Engine Electrical Devices: Removal & Installation Suzuki Equator I

Engine Control Systems 1 illustration ~112 words

INSTALLATION

Installation is in the reverse order of removal.

Scheme 3

Scheme 3: INSPECTION AFTER INSTALLATION
  1. Check that the accelerator pedal moves smoothly within the specified range. Accelerator pedal - total pedal applied stroke "A": 48 mm (1.89 in)
  2. Check that the accelerator pedal smoothly returns to the original position.
  3. Perform an electrical inspection of the accelerator pedal position sensor. Refer to [ «P0222, P0223 TP SENSOR»(ref-375703-S20421883882010102800000) ] (QR25DE), [ «P0222, P0223 TP SENSOR»(ref-375704-S32939520052010102800000) ] (VQ40DE). CAUTION: When the harness connector of the accelerator pedal position sensor is disconnected, perform "Accelerator Pedal Released Position Learning". Refer to [ «PROCEDURE AFTER REPLACING ECM»(ref-375703-S37495777622010102800000) ] (QR25DE), [ «PROCEDURE AFTER REPLACING ECM»(ref-375704-S07622904932010102800000) ] (VQ40DE).
