On-board Refueling Vapor Recovery (ORVR) System Description

This vehicle is equipped with an On-Board Refueling Vapor Recovery (ORVR) system. This system has been developed and equipped to meet enhanced evaporative emission control requirements during vehicle moving, parking and refueling. The ORVR system operates in the following manner

  1. One canister collects evaporative vapors while the vehicle is moving, parking and refueling.
  2. Collected vapor flows into the engine through the intake manifold, where it is consumed during vehicle operation.
  3. Fuel flowing through a reduced diameter section in the filler pipe creates suction in the filler neck.

The ORVR system operates by the Liquid Trap (Liquid Seal) system which ensures long-term durability. The ORVR system has been designed with the following functional features

  1. Collection and routing of refueling vapors to the canister.
  2. Nozzles that are compatible with conventional and Stage II vapor recovery nozzles.
  3. Fuel shut-off signal.
  4. Prevention of liquid fuel entering the canister during normal driving and during vehicle rollover.
  5. Fuel tank over-pressure prevention.
  6. Fuel tank venting to canister during vehicle operation.
  7. Fuel vapor dome over fill protection.

This vehicle is also equipped with an On-Board Diagnostic II (OBD II) system. This system identifies failures or malfunctions of the ORVR system and warns the driver through the Malfunction Indicator Lamp (MIL) on the instrument cluster.

The ORVR system requires no special refueling procedures and maintenance.

The ORVR system and all fuel system components are designed to prevent electrostatic discharge using techniques recommended by SAE J1645. The test procedure (EDS-T-5525) is similar to the SAE J1113 test procedure.

Scheme 2

Scheme 2: Schematic of On Board Refueling Vapor Recovery System

Scheme 3

Scheme 3: Component Location

Scheme 4

Scheme 4: Passenger Car Vehicle Identification Number

Scheme 5

Scheme 5: Certification Label

Manual Transaxle Identification Number Plate (D20)

Identification CodeEngineGear Ratio
FN2.0L DOHC3.550 CR

GEAR RATIO CHART

Scheme 6

Scheme 6

Manual Transaxle Identification Number Plate Location (D20)

The manual transaxle identification number is attached to the top of the transmission case near the engine.

Scheme 7

Scheme 7: Manual Transaxle Identification Number Plate Location (D20)

Automatic Transaxle Identification Number Plate (ZF 4HP16)

Part CodeEngine
JW2.0L DOHC

ENGINE PART CODE CHART

Scheme 8

Scheme 8

Automatic Transaxle Identification Number Plate Location (ZF 4HP16)

The automatic transaxle identification number plate is attached on the rear bottom side of the transaxle case near the bulk head.

Scheme 9

Scheme 9: Automatic Transaxle Identification Number Plate Location (ZF 4HP16)
