ADJUSTMENT
| CAUTION | When the wheel alignment has been adjusted, perform "VDC sensor midpoint setting mode" of the VDC. < Refer to VDC SENSOR MIDPOINT SETTING MODE , ADJUSTMENT, VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). > |
Scheme 6
Scheme 7
Scheme 8
- Adjust the camber angle to the following value. Tire size Camber (Difference between RH and LH 45' or less) Standard vehicle height model P195/65R15 P205/55R16 P205/50R17 -0°20'±0°30' SPORT model P205/50R17 -0°15'±0°30' XV model P225/55R17 0°10'±0°30'
- Loosen the two flange nuts located at the front lower section of the strut. NOTE: When the adjusting bolt needs to be loosened or tightened, hold its head with a wrench and turn the flange nut.
- Turn the camber adjusting bolt so that the camber is set at specification. NOTE: Moving the adjusting bolt by one scale changes the camber by approximately 0°15'. To increase camber. Rotate the left side counterclockwise. Rotate the right side clockwise. To decrease camber. Rotate the left side clockwise. Rotate the right side counterclockwise.
- Tighten two new flange nuts. Tightening torque: 155 N.m (15.81 kgf-m, 114.3 ft-lb)
Scheme 9
- Adjust the steering angle of both inner and outer wheels. Loosen the steering tie-rod lock nut (a), and rotate the tie-rod. Turn the tie-rod to adjust the steering angle of both inner and outer wheels. Tighten the steering tie-rod lock nut (a). Tightening torque: 85 N.m (8.67 kgf-m, 62.7 ft-lb) NOTE: Check and correct the tie-rod boot if twisted.
- Check the toe-in. < Refer to «STEERING ANGLE»(ref-560366-S17025700232013061300000) , INSPECTION, Wheel Alignment. >
