Transfer: Adjustments Suzuki Equator I

Transfer Case 3 illustrations ~309 words

Select Adjustment Pattern

  1. Start engine. Run engine for at least 10 seconds.
  2. Check 4WD shift indicator lamp and 4LO indicator lamp. INDICATOR LAMP CONDITION CHART Indicator lamp condition Refer procedure When 4WD shift indicator lamp or 4LO indicator lamp is flashing. "Pattern A" Except for above. "Pattern B"

METHOD FOR ADJUSTMENT WITH 4WD SHIFT SWITCH AT "4H" OR "4LO"

  1. Start engine. Run the engine for at least 10 seconds.
  2. Shift the transmission according to the directions below, and stay in "N" for at least 2 seconds. For A/T models, stop vehicle and move A/T selector lever to "N" position with brake pedal depressed. For M/T models, stop vehicle and move M/T shift lever to the neutral position with brake and clutch pedal depressed.
  3. Turn 4WD shift switch to "2WD" position. Stay in "2WD" for at least 2 seconds.
  4. Turn ignition switch "OFF".
  5. Start engine.
  6. Erase self-diagnosis. Refer to [ «SDT FUNCTION (4WD)»(ref-375706-S19974404892010102800000) ].
  7. Check 4WD shift indicator lamp and 4LO indicator lamp again. Refer to " «CHECK 4WD SHIFT INDICATOR PATTERN»(ref-375706-S42559178422010102800000) ". If 4WD shift indicator lamp and 4LO indicator lamp do not indicate proper pattern, install new transfer control unit and retry the above check.

Scheme 4

Scheme 4: Precaution for Work
Scheme 4: Precaution for Work

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Before connecting or disconnecting the transfer control unit harness connector, turn ignition switch "OFF" and disconnect the battery cables. Battery voltage is applied to transfer control unit even if ignition switch is turned "OFF".
  2. When connecting or disconnecting pin connectors into or from transfer control unit, take care not to damage pin terminals (bend or break). When connecting pin connectors make sure that there are not any bends or breaks on transfer control unit pin terminals.
  3. Before replacing transfer control unit, perform transfer control unit input/output signal inspection and make sure transfer control unit functions properly. Refer to [ «TRANSFER CONTROL UNIT: REFERENCE VALUE»(ref-375706-S06995483392010102800000) ].
