Rear vehicle detection circuit for Subaru XV GP facelift (2015-2017)

BLK WIRE BLK/WHT WIRE BLU WIRE BRN/WHT WIRE BSD/RCTA BSD/RCTA OFF IND BSD/RCTA OFF SWITCH BUZZER CAN TRANSCEIVER, RECEIVER COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT EXCEPT HYBRID FUSE 4 FUSE 5 FUSE, RELAY BOX (F/B) GB-10 GB-11 GB-12 GB-8 GRN WIRE GRN/YEL WIRE LEFT OUTER MIRROR ASSEMBLY LEFT RADAR SENSOR (MASTER) LT GRN WIRE LT GRN/YEL WIRE MICRO COMPUTER ORG/ WIRE PNK WIRE POWER SUPPLY CIRCUIT RED WIRE RELAY ENERGIZED RIGHT OUTER MIRROR ASSEMBLY RIGHT RADAR SENSOR (SLAVE) VIO WIRE VIO/RED WIRE WARNING LIGHT IND WHT WIRE YEL WIRE
