Lighting Systems: Overview Suzuki Forenza I

Exterior Lights 24 illustrations ~1157 words

Headlamps-ON Reminder Chime Description

When the headlamp switch is in the headlamps-ON or parking lamps-ON position, voltage is applied to the chime module. When the ignition is in ON, ACC or START, voltage is applied through the fuse block to the module. These two voltages are sensed, and the chime module is not sounded.

When the ignition is not in ON, ACC or START, the module loses voltage. The chime module senses change. If the voltage is still available, it is applied to sound the chime. The chime can be turned OFF by turning the headlamp switch OFF. The module no longer senses voltage from the headlamp switch, so the chime module does not sound.

Headlamps Description

The headlamps are controlled by the multifunction lever located on the left side of the steering column. They will come on with the ignition switch in any position. Turning the headlamp switch to the first position turns ON the parking lamps, the license plate lamps and the instrument panel illumination. Turning the switch to the second position turns ON all of the previous lamps and the headlamps. Turning the switch to the OFF position turns OFF all the lamps.

Headlamp high beams and low beams are also controlled by this lever. When the headlamps are ON, pushing the lever away from the driver until the switch clicks changes the lamp from low beam to high beam. An indicator lamp on the instrument cluster assembly will come on when the high beam headlamps are ON. To return the headlamps to low beam, pull the lever toward the driver.

The headlamps must be aimed for proper illumination of the road. Headlamp aim should be checked whenever a new headlamp assembly is installed, or whenever service repairs to the front end area may have disturbed the headlamp assembly or its mountings.

Daytime Running Lamps Description

The Daytime Running Lamps (DRL) will come on when

  1. The ignition is ON.
  2. The light is OFF.
  3. The parking brake is released.

When the exterior lights are ON, the DRL will turn OFF. To turn the DRL OFF when idling, apply the parking brake.

Parking and Turn Signal Lamps Description

The parking lamps can be turned ON by turning the lighting switch to the first position. The parking lamps can be turned OFF by turning the switch to the OFF position.

When the turn signals are activated, the front and rear turn signal lamps flash to signal a turn. The turn signals work only when the ignition is ON.

The turn signals are controlled by the light switch on the left side of the steering column. Moving the lever all the way up or down (past the detent) will turn ON the front and rear turn signals. When the turn is completed, the lever will return to horizontal and the turn signals will stop flashing.

For changing lanes, or for shallow turns in which the steering wheel does not turn far enough to cancel the signal, move the signal lever only to the first detent and hold it there. When the lever is released, it will return to horizontal and the turn signals will cancel.

Sidemarker Lamps Description

The sidemarker lamps are located in the front and rear bumper fascias and work in conjunction with the exterior lighting system. When the parking lamps or headlamps are ON, the sidemarker lamps will illuminate to mark the front and the rear end of the vehicle.

Fog Lamps Description

The fog lamp switch is on the instrument panel to the right of the steering column. To use the fog lamps, first turn ON the headlamps or the parking lamps. Then push the fog lamp switch. The indicator light in the switch will illuminate to indicate that the fog lamps are on. Push the switch again to turn OFF the fog lamps. The indicator light will then go OFF.

The fog lamps should not be used as a substitute for the headlamps.

The fog lamps must be aimed for proper illumination of the road. Fog lamp aim should be checked when a new bulb is installed or if service or repairs in the front end area may have disturbed the fog lamp mountings.

Tail Lamps Description

The park lamps, stoplamps, turn signal lamps and backup lamp are one assembly.

Turning ON either the headlamps or the parking lamps will also turn ON the taillamps. When the brake pedal is pushed, the taillamps will glow brighter to serve as stoplamps.

The center high-mounted stoplamp is located in the rear window and will come on when the brake pedal is pressed.

License Plate Lamp Description

The license plate lamps will come ON when the headlamps or the parking lamps are ON. The license plate lamps are mounted above the license plate.

