Cruise Control System (Except Wrx): Other Subaru XV GP

Cruise Control Systems 1 illustration ~475 words

CAUTION

  1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
  2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
  3. Adjust parts to the given specifications.
  4. Connect the connectors securely during reassembly.
  5. After reassembly, make sure that the each component operates normally.
  6. Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions of "AIRBAG SYSTEM" in this case. < Refer to «CAUTION»(ref-560375-S15420108262013061300000) , General Description. >
  7. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.
  8. If the steering wheel and steering angle sensor (steering roll connector) are removed, perform "VDC sensor midpoint setting mode" of the VDC. < Refer to «VDC SENSOR MIDPOINT SETTING MODE»(ref-560389-S40582429032013061300000) , ADJUSTMENT, VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). >

PREPARATION TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.
Steering wheel pullerUsed for removing the steering wheel.

Scheme 13

Scheme 13: LOCATION
Scheme 13: LOCATION
Relay & fuse boxFuse 15A (stop light & brake switch)(A)

Note. For other related fuses, refer to the Power Supply Circuit wiring diagram. < Refer to the System Wiring Diagram Article. >

CHECK FUSE

  1. Remove the fuse and inspect visually.
  2. If the fuse is blown out, replace the fuse. NOTE: If the fuse is blown again, check the system wiring harness.

NOTE

For operation procedures of each component of the cruise control system, refer to the respective service information.

  1. Cruise control unit: < Refer to «CRUISE CONTROL MODULE»(ref-560402-S20670529982013061300000) . >
  2. Cruise control command switch: < Refer to «CRUISE CONTROL COMMAND SWITCH»(ref-560402-S09705887992013061300000) . >
  3. Combination meter: < Refer to «COMBINATION METER»(ref-560402-S37719072562013061300000) . >
  4. Stop light & brake switch: < Refer to «STOP LIGHT & BRAKE SWITCH»(ref-560402-S00129707752013061300000) . >
  5. Clutch switch: < Refer to «CLUTCH SWITCH»(ref-560402-S18986775122013061300000) . >
  6. Inhibitor switch: < Refer to «INHIBITOR SWITCH»(ref-560402-S11088124342013061300000) . >
  7. Transmission control module (TCM): < Refer to «TRANSMISSION CONTROL MODULE (TCM)»(ref-560402-S40463754272013061300000) . >
  8. Neutral position switch: < Refer to «NEUTRAL POSITION SWITCH»(ref-560402-S15541510472013061300000) . >

The control of cruise control system is carried out in engine control module (ECM).

For the combination meter, refer to "INSTRUMENTATION/DRIVER INFO" service information. < Refer to COMBINATION METER . >

For stop light and brake switch, refer to "BRAKE" service information. < Refer to INSPECTION , Stop Light Switch. >

For clutch switch, refer to "CLUTCH SYSTEM" Service information. < Refer to CLUTCH SWITCH . >

For inhibitor switch, refer to "CONTINUOUSLY VARIABLE TRANSMISSION" service information. < Refer to INHIBITOR SWITCH . >

For transmission control module (TCM), refer to "CONTINUOUSLY VARIABLE TRANSMISSION" service information. < Refer to TRANSMISSION CONTROL MODULE (TCM) . >

For neutral position switch, refer to "MANUAL TRANSMISSION AND DIFFERENTIAL" service information. < Refer to SWITCHES AND HARNESS . >
