PROCEDURE
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK PRE-INSPECTION. Ask the customer when and how the trouble occurred using the interview check list. Ref. to CHECK LIST FOR INTERVIEW . Before performing diagnosis, inspect the following item which might influence the AT problems. General inspection, Ref. to INSPECTION , General Description. Oil leaks Stall speed test, Ref. to STALL TEST . Line pressure test, Ref. to LINE PRESSURE TEST . Transfer clutch pressure test, Ref. to TRANSFER CLUTCH PRESSURE TEST . Time lag test, Ref. to TIME LAG TEST . Road test, Ref. to ROAD TEST . Inhibitor switch, Ref. to INHIBITOR SWITCH . | Is the unit that might influence the AT problem normal? | Go to step 2. | Repair or replace each item. |
| 2 CHECK AT OIL TEMP LIGHT. After the ignition switch is turned to ON, wait for at least 2 seconds. | Does the AT OIL TEMP light illuminate? | Go to step 4. | Go to step 3. |
| 3 CHECK AT OIL TEMP LIGHT. Turn the ignition switch to OFF. Check the AT OIL TEMP light. Ref. to INSPECTION , AT Oil Temp Warning Light Display. After the ignition switch is turned to ON, wait for at least 2 seconds. | Does the AT OIL TEMP light blink? | Go to step 4. | Go to step 5. |
| 4 CHECK DTC. Read the DTC. Ref. to OPERATION , Read Diagnostic Trouble Code (DTC). NOTE: If the communication function of Subaru Select Monitor cannot be executed normally, check the communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure for Subaru Select Monitor Communication. | Is DTC displayed? | Go to step 6. NOTE: Record all DTC. | Go to step 5. |
| 5 PERFORM GENERAL DIAGNOSTICS. Inspect using "Diagnostic Procedure without Diagnostic Trouble Code (DTC)". Ref. to DIAGNOSTIC PROCEDURE WITHOUT DIAGNOSTIC TROUBLE CODE (DTC) . Perform the Clear Memory Mode. Perform the Inspection Mode. Ref. to INSPECTION MODE . Display DTC. | Is DTC displayed? | Go to step 6. | Inspect using "General Diagnostic Table". Ref. to GENERAL DIAGNOSTIC TABLE . |
| 6 PERFORM THE DIAGNOSIS. Inspect by referring to "Diagnostic Procedure with Diagnostic Trouble Code (DTC)". Ref. to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . NOTE: For the DTC table, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . Repair the trouble cause. Perform the Clear Memory Mode. Perform the Inspection Mode. Ref. to INSPECTION MODE . Display DTC. | Is DTC displayed? | Inspect by referring to "Diagnostic Procedure with Diagnostic Trouble Code (DTC)". Ref. to DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC) . | Inspect using "General Diagnostic Table". Ref. to GENERAL DIAGNOSTIC TABLE . |
| NOTE |
|---|
| If the communication function of Subaru Select Monitor cannot be executed normally, check the communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure for Subaru Select Monitor Communication. |
| NOTE |
|---|
| Record all DTC. |
| NOTE |
|---|
| For the DTC table, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . |
DIAGNOSTIC PROCEDURE
CHECK
Check the following item when problem has occurred.
Note. Use copies of this illustration for interviewing customers.
Scheme 96
SRS AIRBAG SYSTEM
The airbag system wiring harness is routed near the TCM.
| CAUTION | All airbag system wiring harnesses and connectors are colored yellow. Do not use an electric test equipment to check these circuits. Be careful not to damage the airbag system wiring harness when performing diagnostics or servicing the TCM. |
MEASUREMENT
When measuring the voltage and resistance of the ECM, TCM or each sensor, use a tapered pin with a diameter of less than 0.64 mm (0.025 in) in order to avoid poor contact. Do not insert a pin of more than 0.65 mm (0.026 in) diameter.
BATTERY
Measure the battery voltage and specific gravity of electrolyte.