Interior Courtesy Lamp Description

The courtesy lamp is located on the headliner just behind the front seats. The lamp switch has three positions. If the switch is left in the center position, the lamp will go ON whenever a door is opened and go OFF when it is closed. In the ON position, the lamp will stay on until it is turned OFF. In the OFF position, the lamp will not come ON, even when a door is opened.

Luggage Compartment Lamp Description

The luggage compartment lamp is located under the deck lid sill plate on the notchback. The lamp is located on the left-side wheelhouse trim panel on the hatchback. It will come ON whenever the luggage compartment is opened.

Backup Lamps Description

The backup lamps are located in the rear combination lamps They will come ON when the transaxle is shifted into reverse. On a vehicle with an automatic transaxle, the backup lamps are activated by the Neutral Safety Backup (NSBU) switch. On a vehicle with a manual transaxle, they are activated by a reverse switch which is part of the transaxle.

Scheme 1

Scheme 1: Backup Lamps Circuit Diagram (For NOTCHBACK/HATCHBACK Model)

Scheme 2

Scheme 2: Backup Lamps Circuit Diagram (For STATION WAGON Model)

Scheme 3

Scheme 3: Instruments Circuit Diagram

Scheme 4

Scheme 4: Front Fog Lamps Circuit Diagram

Scheme 5

Scheme 5: Headlamps-ON Reminder Chime Circuit Diagram

Scheme 6

Scheme 6: Headlamps Circuit Diagram

Scheme 7

Scheme 7: Daytime Running Lamps Circuit Diagram

Scheme 8

Scheme 8: Park, Tail and License Lamps Circuit Diagram (For NOTCHBACK Model)

Scheme 9

Scheme 9: Park, Tail and License Lamp Circuit Diagram (For HATCHBACK Model)

Scheme 10

Scheme 10: Park, Tail and License Lamp Circuit Diagram (For STATION WAGON Model)

Scheme 11

Scheme 11: Park, Tail and License Lamp Circuit Diagram (For NOTCHBACK Model, CANADA ONLY)

Scheme 12

Scheme 12: Park, Tail and License Lamp Circuit Diagram (For STATION WAGON Model, CANADA ONLY)

Scheme 13

Scheme 13: Stoplamps Circuit Diagram (For NOTCHBACK, HATCHBACK Model)

Scheme 14

Scheme 14: Stoplamps Circuit Diagram (For STATION WAGON Model)

Scheme 15

Scheme 15: Turn and Hazard Lamps Circuit Diagram (For NOTCHBACK Model)

Scheme 16

Scheme 16: Turn and Hazard Lamps Circuit Diagram (For HATCHBACK Model)

Scheme 17

Scheme 17: Turn and Hazard Lamps Circuit Diagram (For STATION WAGON Model)

Scheme 18

Scheme 18: Turn and Hazard Lamps Circuit Diagram (For NOTCHBACK Model, CANADA ONLY)

Scheme 19

Scheme 19: Turn and Hazard Lamps Circuit Diagram (For HATCHBACK Model, CANADA ONLY)

Scheme 20

Scheme 20: Turn and Hazard Lamps Circuit Diagram (For STATION WAGON Model, CANADA ONLY)

Scheme 21

Scheme 21: Interior Courtesy and Luggage Compartment Lamp Circuit Diagram

Scheme 22

Scheme 22: Trunk/Tail Gate Open Switch, Trunk Latch Switch and Trunk Room Lamps Circuit Diagram (For NOTCHBACK

Scheme 23

Scheme 23: Trunk/Tail Gate Open Switch, Trunk Latch Switch and Trunk Room Lamps Circuit Diagram (For HATCHBACK

Scheme 24

Scheme 24: Trunk/Tail Gate Open Switch, Trunk Latch Switch and Trunk Room Lamps Circuit Diagram (For STATION WA

Test Description

The number(s) below refer to step(s) on the diagnostic table.

