PROCEDURE TO ADJUST THE SUBARU SUPER COOLANT CONCENTRATION
| CAUTION | Use the SUBARU Super Coolant with a 50 - 60% concentration in order to obtain maximum antifreeze and anti-rust performance. |
To adjust the concentration of SUBARU Super Coolant according to temperature, find the proper SUBARU Super Coolant concentration in the table, and add dilution water to the SUBARU Super Coolant (concentrated type) until it reaches the proper dilution.
| Relationship of SUBARU Super Coolant concentration and freezing temperature | |||
|---|---|---|---|
| SUBARU Super Coolant concentration | 50% | 55% | 60% |
| Freezing temperature | 36°C (-33°F) | 41°C (-42°F) | 50°C (-58°F) |
Engine coolant and diluting water
Refer to "SPECIFICATION" for recommended engine coolant and diluting water. < Refer to SPECIFICATION , Engine Coolant, General Description. >
Scheme 3
- Disconnect the ground cable from battery.
- Remove the V-belts. < Refer to «REMOVAL»(ref-560356-S39091804112013061300000) , V-belt. >
- Remove the main fan motor assembly. < Refer to «REMOVAL»(ref-560359-S02612206152013061300000) , Radiator Main Fan and Fan Motor. >
- Lift up the vehicle.
- Remove the under cover. < Refer to «REMOVAL»(ref-560372-S42274069342013061300000) , Front Under Cover. >
- Remove the water pump pulley using the ST.
ST1 18355AA000 PULLEY WRENCH
ST2 18334AA030 PULLEY WRENCH PIN SET
Scheme 4
Scheme 5
- Drain engine coolant. < Refer to «DRAINING OF ENGINE COOLANT»(ref-560359-S12749968242013061300000) , REPLACEMENT, Engine Coolant. >
- Remove the water pump pulley. < Refer to «WATER PUMP PULLEY»(ref-560359-S25614742822013061300000) , REMOVAL, Water Pump. >
- Remove the front exhaust pipe. < Refer to «REMOVAL»(ref-560376-S32386970822013061300000) , Front Exhaust Pipe. >
- Remove the water pump from the oil pan upper.
