Seat Belts: Removal & Installation Suzuki Equator I

Passive Restraints 4 illustrations ~613 words

REMOVAL OF SEAT BELT RETRACTOR - KING CAB

CAUTIONBefore servicing SRS, turn the ignition switch off, disconnect both battery terminals and wait at least three minutes.

Scheme 1

Scheme 1
Scheme 1
  1. Disconnect both the negative and positive battery terminals, then wait at least three minutes.
  2. Remove the rear door finishers. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  3. Remove the retractor anchor bolt, retractor bolt upper, then remove the retractor and belt assembly. On RH side, disconnect the seat belt tension sensor.
  4. Disconnect the seat belt pre-tensioner harness connector. CAUTION: For installing/removing seat belt pre-tensioner connector, insert a thin screwdriver wrapped in tape into the notch, lift the lock and remove the connector. Install the connector with the lock raised, and push the lock into the connector.

INSTALLATION OF SEAT BELT RETRACTOR - KING CAB

Installation is in the reverse order of removal.

  1. Install the seat belt retractor upper bolt first.
  2. Ensure that seat belt height adjuster is locked in the lowest position during installation.

REMOVAL OF SEAT BELT RETRACTOR - CREW CAB

CAUTIONBefore servicing SRS, turn the ignition switch off, disconnect both battery terminals and wait at least three minutes.

Scheme 2

Scheme 2
Scheme 2
  1. Disconnect both the negative and positive battery terminals, then wait at least three minutes.
  2. Remove the center pillar upper/lower finishers. Refer to [ «BODY SIDE TRIM: REMOVAL AND INSTALLATION»(ref-375698-S35253220412010102800000) ]
  3. Remove the seat belt retractor and belt bolts and assembly. On RH side, disconnect the seat belt tension sensor.
  4. Disconnect the seat belt pre-tensioner harness connector. CAUTION: For installing/removing seat belt pre-tensioner connector, insert a thin screwdriver wrapped in tape into the notch, lift the lock and remove the connector. Install the connector with the lock raised, and push the lock into the connector.

INSTALLATION OF SEAT BELT RETRACTOR - CREW CAB

Installation is in the reverse order of removal.

  1. Install the seat belt retractor and belt assembly upper bolt first.
  2. Ensure that seat belt height adjuster is locked in the lowest position during installation.

Scheme 3

Scheme 3: REMOVAL OF SEAT BELT BUCKLE
Scheme 3: REMOVAL OF SEAT BELT BUCKLE
  1. Remove the front seat. Refer to [ «FRONT SEAT: REMOVAL AND INSTALLATION»(ref-375694-S39892786552010102800000) ]
  2. Remove screw and seat cushion inner finisher.
  3. Remove the anchor bolt and buckle.
  4. Disconnect the buckle switch connector from the seat connector.

INSTALLATION OF SEAT BELT BUCKLE

Installation is in the reverse order of removal.

  1. Remove seat belt lower anchor cover and bolt.
  2. Remove the D-ring anchor bolt cover and D-ring anchor bolt.
  3. Remove the upper and lower rear pillar finishers. Refer to «BODY SIDE TRIM: REMOVAL AND INSTALLATION»(ref-375698-S35253220412010102800000) .
  4. Remove seat belt retractor and belt assembly bolt.

Installation is in the reverse order of removal.

REMOVAL OF SEAT BELT RETRACTOR - CREW CAB OUTBOARD

  1. Remove seat belt lower anchor cover and bolt.
  2. Remove the D-ring anchor bolt cover and D-ring anchor bolt.
  3. Remove the upper and lower rear pillar finishers. Refer to «BODY SIDE TRIM: REMOVAL AND INSTALLATION»(ref-375698-S35253220412010102800000) .
  4. Remove seat belt retractor and belt bolt and assembly from vehicle.

INSTALLATION OF SEAT BELT RETRACTOR - CREW CAB OUTBOARD

Installation is in the reverse order of removal.

REMOVAL OF SEAT BELT RETRACTOR - CREW CAB CENTER

  1. Position the rear seat cushion in the folded up position.
  2. Remove seat belt lower anchor cover and bolt.
  3. Remove rear panel upper finisher. Refer to «BODY SIDE TRIM: REMOVAL AND INSTALLATION»(ref-375698-S35253220412010102800000) .
  4. Remove center belt shoulder guide bolts.
  5. Remove seat belt retractor and belt bolt and assembly from vehicle.

INSTALLATION OF SEAT BELT RETRACTOR - CREW CAB CENTER

Installation is in the reverse order of removal.

Scheme 4

Scheme 4: REMOVAL OF SEAT BELT BUCKLE
Scheme 4: REMOVAL OF SEAT BELT BUCKLE
  1. Position rear seat cushion in the folded up position.
  2. Remove the anchor bolt and seat belt buckle.

Installation is in the reverse order of removal.

LATCH (Lower Anchors and Tether for Children) System: Removal and Installation

Note. The LATCH (Lower Anchors and Tether for Children) system is not serviceable.

Top Tether Strap Child Restraint: Removal and Installation

Note. The Top Tether Strap Child Restraint system is not serviceable.
