OUTLINE
The front wiper is controlled by each function of BCM and IPDM E/R.
Control by BCM
- Combination switch reading function
- Front wiper control function
Control by IPDM E/R
- Front wiper control function
- Relay control function
DETAILED FLOW
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | LISTEN TO CUSTOMER COMPLAINT Listen to customer complaint. Get detailed information about the conditions and environment when the symptom occurs. | GO TO 2 | |
| 2 | VERIFY THE SYMPTOM WITH OPERATIONAL CHECK Verify the symptom with operational check. Refer to [ DIAGNOSIS SYSTEM (IPDM E/R): DIAGNOSIS DESCRIPTION ]. | GO TO 3 | |
| 3 | GO TO APPROPRIATE TROUBLE DIAGNOSIS Go to appropriate trouble diagnosis. Refer to [ WIPER AND WASHER SYSTEM SYMPTOMS: SYMPTOM TABLE ]. | GO TO 4 | |
| 4 | REPAIR OR REPLACE Repair or replace the specific parts. | GO TO 5 | |
| 5 | FINAL CHECK Final check. Is inspection result normal? | Inspection End. | Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] |
DIAGNOSTIC INFORMATION CHART
SDT Function (BCM - COMMON ITEM)
Refer to [ SDT FUNCTION (BCM - COMMON ITEM) ].
Utility
| Work Item | Setting Item | Description |
|---|---|---|
| WIPER SPEED SETTING | ON (1) | With vehicle speed (Front wiper intermittent time linked with the vehicle speed and wiper intermittent dial position) |
| OFF | Without vehicle speed (Front wiper intermittent time linked with the wiper intermittent dial position) | |
| (1) Factory setting | ||
| (1) | Factory setting |
ITEM DESCRIPTION
Data List
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Ignition switch ON status judged from ignition power supply |
| IGN SW CAN [ON/OFF] | Ignition switch ON status received from IPDM E/R with CAN communication |
| FR WIPER HI [ON/OFF] | Each switch status that BCM judges from the combination switch reading function |
| FR WIPER LOW [ON/OFF] | |
| FR WIPER INT [ON/OFF] | |
| FR WASHER SW [ON/OFF] | |
| INT VOLUME [1 - 7] | Each switch status that BCM judges from the combination switch reading function |
| FR WIPER STOP [ON/OFF] | Front wiper motor (stop position) status received from IPDM E/R with CAN communication |
| VEHICLE SPEED [km/h] | The value of the vehicle speed signal received from combination meter with CAN communication |
| RR WIPER ON [ON/OFF] | Each switch status that BCM judges from the combination switch reading function |
| RR WIPER INT [ON/OFF] | |
| RR WASHER SW [ON/OFF] | |
| RR WIPER STOP [ON/OFF] | Rear wiper motor (stop position) status input from the rear wiper motor |
| H/L WASH SW (1) | |
| (1) The item is indicated, not monitored. | |
| (1) | The item is indicated, not monitored. |
MONITOR ITEM DESCRIPTION
SDT Function (IPDM E/R)
Refer to [ SDT FUNCTION (IPDM E/R) ].
Reference Value
Refer to "REFERENCE VALUE" in ECU DIAGNOSIS: BCM (BODY CONTROL MODULE)
Terminal Layout
Refer to "TERMINAL LAYOUT" in ECU DIAGNOSIS: BCM (BODY CONTROL MODULE)
Physical Values
Refer to "PHYSICAL VALUES" in ECU DIAGNOSIS: BCM (BODY CONTROL MODULE)
Fail Safe: BCM
Refer to FAIL SAFE: BCM
Refer to "REFERENCE VALUE" in ECU DIAGNOSIS: IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) .
Refer to "TERMINAL LAYOUT" in ECU DIAGNOSIS: IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) .
Refer to "PHYSICAL VALUES" in ECU DIAGNOSIS: IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) .
Fail Safe: IPDM E/R
Refer to [ FAIL SAFE: IPDM E/R ].
Component Function Check
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK FRONT WIPER LO OPERATION IPDM E/R AUTO ACTIVE TEST Start IPDM E/R auto active test. Refer to [ DIAGNOSIS SYSTEM (IPDM E/R): DIAGNOSIS DESCRIPTION ]. Check that the front wiper operates at the LO operation. SDT ACTIVE TEST Select "FRONT WIPER" of IPDM E/R active test item. While operating the test item, check front wiper operation. LO: Front wiper (LO) operation OFF: Stop the front wiper. Is front wiper (LO) operation normal? | Front wiper motor LO circuit is normal. | Refer to [ FRONT WIPER MOTOR LO CIRCUIT CHECK ]. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK FRONT WIPER HI OPERATION IPDM E/R AUTO ACTIVE TEST Start IPDM E/R auto active test. Refer to [ DIAGNOSIS SYSTEM (IPDM E/R): DIAGNOSIS DESCRIPTION ]. Check that the front wiper operates at the HI operation. SDT ACTIVE TEST Select "FRONT WIPER" of IPDM E/R active test item. While operating the test item, check front wiper operation. HI: Front wiper (HI) operation OFF: Stop the front wiper. Is front wiper (HI) operation normal? | Front wiper motor HI circuit is normal. | Refer to [ FRONT WIPER MOTOR HI CIRCUIT CHECK ]. |
DIAGNOSIS PROCEDURE
COMPONENT FUNCTION CHART Step Action YES NO 1 CHECK FRONT WIPER (AUTO STOP) SIGNAL CHECK SDT data list Select "FR WIPER STOP" of IPDM E/R data list item. Operate the front wiper. Check that "FR WIPER STOP" changes to "ON" and "OFF" linked with the wiper operation. Is the status of item normal? Front wiper auto stop signal circuit is normal. Refer to [ FRONT WIPER AUTO STOP SIGNAL CIRCUIT CHECK ]
Scheme 31
Front Wiper Motor Ground Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK FRONT WIPER MOTOR (GROUND) OPEN CIRCUIT Turn the ignition switch OFF. 2. Disconnect front wiper motor. 3. Check continuity between front wiper motor harness connector and ground. Does continuity exist? Front wiper motor ground circuit is normal. Repair or replace harness
Scheme 32
FRONT WIPER MOTOR PROTECTION FUNCTION
- IPDM E/R may stop the front wiper to protect the front wiper motor if any obstruction (operation resistance) such as a large amount of snow is detected during the front wiper operation.
- At that time turn OFF the front wiper and remove the foreign object. Then wait for approximately 20 seconds or more and reactivate the front wiper. The wiper will operate normally.
Special Service Tool
Refer to [ SPECIAL SERVICE TOOL ].
Commercial Service Tool
Refer to [ COMMERCIAL SERVICE TOOL ].