  1. Bulb test. Clip one end of a jumper wire to the negative battery terminal. Clip the other end of the jumper wire onto one end of the bulb. Take the free end of the bulb (the end without the jumper attached) and touch it to the positive battery terminal.
StepActionValue (s)YesNo
1Remove the interior courtesy lamp bulb and inspect the filament. If the filament is not broken, test the bulb using the vehicle's battery and a jumper wire. Does the bulb pass the visual and physical checks?Go to Step 3Go to Step 2
2Replace the bulb. Is the repair complete?System OK
3Reinstall the interior courtesy lamp bulb. Check fuse Ef19. Is fuse Ef19 blown?Go to Step 4Go to Step 5
4Check for a short circuit and repair it, if necessary. Replace the fuse. Is the repair complete?System OK
5Check fuse Ef19. Does the voltage at fuse Ef19 equal the specified value?11 - 14 VGo to Step7 Go to Step 6
6Repair the open power supply circuit for fuse Ef19. Is the repair complete?System OK
7Disconnect the interior courtesy lamp electrical connector. Check the voltage at connector terminal 1 (W/Sun Roof: 3). Does the voltage at connector terminal 1 (W/Sun Roof: 3) equal the value specified?11-14 VGo to Step 8Go to Step 9
8Repair the open circuit between fuse Ef19 and the interior courtesy lamp terminal 1 (W/Sun Roof: 3). Is the repair complete?System OK
9With the interior courtesy lamp disconnected, turn it to the on position. Use an ohmmeter to check the resistance between ground and terminal 2 (W/Sun Roof: 1) of the interior courtesy lamp connector (harness side). Is the resistance equal to the specified value?0 ohmsGo to Step 10Go to Step 11
10Replace the interior courtesy lamp switch assembly. Is the repair complete?System OK
11Repair the ground circuit for the interior courtesy lamp. Is the repair complete?System OK

INTERIOR COURTESY LAMP DIAGNOSIS

The number(s) below refer to step(s) on the diagnostic table.

  1. Bulb test. Clip one end of a jumper wire to the negative battery terminal. Clip the other end of the jumper wire onto one end of the bulb. Take the free end of the bulb (the end without the jumper attached) and touch it to the positive battery terminal.
StepActionValue (s)YesNo
1Remove the luggage compartment lamp bulb and inspect the filament. If the filament is not broken, test the bulb using the vehicle's battery and a jumper wire. Does the bulb pass the visual and physical check?Go to Step 3Go to Step 2
2Replace the bulb. Is the repair complete?System OK
3Reinstall the luggage compartment lamp bulb. Check fuse Ef19. Is fuse Ef19 blown?Go to Step 4Go to Step 5
4Check for a short circuit and repair it, if necessary. Replace the fuse. Is the repair complete?System OK
5Check fuse Ef19. Does the voltage at fuse Ef19 equal the specified value?1114 V Go to Step 7Go to Step 6
6Repair the open power supply circuit for fuse Ef19. Is the repair complete?System OK
7Disconnect the luggage compartment lamp electrical connector. Check the voltage at the orange wire. Does the voltage at the ORN wire equal the specified value?1114 V Go to Step 8Go to Step 9
8Repair the open circuit between fuse Ef19 and the luggage compartment lamp. Is the repair complete?System OK
9Reconnect the luggage compartment lamp. Remove the luggage compartment lamp switch. With a voltmeter (or test lamp), test the PNK/BLK wire at the luggage compartment lamp switch. Does the voltage at the luggage compartment lamp switch equal the specified value?11 - 14 VGo to Step 11Go to Step 10
10Repair the open circuit between the luggage compartment lamp and the luggage compartment lamp switch. Is the repair complete?System OK
11Use an ohmmeter to check the resistance between ground and the BLK wire at the luggage compartment lamp switch connector (harness side). Is the resistance equal to the specified value?0 ohmsGo to Step 12Go to Step 13
12Replace the luggage compartment lamp switch. Is the repair complete?System OK
13Repair the ground circuit for the interior courtesy lamp. Is the repair complete?System OK

LUGGAGE COMPARTMENT LAMP DIAGNOSIS
