Active Test
| Test Item | Operation | Description |
|---|---|---|
| TAIL LAMP | ON | Transmits the position light request signal to IPDM E/R with CAN communication to turn the tail lamp ON. |
| OFF | Stops the tail lamp request signal transmission. | |
| HEAD LAMP | HI | Transmits the high beam request signal with CAN communication to turn the headlamp (HI). |
| LO | Transmits the low beam request signal with CAN communication to turn the headlamp (LO). | |
| OFF | Stops the high & low beam request signal transmission. | |
| FR FOG LAMP | ON | Transmits the front fog lights request signal to IPDM E/R with CAN communication to turn the front fog lamp ON. |
| OFF | Stops the front fog lights request signal transmission. | |
| CARGO LAMP | ON | Transmits the cargo lamp request signal to IPDM E/R with CAN communication to turn the each lamp ON. |
| OFF | Stops the day time running light request signal transmission. | |
| CORNERING LAMP (1) | RH | |
| LH | ||
| OFF | ||
| (1) The item is indicated, not monitored. | ||
| (1) | The item is indicated, not monitored. |
ITEM DESCRIPTION
| Test Item | Operation | Description |
|---|---|---|
| FLASHER | RH | Outputs the voltage to turn the right side turn signal lamps ON. |
| LH | Outputs the voltage to turn the left side turn signal lamps ON. | |
| OFF | Stops the voltage to turn the turn signal lamps OFF. |
ITEM DESCRIPTION
| Test Item | Operation | Description |
|---|---|---|
| BATTERY SAVER | OFF | Cuts the interior room lamp power supply to turn interior room lamps OFF. |
| ON | Outputs the interior room lamp power supply to turn interior room lamps ON. (1) | |
| (1) Each lamp switch is in ON position. | ||
| (1) | Each lamp switch is in ON position. |
ITEM DESCRIPTION
Scheme 29
| Work Item | Setting item | Setting | |
|---|---|---|---|
| SET I/L D-UNLCK INTCON | ON (1) | With the interior room lamp timer function | |
| OFF | Without the interior room lamp timer function | ||
| ROOM LAMP ON TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual brightening time. |
| MODE 2 (1) | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 5 | 0 sec. | ||
| ROOM LAMP OFF TIME SET | MODE 1 | 0.5 sec. | Sets the interior room lamp gradual dimming time. |
| MODE 2 | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 (1) | 3 sec. | ||
| MODE 5 | 0 sec. | ||
| (1) Initial setting | |||
| (1) | Initial setting |
ITEM SETTING CHART
| Test Item | Operation | Description |
|---|---|---|
| IGN ILLUM | ON | Outputs the ignition keyhole illumination control signal to turn the ignition keyhole illumination lamp ON. |
| OFF | Stops the ignition keyhole illumination control signal to turn the ignition keyhole illumination lamp OFF. | |
| INT LAMP | ON | Outputs the interior room lamp control signal to turn the interior room lamps ON. |
| OFF | Stops the interior room lamp control signal to turn the interior room lamps OFF. | |
| STEP LAMP TEST | This test is shown, not supported. | |
| LUGGAGE LAMP TEST | This test is shown, not supported. |
ITEM DESCRIPTION
Scheme 30
| Service item | Setting item | Setting | |
|---|---|---|---|
| SET I/L D-UNLCK INTCON | ON | This item is not used for this model | |
| OFF | |||
| ROOM LAMP ON TIME SET | MODE 1 | 0.5 sec. | This item is not used for this model |
| MODE 2 | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 5 | 4 sec. | ||
| MODE 6 | 5 sec. | ||
| MODE 7 | 0 sec. | ||
| ROOM LAMP OFF TIME SET | MODE 1 | 0.5 sec. | This item is not used for this model |
| MODE 2 | 1 sec. | ||
| MODE 3 | 2 sec. | ||
| MODE 4 | 3 sec. | ||
| MODE 5 | 4 sec. | ||
| MODE 6 | 5 sec. | ||
| MODE 7 | 0 sec. | ||
ITEM SETTING CHART
| Test item | Operation | Description |
|---|---|---|
| INT LAMP | ON | This item is not used for this model |
| OFF | ||
| IGN ILLUM | ON | This item is not used for this model |
| OFF | ||
| LUGGAGE LAMP TEST | ON | This item is not used for this model |
| OFF |
ITEM DESCRIPTION
