Subaru XV
Wiring diagram

Wiring diagram: Shift interlock — Shift interlock circuit

Subaru XV GP facelift · 2015-2017

All systems

Shift interlock circuit Subaru XV GP facelift

Components on the diagram

    Components on these wiring diagrams

    Click a component to highlight it on every diagram it appears on.