Standard voltage
12 V or more
Specific gravity
1.260 or more
TRANSMISSION GROUND
Make sure that the ground terminal bolt is tightened securely.
Tightening torque
13 N.m (1.3 kgf-m, 9.4 ft-lb)
Scheme 97
ATF LEVEL
Make sure that ATF level is the specified amount. Ref. to INSPECTION , Automatic Transmission Fluid.
Scheme 98
FRONT DIFFERENTIAL OIL LEVEL
Make sure the front differential oil level is the specified amount. Ref. to INSPECTION , Differential Gear Oil.
Scheme 99
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and current. |
| Oscilloscope | Used for measuring the sensor. |
TOOL NAME REFERENCE
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
Scheme 105
Scheme 106
Note. The measurement should be performed after warming up.
| Item | Connector No. | Terminal No. | Measuring condition | Measured value | Resistance between terminal and chassis ground | Remarks |
|---|---|---|---|---|---|---|
| P/L solenoid output | B54 | 6 | Engine ON, "P" range, accelerator OFF, brake ON | 3.5 - 7.5 V | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Drive frequency: 300 Hz |
| I/C oil pressure switch input | B54 | 20 | While driving at 1st-3rd of manual mode | 6 V or more | ||
| While driving at 4th or 5th of manual mode | Less than 1.5 V | |||||
| Power GND | B54 | 12 | Always | Approx. 0 V | ||
| CAN communication line (+) | B55 | 21 | ||||
| CAN communication line (-) | B55 | 20 | ||||
| ATF temperature sensor 1 input | B54 | 17 | Ignition switch ON ATF oil temperature 20°C (68°F) | 3.5 - 4.3 V | 2.5 - 7.0 kohms | When measuring the resistance, be sure to disconnect the connector and perform the measurement with TCM alone. |
| Ignition switch ON ATF oil temperature 80°C (176°F) | 1 - 2.2 V | 0.3 - 0.8 kohms | ||||
| Back-up power supply | B55 | 24 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | ||||||
| I/C solenoid output | B54 | 3 | While driving at 1st-3rd of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Drive frequency: 300 Hz |
| While driving at 4th or 5th of manual mode | Less than 1.5 V | |||||
| H & LR/C solenoid output | B54 | 5 | While driving at 2nd of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Drive frequency: 300 Hz |
| While driving at 1st, 3rd-5th of manual mode | Less than 1.5 V | |||||
| Power GND | B54 | 13 | Always | Approx. 0 V | ||
| Analog GND | B54 | 18 | Always | Approx. 0 V | ||
| Fr/B solenoid output | B54 | 4 | While driving at other than 4th of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Drive frequency: 300 Hz |
| While driving at 4th of manual mode | Less than 1.5 V | |||||
| L/U solenoid output | B54 | 7 | When lock-up | 3 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Drive frequency: 300 Hz |
| When not lock-up | Less than 1 V | |||||
| D/C solenoid output | B54 | 1 | While driving at 1st or 5th of manual mode | 5 V or more | 3 - 9 ohms (ATF temperature 20°C (68°F)) | Drive frequency: 300 Hz |
| While driving at 2nd-4th of manual mode | Less than 1.5 V | |||||
| D/C oil pressure switch input | B54 | 22 | While driving at 1st or 5th of manual mode | 6 V or more | ||
| While driving at 2nd-4th of manual mode | Less than 1.5 V | |||||
| Subaru Select Monitor communication line | B55 | 8 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Sensor | GND (analog) B54 | 16 | Always | Approx. 0 V | ||
| H&LR/C oil pressure switch input | B54 | 14 | While driving at 2nd of manual mode | 6 V or more | ||
| While driving at 3rd-5th of manual mode | Less than 1.5 V | |||||
| Fwd/B solenoid output | B54 | 19 | While driving at 1st or 2nd of manual mode | 5 V or more | Drive frequency: 300 Hz | |
| While driving at 3rd-5th of manual mode | Less than 1.5 V | |||||
