTION

For removal and installation of front wheel hub assembly, referring to FRONT WHEEL HUB ASSEMBLY REMOVAL AND INSTALLATION .

Rear Wheel Encoder On-Vehicle Inspection

Refer to REAR WHEEL ENCODER ON-VEHICLE INSPECTION .

Rear Wheel Encoder Removal and Installation

Reference: REAR WHEEL ENCODER ON-VEHICLE INSPECTION

For removal and installation of front wheel hub assembly, referring to REAR WHEEL HUB ASSEMBLY REMOVAL AND INSTALLATION .

Scheme 23

Scheme 24

1. Calibrate yaw rate/G sensor assembly. See «SENSOR CALIBRATION OF ESP® COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program__sensor-calibration-of-espr-components) .
2. Check that basic brake system other than ESP®. See «BRAKE DIAGNOSIS NOTE»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical-hydraulic/#brake-control-system-and-diagnosis) .
3. Connect SUZUKI scan tool to data link connector (DLC) (1) with ignition switch OFF. Special Tool (A): SUZUKI scan tool (SUZUKI-SDT)
4. Turn ignition switch to ON position and select menu "DATA LIST" mode of SUZUKI scan tool. Refer to scan tool operators manual for further details.
5. When brake pedal is released, check "Master Cyl Press" under "DATA LIST" of SUZUKI scan tool. If pressure is out of specification, replace ESP® hydraulic unit/control module assembly. Master cylinder pressure specification Brake pedal released: 0 ± 0.8 MPa (0 ± 8.2 kg/cm 2 , 0 ± 116 psi)
6. Hoist vehicle and remove right-side front wheel.
7. Connect special tool with rubber hose (1) to Front brake caliper bleeder plug (2). Special Tool (A): 09956-02311
8. When bleeder plug loosen and depress brake pedal to make special tool gauge reading 10 MPa (100 kg/cm 2 , 1422 psi), check "Master Cyl Press" under "DATA LIST" of SUZUKI scan tool. If pressure displayed on SUZUKI scan tool is out of specification, replace ESP® hydraulic unit/control module assembly. Master cylinder pressure specification Brake pedal depressed 10 MPa (102 kg/cm 2 , 1450 psi): 10 ± 1.2 MPa (102 ± 12.2 kg/cm 2 , 1450 ± 174 psi)
9. After completing the check, turn ignition switch to OFF position and disconnect SUZUKI scan tool from DLC.
10. Tighten bleeder plug and bleed air from brake system. See «AIR BLEEDING OF BRAKE SYSTEM»(/suzuki/grand-vitara/ii-2008-2012/remont/mechanical-hydraulic/#brake-control-system-and-diagnosis__air-bleeding-of-brake-system) .

Scheme 25

1. Calibrate yaw rate/G sensor assembly. See «SENSOR CALIBRATION OF ESP® COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program__sensor-calibration-of-espr-components) .
2. Park and level the vehicle with parking brake and fix wheels with chokes.
3. Check yaw rate/G sensor assembly installation condition.
4. Connect SUZUKI scan tool to data link connector (DLC) (1) with ignition switch OFF. Special Tool : SUZUKI scan tool (SUZUKI-SDT)
5. Turn ignition switch to ON position and select menu "DATA LIST" mode of SUZUKI scan tool. Refer to scan tool operators manual for further details.
6. Check "G Sensor" under "DATA LIST" of SUZUKI scan tool in the following vehicle conditions. Level condition Front-up condition Rear-up condition If Longitudinal G condition is out of specification, replace yaw rate/G sensor assembly. Longitudinal G specification LONGITUDINAL G SPECIFICATION CHART Vehicle condition Longitudinal G Level condition 0 ± 0.1 G Front-up condition 0.1 ± 0.1 G Rear-up condition -0.1 ± 0.1 G

Scheme 26

Scheme 27

Scheme 28

1. Calibrate yaw rate/G sensor assembly. See «SENSOR CALIBRATION OF ESP® COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program__sensor-calibration-of-espr-components) .
2. Park and level the vehicle with parking brake and fix wheels with chokes.
3. Check yaw rate/G sensor assembly installation condition.
4. Connect SUZUKI scan tool to data link connector (DLC) (1) with ignition switch OFF. Special Tool (A): SUZUKI scan tool (SUZUKI-SDT)
5. Turn ignition switch to ON position and select menu "DATA LIST" mode of SUZUKI scan tool. Refer to scan tool operators manual for further details.
6. Check "G Sensor (lateral)" under "DATA LIST" of SUZUKI scan tool in the following vehicle conditions. Level condition Right-up condition Left-up condition If Lateral G condition is out of specification, replace yaw rate/G sensor assembly. Lateral G specification LATERAL G SPECIFICATION CHART Vehicle condition G Sensor (lateral) Level condition 0 ± 0.1 G Right-up condition 0.1 ± 0.1 G Left-up condition -0.1 ± 0.1 G

