SPECIFICATION
| Item | Specification | ||
|---|---|---|---|
| Vehicle model | AT | ||
| Starter | Type | Reduction type | |
| Model | 428000-5250 | ||
| Manufacturer | DENSO | ||
| Voltage and output | 12 V - 1.6 kW | ||
| Direction of rotation | Counterclockwise (when observed from pinion) | ||
| Number of pinion teeth | 9 | ||
| No-load characteristics | Voltage | 11 V | |
| Current | 90 A or less | ||
| Rotating speed | 1,550 rpm or more | ||
| Load characteristics | Voltage | 8 V | |
| Current | 370 A | ||
| Torque | 12.8 N.m (1.31 kgf-m, 9.4 ft-lb) or more | ||
| Rotating speed | 800 rpm or more | ||
| Lock characteristics | Voltage | 3 V | |
| Current | 750 A or less | ||
| Torque | 19.0 N.m (1.9 kgf-m, 14.0 ft-lb) or more | ||
| Generator | Type | Rotating-field three-phase type, voltage regulator built-in type, with load response control system | |
| Model | A003TJ2091 | ||
| Manufacturer | MITSUBISHI ELECTRIC | ||
| Voltage and output | 12 V - 130 A | ||
| Polarity on ground side | Negative | ||
| Direction of rotation | Clockwise (when observed from pulley side) | ||
| Armature connection | Delta connection | ||
| Output current | 1,500 rpm - 55 A or more 2,500 rpm - 108 A or more 5,000 rpm - 127 A or more | ||
| Regulated voltage | 14.1 - 14.8 V [20°C (68°F)] | ||
| Battery | Type and capacity | 12 V - 52 AH (75D23L) | |
ITEM SPECIFICATION CHART
Scheme 1
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.4 (0.1, 1.0)
T2: 6 (0.6, 4.4)
T3: 7.5 (0.8, 5.5)
T4: 10 (1.0, 7.4)
Scheme 2
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.7 (0.5, 3.5)
T2: 108 (11.0, 79.8)
