SPECIFICATION
| Model | Except for XV model | XV model | |||
|---|---|---|---|---|---|
| Whole system | Minimum turning radius | M (ft) | 5.3 (17.39) | ||
| Steering angle | Inner wheel | 38.3°±1.5° | 38.5°±1.5° | ||
| Outer wheel | 33.7°±1.5° | 34.0°±1.5° | |||
| Steering wheel diameter | Mm (in) | 375 (14.76) | |||
| Lock-to-lock revolution number | 3.2 | 3.1 | |||
| Gearbox | Type | Rack & pinion type | |||
| Backlash | 0 (Automatic adjusting) | ||||
| Motor (Temperature 20°C (68°F)) | Rated voltage | V | 12 | ||
| Rated torque | N.m (kgf-m, ft-lb) | 4.5 (0.46, 3.31) | |||
| Rated revolution speed | Rpm | 1, 140 | |||
| Rated current | A | 85 | |||
| Rated output | W | 561 | |||
| Model | Except for XV model | XV model | |||
|---|---|---|---|---|---|
| Steering wheel | Free play | Mm (in) | 17 (0.67) or less | ||
| Steering shaft | Clearance between the steering wheel and column cover | Mm (in) | 4 - 6 (0.16 - 0.24) | ||
| Steering gearbox (Power steering system) | Sliding resistance | N (kgf, lbf) | 350 (36, 79) or less Difference between right and left sliding resistance: 20% or less | 333 (34, 75) or less Difference between right and left sliding resistance: 20% or less | |
| Rack shaft play in the radial direction | Right-turn steering | Mm (in) | Horizontal play: 0.6 (0.024) or less Vertical play: 0.4 (0.016) or less | ||
| Left-turn steering | Mm (in) | 0.4 (0.016) or less | |||
| Input shaft play | In radial direction | Mm (in) | 0.18 (0.0071) or less | ||
| In axial direction | Mm (in) | 0.27 (0.0106) or less | |||
| Rotational resistance | N (kgf, lbf) | Maximum allowable value: 18.3 (1.9, 4.1) or less Difference between right and left sliding resistance: 20% or less | Maximum allowable value: 17.7 (1.8, 4.0) or less Difference between right and left sliding resistance: 20% or less | ||
| Steering wheel effort (Power steering system) | At standstill with engine idling on paved road | N (kgf, lbf) | 29.4 (3.0, 6.6) or less | ||
| At standstill with engine stalled on paved road | N (kgf, lbf) | 294.2 (30, 66.2) or less | |||
Scheme 17
Tightening torque: N.m (kgf-m, ft-lb)
T1: 7.5 (0.76, 5.5)
T2: 20 (2.04, 14.8)
T3: 39 (3.98, 28.8)
Scheme 18
Tightening torque: N.m (kgf-m, ft-lb)
T1: 24 (2.45, 17.7)
T2: 27 (2.75, 19.9)
T3: 60 (6.12, 44.3)
T4: 85 (8.67, 62.7)
T5: 90 (9.18, 66.4)
Scheme 19
Tightening torque: N.m (kgf-m, ft-lb)
T: 7.5 (0.76, 5.5)
ELECTRICAL SPECIFICATION
Refer to Control Module I/O Signal of "POWER ASSISTED SYSTEM (POWER STEERING) (DIAGNOSTICS)". < Refer to ELECTRICAL SPECIFICATION , Control Module I/O Signal. >
