Engine Lubrication System (Except Wrx): Other Subaru XV GP

Lubrication System 8 illustrations ~1041 words

CAUTION

  1. Prior to starting work, pay special attention to the following: Always wear work clothes, a safety cap, protective shoes. Additionally, wear a helmet, protective goggles, etc. if necessary. Protect the vehicle using a seat cover, fender cover, etc. Prepare the service tools, clean cloth, containers to catch grease and oil, etc.
  2. Prepare a container and cloth when performing work which oil possibly spills. If oil spills, wipe it off immediately to prevent from penetrating into floor or flowing out for environmental protection.
  3. Vehicle components are extremely hot immediately after driving. Be wary of receiving burns from heated parts.
  4. When performing a repair, identify the cause of trouble and avoid unnecessary removal, disassembly and replacement.
  5. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from battery.
  6. Always use the jack-up point when the shop jacks or rigid racks are used to support the vehicle.
  7. Remove contamination including dirt and corrosion before removal, installation, disassembly or assembly.
  8. Keep the removed parts in order and protect them from dust and dirt.
  9. All removed parts, if to be reused, should be reinstalled in the original positions with attention to the correct directions, etc.
  10. Bolts, nuts and washers should be replaced with new parts as required.
  11. Be sure to tighten the fasteners including bolts and nuts to the specified torque.
  12. If the engine oil is spilt over exhaust pipe or the under cover, wipe it off with cloth to avoid emitting smoke or causing a fire.
  13. Follow all government and local regulations concerning disposal of refuse when disposing of oil.

GENERAL TOOL

TOOL NAMEREMARKS
Oil filter wrench (65/67 mm 14 Flutes)Used for removing and installing oil filter (Blue). (outer diameter: 67.4 mm (2.65 in))
Circuit testerUsed for measuring resistance and voltage.

Scheme 41

Scheme 41: WIRING DIAGRAM

OIL PAN

Note. Before installing the oil pan, wipe and clean the mating surface of oil pan and oil pan upper. Use a new oil pan seal ring.

Scheme 42

Scheme 42: OIL PAN

Scheme 43

Scheme 43
  1. Apply liquid gasket to the mating surfaces of oil pan upper, and install the oil pan. NOTE: Install within 5 min. after applying liquid gasket. Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) or equivalent Liquid gasket applying diameter: 5±1 mm (0.1969±0.0394 in)
  2. Tighten the bolts to install the oil pan to the oil pan upper in the numerical order. Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
  3. Install the front exhaust pipe. < Ref. to «INSTALLATION»(ref-560376-S08119204982013061300000) , Front Exhaust Pipe. >
  4. Install the under cover. < Ref. to «INSTALLATION»(ref-560372-S19308806142013061300000) , Front Under Cover. >
  5. Lower the vehicle.
  6. Connect the battery ground terminal.
  7. Refill the engine oil. < Ref. to «REPLACEMENT»(ref-560354-S15960665222013061300000) , Engine Oil. >

OIL PAN UPPER

Note. Before installing the oil pan upper, clean the mating surface of oil pan upper and cylinder block.

Scheme 44

Scheme 44: OIL PAN UPPER

Scheme 45

Scheme 45

Scheme 46

Scheme 46
  1. Attach the stud bolts to the oil pan upper.
  2. Attach the oil strainer to the oil pan upper. NOTE: Use new O-rings.
  3. Attach the baffle plate to the oil pan upper. Tightening torque: T1: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb) T2: 10 N.m (1.0 kgf-m, 7.4 ft-lb) T3: 18 N.m (1.8 kgf-m, 13.3 ft-lb) T4: 41.7 N.m (4.3 kgf-m, 30.8 ft-lb)
  4. Apply liquid gasket to the mating surface of the oil pan upper as shown in the figure, and install the oil pan upper to the cylinder block. CAUTION: Be careful not to apply any liquid gasket to the O-ring. NOTE: Use new O-rings. Install within 5 min. after applying liquid gasket. Apply liquid gasket 1.5 mm (0.0591 in) outside from the chamfer surface. However, application of liquid gasket on the chamfer surface around the bolt hole is allowed. Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) or equivalent Liquid gasket applying diameter: 5±1 mm (0.1969±0.0394 in)
  5. Tighten the bolts to install the oil pan upper to the cylinder block in the numerical order. NOTE: After tightening, if the liquid gasket is squeezed out onto the seal surface of the chain cover, completely remove any squeezed-out liquid gasket. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
  6. Install the chain cover. < Ref. to «INSTALLATION»(ref-560356-S35441513312013061300000) , Chain Cover. >
  7. Install the oil level switch on the oil pan upper, and secure the harness with clips (A). NOTE: Use new O-rings. Apply a coat of engine oil to the O-rings. Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
  8. Install the oil pan. < Ref. to «OIL PAN»(ref-560354-S39078584872013061300000) , INSTALLATION, Oil Pan and Strainer. >
  9. Install the water pipe assembly. < Ref. to «WATER PUMP»(ref-560359-S26459244592013061300000) , COMPONENT, General Description. >
  10. Install the thermostat cover. < Ref. to «INSTALLATION»(ref-560359-S13877964842013061300000) , Thermostat. >
  11. Install the water pump. < Ref. to «INSTALLATION»(ref-560359-S17083422922013061300000) , Water Pump. >
  12. Lower the vehicle.
  13. Install the engine to the vehicle. < Ref. to «INSTALLATION»(ref-560356-S07921548712013061300000) , Engine Assembly. >
  14. Refill the engine oil. < Ref. to «REPLACEMENT»(ref-560354-S15960665222013061300000) , Engine Oil. >

OIL FILTER

CAUTIONIf the engine oil is spilt over exhaust pipe or the under cover, wipe it off with cloth to avoid emitting smoke or causing a fire.

Note. Clean off water or dust from the oil element mating surface using air. Remove the oil filter.

Scheme 47

Scheme 47
  1. Oil filter (Black) Remove the oil filter using ST. ST 18332AA000 OIL FILTER WRENCH (outer diameter: 68 mm (2.68 in) for oil filter)
  2. Oil filter (Blue) Remove using a general tool (65/67 mm 14 Flutes).

Scheme 48

Scheme 48: OIL PUMP UNION
  1. Remove the oil filter. < Ref. to «OIL FILTER»(ref-560354-S37346450872013061300000) , REMOVAL, Engine Oil Filter. >
  2. Remove the oil pump union from the chain cover.
CAUTIONDo not tighten excessively, or oil may leak.
  1. Clean the oil filter installing surface on the chain cover.
  2. Obtain a new oil filter and apply a thin coat of engine oil to the seal rubber.
  3. Install the oil filter by turning it by hand, being careful not to damage the seal rubber of the oil filter. Tighten the oil filter (Black) with an outer diameter of 68 mm (2.68 in) (approx. 1 rotation) after the seal rubber of the oil filter comes in contact with chain cover. When using a torque wrench, tighten to 14 N.m (1.4 kgf-m, 10.3 ft-lb). Tighten the oil filter (Blue) with an outer diameter of 67.4 mm (2.65 in) (approx. 7/8 rotation) after the seal rubber of the oil filter comes in contact with chain cover. When using a torque wrench, tighten to 12 N.m (1.2 kgf-m, 8.9 ft-lb).
  4. After installing, check the engine oil level and replenish it if necessary. < Ref. to «INSPECTION»(ref-560354-S05253768682013061300000) , Engine Oil. >

OIL PUMP UNION

Install in the reverse order of removal.

Tightening torque

45 N.m (4.6 kgf-m, 33.2 ft-lb)
