GENERAL TOOL

TOOL NAME	REMARKS
Steering wheel puller	Used for removing and installing the steering wheel.
TORX® T40	Used for removing and installing the beam COMPL - steering.

Scheme 155

Scheme 155: POWER SUPPLY

Scheme 156

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the lock (A). While holding down the lock (A), disconnect the connector.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 157

Scheme 157: AIRBAG CONTROL MODULE

How to disconnect: Push the lock lever plate (A). While holding down the lock lever plate (A), pull the lever toward you.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Insert the connector and push the lock lever in securely.

Scheme 158

Scheme 158: DRIVER'S AIRBAG MODULE (ROLL CONNECTOR)

Scheme 159

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Pull the slide lock (A) in the direction of arrow. With the slide lock pulled, disconnect the connector.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 160

Scheme 160: PASSENGER'S AIRBAG MODULE

Scheme 161

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Pull the slide lock (A) in the direction of arrow. With the slide lock pulled, disconnect the connector.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 162

Scheme 162: DRIVER'S AIRBAG MODULE, CURTAIN AIRBAG MODULE & PRETENSIONER

Scheme 163

How to disconnect: Using a flat tip screwdriver, pry the push lock upward to unlock. Pull the connector to disconnect from the airbag module assembly or the retractor assembly.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Press in the push lock securely. Then pull it gently to make sure that it is locked. Connect the connector in the reverse order of disconnecting. At this time, be sure to insert until a clicking sound is heard.

Scheme 164

Scheme 164: FRONT SUB SENSOR

Scheme 165

Scheme 166

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the lock arm. Holding outer part, pull it one step in the direction of arrow. Push the lock arm again. Holding outer part, pull it in the direction of arrow to disconnect the connector.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 167

Scheme 167: FRONT DOOR IMPACT SENSOR AND SATELLITE SAFING SENSOR

Scheme 168

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Holding outer part (A), pull it in the direction of arrow.
How to connect: CAUTION: Do not touch the outer side section or else the outer side (A) will move back. Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 169

Scheme 169: FRONT DOOR IMPACT SENSOR (BETWEEN AIRBAG REAR HARNESS AND DOOR HARNESS)

Scheme 170

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Pull the slide lock (A) in the direction of arrow. With the slide lock pulled, disconnect the connector.
How to connect: CAUTION: Outer side (A) moves back, and so do not touch the outer part. Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 171

Scheme 171: SIDE AIRBAG SENSOR AND CURTAIN AIRBAG SENSOR

Scheme 172

Scheme 173

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the lock arm. Holding outer part, pull it one step in the direction of arrow. Push the lock arm again. Holding outer part, pull it in the direction of arrow to disconnect the connector.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 174

Scheme 174: SIDE AIRBAG MODULE

Scheme 175

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Move the slide lock (A) in the direction of arrow and hold it. While holding the slide lock (A) in place, pull the connector (B) to the direction of arrow.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 176

Scheme 176: BUCKLE SWITCH RH

Scheme 177

How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Move the slide lock (A) in the direction of arrow and hold it. While holding the slide lock (A), pull the connector (B) in the direction of arrow.
How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.
