SPECIFICATION
| Item | Specifications | |||
|---|---|---|---|---|
| Vehicle model | CVT | MT | ||
| Starter | Type | Reduction type | ||
| Model | M000T38571 | M000T33176 | ||
| Manufacturer | Mitsubishi Electric | |||
| Voltage and output | 12 V - 1.2 kW | 12 V - 1.0 kW | ||
| Direction of rotation | Counterclockwise (when observed from pinion) | |||
| Number of pinion teeth | 9 | 8 | ||
| Armature commutator runout | Standard | 0.05 mm (0.0020 in) | ||
| Limit | 0.10 mm (0.0039 in) | |||
| Armature depth of segment mold | Standard | 0.50 mm (0.020 in) | ||
| Brush length | Standard | 12.3 mm (0.484 in) | ||
| Limit | 7.0 mm (0.276 in) | |||
| Brush spring force | Standard | 15.9 - 19.5 N (1.62 - 1.99 kgf, 3.57 - 4.38 lbf) | ||
| Limit | 2.5 N (0.25 kgf, 0.56 lbf) | |||
| No-load characteristics | Voltage | 11 V | ||
| Current | 90 A or less | 95 A or less | ||
| Rotating speed | 2, 370 rpm or more | 2, 500 rpm or more | ||
| Load characteristics | Voltage | 7.5 V | 7.5 V | |
| Current | 300 A | 300 A | ||
| Torque | 10.65 N.m (1.1 kgf-m, 7.8 ft-lb) or more | 8.84 N.m (0.9 kgf-m, 6.5 ft-lb) or more | ||
| Rotating speed | 840 rpm or more | 870 rpm or more | ||
| Lock characteristics | Voltage | 4 V | 4 V | |
| Current | 780 A or less | 680 A or less | ||
| Torque | 20 N.m (2.0 kgf-m, 14.8 ft-lb) or more | 17 N.m (1.7 kgf-m, 12.5 ft-lb) or more | ||
| Generator | Type | Rotating-field three-phase type, voltage regulator built-in type, with load response control system | ||
| Model | A2TL0291 | |||
| Manufacturer | Mitsubishi Electric | |||
| Voltage and output | 12 V - 110 A | |||
| Polarity on ground side | Negative | |||
| Direction of rotation | Clockwise (when observed from pulley side) | |||
| Stator connection | 3-phase type | |||
| Output current | 1, 500 rpm - 46 A or more 2, 500 rpm - 90 A or more 5, 000 rpm - 109 A or more | |||
| Regulated voltage | 14.1 - 14.8 V [20°C (68°F)] | |||
| Rotor slip ring outer diameter | Standard | 22.7 mm (0.894 in) | ||
| Limit | 22.1 mm (0.870 in) | |||
| Brush length | Standard | 18.5 mm (0.728 in) | ||
| Limit | 5.0 mm (0.197 in) | |||
| Battery | Type and capacity | 12 V - 48 AH (55D 23L) | ||
Scheme 1
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.4 (0.1, 1.0)
T2: 6 (0.6, 4.4)
T3: 7.5 (0.8, 5.5)
T4: 10 (1.0, 7.4)
Scheme 2
Tightening torque: N.m (kgf-m, ft-lb)
T1: 2 (0.2, 1.5)
T2: 3.9 (0.4, 2.9)
T3: 4.4 (0.4, 3.2)
T4: 8.9 (0.9, 6.6)
T5: 108 (11.0, 79.8)
Scheme 3
Tightening torque: N.m (kgf-m, ft-lb)
T1: 8.5 (0.9, 6.3)
T2: 16 (1.6, 11.8)
T3: 25 (2.5, 18.4)
T4: 36 (3.7, 26.6)
Scheme 4
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6 (0.6, 4.4)
T2: 7.5 (0.8, 5.5)
T3: 11 (1.1, 8.1)
T4: 13 (1.3, 9.6)
T5: 14 (1.4, 10.3)