| Fwd/B oil pressure switch input | B54 | 21 | While driving at 1st or 2nd of manual mode | Less than 1.5 V | ||
| While driving at 3rd-5th of manual mode | 6 V or more | |||||
| Front vehicle speed sensor input | B54 | 24 | While driving at 2nd and 20 km/h (12 MPH) of manual mode | Approx. 500 - 700 rpm | Use the Subaru Select Monitor. | |
| While driving at 4th and 80 km/h (50 MPH) of manual mode | Approx. 2,000 - 2,500 rpm | Use the Subaru Select Monitor. | ||||
| Inhibitor switch 1 input | B54 | 8 | Ignition switch ON, "P" range | Less than 0.5 V | ||
| Ignition switch ON, "N" range | 5 V or more | |||||
| Inhibitor switch 2 input | B54 | 9 | Ignition switch ON, "P" range | 5 V or more | ||
| Ignition switch ON, "D" range | Less than 0.5 V | |||||
| Ignition power supply | B54 | 27 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Rear vehicle speed sensor input | B54 | 23 | While driving at 2nd and 20 km/h (12 MPH) of manual mode | Approx. 500 - 700 rpm | Use the Subaru Select Monitor. | |
| While driving at 4th and 80 km/h (50 MPH) of manual mode | Approx. 2,000 - 2,500 rpm | Use the Subaru Select Monitor. | ||||
| Fr/B oil pressure switch input | B54 | 15 | While driving at other than 4th of manual mode | Less than 1.5 V | ||
| While driving at 4th of manual mode | 6 V or more | |||||
| Turbine speed sensor 1 input | B54 | 26 | 2nd of manual mode, turbine speed sensor is 2,000 rpm (Read from Subaru Select Monitor) | Approx. 0 rpm | Use the Subaru Select Monitor. | |
| 4th of manual mode, turbine speed sensor is 2,000 rpm (Read from Subaru Select Monitor) | Approx. 1,900 - 2,100 rpm | Use the Subaru Select Monitor. | ||||
| Inhibitor switch 3 input | B54 | 10 | Ignition switch ON, "R" range | 5 V or more | ||
| Ignition switch ON, "D" range | Less than 0.5 V | |||||
| Control GND1 | B55 | 23 | Ignition switch ON | Approx. 0 V | ||
| Ignition switch OFF | ||||||
| Control GND2 | B55 | 22 | Ignition switch ON | Approx. 0 V | ||
| Ignition switch OFF | ||||||
| Inhibitor switch 4 input | B54 | 11 | Ignition switch ON, "P" range | Less than 0.5 V | ||
| Ignition switch ON, "D" range | 5 V or more | |||||
| Back-up light relay output | B55 | 13 | Ignition switch ON, "R" range | Less than 1 V | 90 - 110 ohms (ATF temperature 25°C (77°F)) | |
| Ignition switch ON, other than "R" range | 8 V or more | |||||
| AWD solenoid output | B54 | 2 | Engine ON, "P" range or "N" range, accelerator OFF | Less than 1 V | 3 - 9ohms (ATF temperature 20°C (68°F)) | Drive frequency: 300 Hz |
| Engine ON, "D" range, accelerator OFF, brake ON | 2 V or more | |||||
| Turbine speed sensor 2 input | B54 | 25 | 2nd of manual mode, turbine speed sensor is 2,000 rpm (Read from Subaru Select Monitor) | Approx. 1,200 - 1,500 rpm | Use the Subaru Select Monitor. | |
| 4th of manual mode, turbine speed sensor is 2,000 rpm (Read from Subaru Select Monitor) | Approx. 1,900 - 2,100 rpm | Use the Subaru Select Monitor. | ||||
| PN signal output | B55 | 11 | Ignition switch ON, Other than "P" range or "N" range | 8 V or more | ||
| Ignition switch ON, "P" range or "N" range | Less than 1 V | |||||
| Ignition power supply 1 | B55 | 26 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | ||||||
| Ignition power supply 2 | B55 | 19 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Ignition power supply 3 | B55 | 18 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF | Less than 1 V | |||||
| Ignition power supply 4 | B55 | 25 | Ignition switch ON | 8 V or more | ||
| Ignition switch OFF |
CONNECTOR TERMINAL REFERENCE
Scheme 107
- Prepare the Subaru Select Monitor kit. Ref. to «PREPARATION TOOL»(ref-356687-S05357886002010022700000) , General Description.