Scheme 29

1. Calibrate yaw rate/G sensor assembly. See «SENSOR CALIBRATION OF ESP® COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program__sensor-calibration-of-espr-components) .
2. Check yaw rate/G sensor assembly installation condition.
3. Connect SUZUKI scan tool to data link connector (DLC) (1) with ignition switch OFF. Special Tool : SUZUKI scan tool (SUZUKI-SDT)
4. Turn ignition switch to ON position and select menu "DATA LIST" mode of SUZUKI scan tool. Refer to scan tool operators manual for further details.
5. Check "Yaw rate sensor" under "DATA LIST" of SUZUKI scan tool in the following vehicle conditions. Parking condition Drive vehicle in right turning condition with steering wheel fully turned Drive vehicle in left turning condition with steering wheel fully turned If yaw rate condition is out of specification, replace yaw rate/G sensor assembly. Yaw rate specification YAW RATE SPECIFICATION CHART Vehicle condition Yaw rate Parking 0 ± 4 deg/s Right turning 30 ± 4 deg/s Left turning -30 ± 4 deg/s NOTE: Drive the vehicle on level ground and at 10 km/h (6.2 mph). Minimum turning radius is 5.3 m (17.4 ft).

Scheme 30

Yaw Rate/G Sensor Assembly Removal and Installation

Reference: YAW RATE/G SENSOR ASSEMBLY ON-VEHICLE INSPECTION

Removal

1. Disconnect negative (-) cable at battery.
2. Remove console rear panel. Refer to «CONSOLE BOX COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
3. Remove yaw rate/G sensor assembly from floor panel.

Installation

Reference: YAW RATE/G SENSOR INSPECTION

Scheme 31

Scheme 32

1. Before installing yaw rate/G sensor assembly (1), check installing condition as follows. Deformations around sensor installation area (2) (in floor panel). Foreign matters on mating surface between sensor and floor panel.
2. Install yaw rate/G sensor assembly (1) to floor panel. Tightening torque Yaw rate/G sensor assembly bolt (a): 8 N.m (0.8 kg-m, 6.0 lbf-ft)
3. Install console rear panel. Refer to «CONSOLE BOX COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/exteriorinterior-trim/#interior-trim) .
4. Connect negative (-) cable to battery.
5. After completing installation, calibrate yaw rate/G sensor assembly. Refer to «SENSOR CALIBRATION OF ESP® COMPONENTS»(/suzuki/grand-vitara/ii-2008-2012/remont/anti-locktraction-control/#electronic-stability-program__sensor-calibration-of-espr-components) .

Yaw Rate/G Sensor Inspection

Reference: YAW RATE/G SENSOR ASSEMBLY REMOVAL AND INSTALLATION

1. Check sensor for dents, cracks or deformation.
2. Check sensor connector (sensor side and harness side) and sensor connector lock mechanism for damage or crack.
3. Check connector terminals for bend, corrosion or rust.

If it is found faulty, replace yaw rate/G sensor assembly.

Scheme 33

Steering Angle Sensor On-Vehicle Inspection

Scheme 34

Scheme 35

1. Connect SUZUKI scan tool to data link connector (DLC) (1) with ignition switch OFF. Special Tool (A): SUZUKI scan tool (SUZUKI-SDT)
2. Turn ignition switch to ON position and select menu "DATA LIST" mode of SUZUKI scan tool. Refer to scan tool operators manual for further details.
3. Check "Steering angle Sen" under "DATA LIST" of SUZUKI scan tool in the following steering wheel conditions. Front wheels in straight-ahead position Rotate steering wheel a round in clockwise (counter clockwise) from straight-ahead position If steering angle condition is out of specification, replace steering angle sensor. Steering angle Specification STEERING ANGLE SPECIFICATION CHART Vehicle condition Steering angle Front wheels in straight-ahead position 0 ± 3 deg Rotate steering wheel a round in clockwise 360 ± 3 deg Rotate steering wheel a round in counterclockwise -360 ± 3 deg

Steering Angle Sensor Removal and Installation

Refer to STEERING ANGLE SENSOR REMOVAL AND INSTALLATION .

Steering Angle Sensor Inspection

1. Check sensor for dents, cracks or deformation.
2. Check sensor connector (sensor side and harness side) and sensor connector lock mechanism for damage or crack.
3. Check connector terminals for bend, corrosion or rust.

If it is found faulty, replace steering angle sensor (1).

Scheme 36

Scheme 37

1. Disconnect negative (-) cable at battery.
2. Remove center garnish (1) with audio unit (if equipped), HVAC control module and ESP® OFF switch. See «AUDIO UNIT REMOVAL AND INSTALLATION»(/suzuki/grand-vitara/ii-2008-2012/remont/entertainment-systems/#instrumentationdriver-infohorn) .

Reference: ESP® OFF SWITCH INSPECTION

Reverse removal procedure.

ESP® OFF Switch Inspection

Reference: ESP® OFF SWITCH REMOVAL AND INSTALLATION

Check for continuity between terminals at each switch position.

If check result is not as specified, replace ESP® OFF switch (1).

