Starting System: Removal & Installation Suzuki Equator I

REMOVAL

1. Disconnect the negative battery terminal.
2. Remove the air cleaner cover and the air cleaner to intake manifold collector duct. Refer to [ «AIR CLEANER AND AIR DUCT: EXPLODED VIEW»(ref-375720-S11578578132010102800000) ]
3. Remove the harness protector from the starter motor engine room harness.
4. Remove terminal "1" and "2" nuts.
5. Remove the two starter motor bolts, using power tools.
6. Remove the starter motor.

INSTALLATION

Installation is in the reverse order of removal.

Scheme 14

Scheme 15

1. Disconnect the negative battery terminal.
2. Remove engine undercover, using power tools.
3. Remove exhaust manifold cover from exhaust manifold (bank 1) to gain access to starter cover bolts. Refer to [ «EXHAUST MANIFOLD AND THREE WAY CATALYST: EXPLODED VIEW [VQ40DE]»(ref-375741-S20431945982010102800000) ]
4. Remove starter cover bolts and starter cover.
5. Disconnect terminal "1" connector and remove terminal "2" nut.
6. Remove the two starter motor bolts, using power tools.
7. Remove the starter motor.

Installation is in the reverse order of removal.