- Prepare PC with Subaru Select Monitor installed.
- Connect the USB cable to the SDI (Subaru Diagnostic Interface) and the USB port of the personal computer (port for Subaru Select Monitor). NOTE: The dedicated port for the Subaru Select Monitor means the USB port which was used to install the Subaru Select Monitor.
- Connect the diagnosis cable to SDI.
- Connect the SDI to the data link connector located in the lower portion of the instrument panel (on the driver's side). CAUTION: Do not connect scan tools other than the Subaru Select Monitor.
- Start the PC.
- Turn the ignition switch to ON (engine OFF).
- Run the "PC application for Subaru Select Monitor".
- On the «Main Menu» display screen, select the {Each System Check}.
- On the «System Selection Menu», select {Transmission Control System}.
- After transmission type information pops up, select [OK].
- On the «Transmission Diagnosis» display screen, select {Diagnostic Code(s) Display}.
- On the «Diagnostic Code(s) Display» screen, select the {Temporary Diagnostic Code(s)} or {Memorized Diagnostic Code(s)}
READ CURRENT DATA
- On the «Main Menu» display screen, select the {Each System Check}.
- On the «System Selection Menu», select {Transmission Control System}.
- After transmission type information pops up, select [OK].
- On the «Transmission Diagnosis» screen, select {Current Data Display & Save}.
- Select {Normal sampling} on the «Current Data Display & Save» screen.
- Using the scroll key, scroll the display screen up or down until the desired data is shown. A list of the support data is shown in the following table. SUPPORT DATA REFERENCE Item Display Unit of measure Engine speed signal Engine Speed rpm Battery voltage Battery Voltage V Accelerator pedal position sensor Accel. Opening Angle % Front vehicle speed sensor signal Front Wheel Speed km/h Gear position Gear Position - Turbine speed sensor signal Turbine Revolution Speed rpm Rear vehicle speed sensor signal Rear Wheel Speed km/h Lateral G sensor Lateral G Sensor V ATF temperature sensor signal ATF Temp. °C Turbine speed sensor 1 signal AT Turbine Speed 1 rpm Turbine speed sensor 2 signal AT Turbine Speed 2 rpm High & low reverse clutch solenoid indicator current H&LR/C Solenoid Current A Direct clutch solenoid indicator current D/C Solenoid Current A Front brake solenoid indicator current F/B Solenoid Current A Input clutch solenoid indicator current I/C Solenoid Current A Line pressure solenoid indicator current P/L Solenoid Current A Lock-up solenoid indicator current L/U Solenoid Current A Transfer solenoid indicator current AWD Sol. Current A High & low reverse clutch solenoid target oil pressure H&LR/C Solenoid Pressure kPa Direct clutch solenoid target oil pressure D/C Solenoid Pressure kPa Front brake solenoid target oil pressure F/B Solenoid Pressure kPa Input clutch solenoid target oil pressure I/C Solenoid Pressure kPa Line pressure solenoid target oil pressure P/L Solenoid Pressure kPa Lock-up solenoid target oil pressure L/U Solenoid Pressure kPa Transfer solenoid target oil pressure AWD Solenoid Pressure kPa Ignition switch Ignition Switch ON Input or OFF Input Tip signal Tiptronic Mode Switch ON or OFF Cruise control ON signal Cruise Control Signal ON or OFF Tip down shift signal Down Switch ON or OFF Stop light switch signal Stop Light Switch ON or OFF Tip up shift signal Up Switch ON or OFF Drive range signal D Range Signal ON or OFF Reverse range signal R Range Signal ON or OFF Diagnosis light output signal Diagnosis Lamp ON or OFF ATF oil temperature light signal ATF Temperature Lamp ON or OFF Parking range signal P Range ON or OFF P/N range output signal P/N Signal ON or OFF Neutral range signal N Range ON or OFF Inhibitor switch 1 input