Engine Cooling System - Cooling (H6DO): Adjustments Subaru Tribeca WX facelift

Cooling System (Mechanical) 2 illustrations ~234 words

PROCEDURE TO ADJUST THE CONCENTRATION OF THE SUBARU SUPER COOLANT

CAUTIONUse the SUBARU Super Coolant with a 50 - 60% concentration in order to obtain maximum antifreeze and anti-rust performance.

To adjust the concentration of SUBARU Super Coolant according to temperature, find the proper SUBARU Super Coolant concentration in the chart, and add diluting water to the SUBARU Super Coolant (undiluted type) until it reaches the proper dilution.

Relationship of SUBARU Super Coolant concentration and freezing temperature
SUBARU Super Coolant concentration50%55%60%
Freezing temp.36°C (-33°F)41°C (-42°F)50°C (-58°F)

SUBARU SUPER COOLANT CONCENTRATION AND FREEZING TEMPERATURE CHART

Engine coolant and diluting water

Refer to "SPECIFICATION" for the recommended engine coolant and diluting water. Ref. to SPECIFICATION , General Description.

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL
  1. Remove the radiator. Ref. to «REMOVAL»(ref-356686-S07060985392010022700000) , Radiator.
  2. Remove the V-belts. Ref. to «REMOVAL»(ref-356702-S00140377892010022700000) , V-belt.
  3. Remove the crank pulley. Ref. to «REMOVAL»(ref-356702-S02998419892010022700000) , Crank Pulley.
  4. Remove the chain cover. Ref. to «REMOVAL»(ref-356702-S00863908562010022700000) , Chain Cover.
  5. Remove the timing chain assembly. Ref. to «REMOVAL»(ref-356702-S25228579272010022700000) , Timing Chain Assembly.
  6. Remove the water pump.

Scheme 6

Scheme 6: INSTALLATION
Scheme 6: INSTALLATION
  1. Install the water pump to oil pan upper. NOTE: Tighten the bolts in the numerical order as shown in the illustration. Use new O-rings. Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
  2. Install the timing chain assembly. Ref. to «INSTALLATION»(ref-356702-S11926965042010022700000) , Timing Chain Assembly.
  3. Install the chain cover. Ref. to «INSTALLATION»(ref-356702-S27091003422010022700000) , Chain Cover.
  4. Install the crank pulley. Ref. to «INSTALLATION»(ref-356702-S19937659232010022700000) , Crank Pulley.
  5. Install the V-belts. Ref. to «INSTALLATION»(ref-356702-S21173229552010022700000) , V-belt.
  6. Install the radiator. Ref. to «INSTALLATION»(ref-356686-S01138712392010022700000) , Radiator.
  7. Fill engine coolant. Ref. to «FILLING OF ENGINE COOLANT»(ref-356686-S03353205592010022700000) , REPLACEMENT, Engine Coolant.
