SPECIFICATION
| Front | Wheel arch height | 442 (17.4) | |
|---|---|---|---|
| (Tolerance: +12 mm -24 mm ( +0.47 in -0.94 in )) | Mm (in) | ||
| Camber (Tolerance: ±0°45' Differences between RH and LH: 45' or less) | 0°00' | ||
| Caster (Referential Value) | 4°04' | ||
| Steering angle (Tolerance: ±1.5°) | Inner wheel | 37.0° | |
| Outer wheel | 32.0° | ||
| Toe-in | Mm (in) | 0±3 (0±0.12) Toe angle (sum of both wheels): 0°±0°14' | |
| Kingpin angle (Referential Value) | 12°12' | ||
| Rear | Wheel arch height | 439 (17.3) | |
| (Tolerance: +12 mm -24 mm ( +047 in -0.94 in )) | Mm (in) | ||
| Camber (Tolerance: ±0°45' Differences between RH and LH: 45' or less) | 0°31' | ||
| Toe-in | Mm (in) | 2±2 (0.08±0.08) Toe angle (sum of both wheels): 0°10'±0°10' | |
| Thrust angle (Tolerance: ±0°30') | 0° | ||
FRONT WHEEL SPECIFICATION CHART
Note. Front and rear toe-in and front camber can be adjusted. Adjust if the toe-in or camber tolerance exceeds specifications. Other items indicated in the specifications chart cannot be adjusted. If other items exceed specifications, check the suspension parts and connections for deformation, and replace with new parts as required.
Scheme 4
Tightening torque: N.m (kgf-m, ft-lb)
T1: 20 (2.0, 14.5)
T2: 25 (2.5, 18.1)
T3: 45 (4.6, 33.2)
T74: 60 (6.1, 44.3)
T5: 50 (5.1, 36.9)
T6: 55 (5.6, 40.6)
T7: 60 (6.1, 44.3)
T8: 88 (9.0, 64.9)
T9: 95 (9.7, 70.1)
T10: 110 (11.2, 81.1)
T11: 150 (15.3, 110.6)
T12: 155 (15.8, 114.3)