Scheme 38

Hill Descent Control Switch Removal and Installation

Refer to ESP® OFF SWITCH REMOVAL AND INSTALLATION .

Hill Descent Control Switch Inspection

Reference: HILL DESCENT CONTROL SWITCH REMOVAL AND INSTALLATION

Check for continuity between terminals at each switch position.

If check result is not as specified, replace hill descent control switch (1).

Scheme 39

Brake light Relay Inspection

1. Disconnect negative (-) cable at battery.
2. Remove brake light relay (1) from relay box.
3. Check brake light relay as follows. Check that there is no continuity between terminals (5) or (6) and (4). If there is continuity, replace relay. Check continuity between terminals (3) and (6). If there is no continuity, replace relay. Connect battery positive (+) terminal to terminal (4) of relay. Connect battery negative (-) terminal to terminal (2) of relay. Check continuity between terminals (5) and (6). If there is no continuity, replace relay.

Tightening Torque Specifications

TIGHTENING TORQUE SPECIFICATION CHART

Reference

For the tightening torque of fastener not specified in this section, refer to FASTENER INFORMATION .

Special Tool

SPECIAL TOOL DESCRIPTION CHART 09956-02311 Brake pressure gauge SUZUKI scan tool (SUZUKI-SDT) - This kit includes following items. SUZUKI-SDT DLC3 cable USB cable AC/DC power supply Voltage meter probe Storage case

Scheme 40

Scheme 41

See also:
• PRECAUTION FOR CAN COMMUNICATION SYSTEM
• CAN COMMUNICATION SYSTEM DESCRIPTION
• ABS DESCRIPTION
• DTC CHECK
• BRAKES SYMPTOM DIAGNOSIS
• INTERMITTENT AND POOR CONNECTION INSPECTION
• EBD WARNING LIGHT (BRAKE WARNING LIGHT) CHECK
• CAN DTC (LOST COMMUNICATION AND COMMUNICATION BUS OFF) TABLE
• BRAKE LIGHT SWITCH ON VEHICLE INSPECTION
• BRAKE FLUID LEVEL SWITCH INSPECTION
• INSPECTION OF BCM AND ITS CIRCUITS
• DTC C1041/C1042/C1043/C1044/C1045/C1046/C1051/C1052/C1053/C1054/C1055/C1056: INLET SOLENOID CIRCUIT FAILURE, OUTLET SOLENOID CIRCUIT FAILURE, MASTER CYLINDER CUT SOLENOID CIRCUIT FAILURE, LOW PRESSURE SOLENOID CIRCUIT FAILURE; (DTC C1041/C1045/C1051/C1055
• ABS (ESP®) HYDRAULIC UNIT/CONTROL MODULE ASSEMBLY ON-VEHICLE INSPECTION
• FRONT WHEEL SPEED SENSOR REMOVAL AND INSTALLATION
• FRONT AND REAR WHEEL SPEED SENSOR INSPECTION
• FRONT WHEEL ENCODER ON-VEHICLE INSPECTION
• FRONT WHEEL HUB ASSEMBLY REMOVAL AND INSTALLATION
• REAR WHEEL ENCODER ON-VEHICLE INSPECTION
• REAR WHEEL HUB ASSEMBLY REMOVAL AND INSTALLATION
• BRAKE DIAGNOSIS NOTE
• AIR BLEEDING OF BRAKE SYSTEM
• CONSOLE BOX COMPONENTS
• STEERING ANGLE SENSOR REMOVAL AND INSTALLATION
• AUDIO UNIT REMOVAL AND INSTALLATION
• FASTENER INFORMATION
• ELECTRONIC STABILITY PROGRAM CHECK
• ESP® HYDRAULIC UNIT OPERATION CHECK
• SENSOR CALIBRATION OF ESP® COMPONENTS
• FAIL-SAFE TABLE
• CUSTOMER COMPLAINT ANALYSIS
• PROBLEM SYMPTOM CONFIRMATION
• DTC CHECK, RECORD AND CLEARANCE
• STEP 2: DRIVING TEST
• STEP 7: FINAL CONFIRMATION TEST
• EBD WARNING LIGHT (BRAKE WARNING LIGHT) CHECK
• ABS WARNING LIGHT CHECK
• DTC CLEARANCE
• STEP 4: ESP® CHECK
• STEP 3
• STEP 6
• DTC CHECK
• DTC C1021, C1025, C1031, C1035
• DTC C1041, C1045, C1051, C1055
• DTC C1057
• DTC C1061
• DTC C1063
• DTC C1071
• DTC U0073
• DTC U0100
• DTC U0101
• DTC U0114
• DTC U0126
• DTC U1140
• STEERING ANGLE SENSOR ON-VEHICLE INSPECTION
• ESP® OFF SWITCH INSPECTION
• FRONT WHEEL SPEED SENSOR ON-VEHICLE INSPECTION
• FRONT WHEEL SPEED SENSOR INSPECTION
• YAW RATE/G SENSOR INSPECTION
• YAW RATE/G SENSOR ASSEMBLY REMOVAL AND INSTALLATION
