SPECIFICATION
| Headlight | Halogen type low beam | 12 V - 55 W |
|---|---|---|
| HID type low beam | 12 V - 35 W | |
| Halogen type high beam | 12 V - 60 W | |
| Front turn signal, parking | 12 V - 28/8 W | |
| Front side marker light | 12 V - 5 W | |
| Front fog light | 12 V - 55 W | |
| Side turn signal light | 12 V - 1.4 W (LED) | |
| Rear combination light | Stop/Tail light/Rear side marker light | 12 V - 27/8 W |
| Turn signal light | 12 V - 27 W | |
| Rear finisher light | 12 V - 5 W | |
| Back-up light | 12 V - 16 W | |
| License plate light | 12 V - 5 W | |
| High-mounted stop light | 12 V - 1.2 W (LED) | |
| Room light | 12 V - 8 W (Model without rear entertainment system) | |
| 12 V - 5 W (Model with rear entertainment system) | ||
| Spot map light | 12 V - 8 W | |
| Luggage room light | 12 V - 13 W | |
| Rear gate light | 12 V - 5 W | |
| Glove box light | 12 V - 1.4 W | |
| Door step light | 12 V - 3 W | |
| Vanity mirror light | 12 V - 3 W | |
SPECIFICATION CHART
The parking light bulb is integrated into the front turn signal light bulb as a unit; therefore, refer to "Front Turn Signal Light Bulb" for the removal procedure. Ref. to REMOVAL , Front Turn Signal Light Bulb.
Scheme 4
- Open the front hood.
- Turn the socket (A) and remove the front turn signal light bulb.
The rear side marker light bulb is integrated into the tail/stop light as a single unit; therefore, refer to REMOVAL , Tail/Stop Light Bulb.
Scheme 5
Scheme 6
- Remove the bulb inspection cover (A) of the rear gate trim.
- Disconnect the harness connector.
- Remove the mounting nuts and detach the rear finisher assembly.
