Engine Ignition System (H6DO): Removal & Installation Subaru Tribeca WX рестайлинг

REMOVAL

Spark plug

Ref. to SPECIFICATION , General Description .

Scheme 8

Scheme 9

Scheme 10

1. Remove the collector cover.
2. Disconnect the ground cable from battery.
3. Remove the air cleaner case. Ref. to «REMOVAL»(ref-356695-S25477935752010022700000) , Air Cleaner Case .
4. Remove the bracket (A).
5. Disconnect the connector (B) from ignition coil.
6. Remove the ignition coil. NOTE: Turn the #5 ignition coil to remove it.
7. Remove the spark plug with a spark plug socket.

Scheme 11

Scheme 12

Scheme 13

1. Remove the collector cover.
2. Remove the battery and battery carrier.
3. Remove the bracket (A).
4. Disconnect the connector (B) from ignition coil.
5. Remove the ignition coil. NOTE: Turn the #6 ignition coil to remove it.
6. Remove the spark plug with a spark plug socket.

Direct ignition type has been adopted. Refer to "Spark Plug" for removal procedure, Ref. to REMOVAL , Spark Plug .

INSTALLATION

Install in the reverse order of removal.

Tightening torque

16 N.m (1.6 kgf-m, 11.8 ft-lb)
