Wiring diagram: Power windows — Power windows circuit, with hev Subaru XV GP
All systems
- Active bodyworks
- Air conditioning 3
- Anti-lock brakes 2
- Anti-theft 4
- Body control modules 2
- Computer data lines 2
- Cooling fan 2
- Cruise control 2
- Defoggers 4
- Electronic power steering 2
- Engine performance 2.0l
- Engine performance 2.0l hev
- Exterior lights 4
- Ground distribution 2
- Headlights 4
- Horn 2
- Instrument cluster 2
- Interior lights 4
- Navigation 6
- Power distribution 3
- Power door locks 3
- Power mirrors 4
- Power seats 2
- Power top/sunroof 2
- Power windows 2
- Radio 2
- Shift interlock 3
- Starting/charging 5
- Supplemental restraints 2
- Transmission 2
- Warning systems 4
- Wiper/washer 4
Power windows circuit, with hev (1 of 2) Subaru XV GP
Components on the diagram
Power windows circuit, with hev (2 of 2) Subaru XV GP
