COMPUTERIZED ENGINE CONTROLS
(Scheme 71)- (Scheme 72) to locate component parts.
Scheme 71
Scheme 72
| CAUTION | The Engine Control Module (ECM) consists of precision parts. Do not expose the ECM to excessive shock. |
- Disconnect the negative battery cable.
- Disable air bag system. See DISABLING AIR BAG SYSTEM in appropriate AIR BAG RESTRAINT article.
- Remove glove box. See REMOVAL & INSTALLATION section of appropriate GAUGES & INSTRUMENT PANEL article under ACCESSORIES & EQUIPMENT.
- Remove instrument panel passenger lower member (1). (Scheme 73)
- Remove right side dash trim.
- Disconnect instrument panel harness connectors' clamp, engine harness connectors (1), and floor harness connector (2).
- Remove ground wire harness (3). (Scheme 74)
- Disconnect connectors (1) from ECM while releasing connectors lock. NOTE: Do not damage ventilation duct.
- Remove ECM from body after removing its nuts (2). (Scheme 75)
- Reverse removal procedure noting the following: Connect connectors securely to ECM until a click is heard. Be careful not to catch any cable or wiring harness when installing each part. Securely tighten body earth bolt.