signal Inhibitor SW 1 High or Low Inhibitor switch 2 input signal Inhibitor SW 2 High or Low Inhibitor switch 3 input signal Inhibitor SW 3 High or Low Inhibitor switch 4 input signal Inhibitor SW 4 High or Low Backup light relay output signal Back Lamp Relay ON or OFF High & low reverse clutch oil pressure switch input signal H&LR/C Fluid Pressure ON or OFF Direct clutch oil pressure switch input signal D/C Fluid Pressure ON or OFF Front brake oil pressure switch input signal F/B Fluid Pressure ON or OFF Input clutch oil pressure switch input signal I/C Fluid Pressure ON or OFF Forward brake indicator current Fwd/B solenoid current A Forward brake solenoid input signal Fwd/B solenoid target pressure kPa Forward brake oil pressure switch input signal Fwd/B hydraulic pressure SW ON or OFF NOTE: For details concerning the operation procedure, refer to «SUBARU SELECT MONITOR»(ref-356722-S32609844612010022700000) .
CLEAR MEMORY MODE
- Shift the select lever to "P" range.
- On the «Main Menu» display screen, select the {Each System Check}.
- On the «System Selection Menu», select {Transmission Control System}.
- After transmission type information pops up, select [OK].
- On the «Transmission Diagnosis» display screen, select {Clearing Memory}.
- When "Done. Turn ignition switch to OFF" pops up, select [OK].
- Turn the Subaru Select Monitor and ignition switch to OFF. To turn the ignition switch to ON again, wait for more than 10 seconds. NOTE: To clear the previous DTC, use {Clearing Memory}, and to clear the learned value, use {Clear Memories 2}. For details concerning the operation procedure, refer to «SUBARU SELECT MONITOR»(ref-356722-S32609844612010022700000) .
| WARNING | Observe the traffic law during driving on roads. |
- Shift the select lever to "D" range, and then drive the vehicle with changing the gear from 1st to 5th.
- When driving the vehicle at 5th speed of "D" range, set the gear to manual mode and drive the vehicle by downshifting using "-" of the select lever from 5th --> 4th, 4th --> 3rd, 3rd --> 2nd, and 2nd --> 1st. NOTE: At shifting down, drive the vehicle at least 10 seconds in each speed.
- Shift the select lever to "R" range and drive the vehicle for more than 2 seconds.
PREPARATION FOR LEARNING CONTROL
- Warm-up or cool down until the ATF temperature displayed on the Subaru Select Monitor reaches 60 - 80°C (140 - 176°F).
- Shift the select lever to "P" range.
- Fully apply the parking brake.
- Lift up the vehicle. CAUTION: Be sure to keep the lowest edge of the tires 30 cm or more off the ground because the vehicle vibrates during the work.
- Connect the Subaru Select Monitor to the data link connector.
- Turn the ignition switch to ON. (Press push button ignition switch twice without depressing brake pedal for push button start.)
- Select {Learning and inspection mode related to AT} on the «Transmission Diagnosis» display screen of Subaru Select Monitor.
- Select {AT learning mode} on the «Learning and inspection mode related to AT» display screen of Subaru Select Monitor.
- Perform the procedures according to the message displayed on the Subaru Select Monitor.
SIMPLE LEARNING
Note. Simple learning is learning performed with the vehicle lifted, without actually running the vehicle.
| CAUTION | Do not turn the power of the Subaru Select Monitor OFF during work, and do not disconnect the data link connector. |
- Follow the messages displayed on the Subaru Select Monitor screen when working. NOTE: For the messages "SHIFT control system learning in progress" and "AWD control system learning in progress", AT OIL TEMP light in the combination meter blinks at a cycle of 2 Hz before learning operation starts. When AT OIL TEMP light in the combination meter goes off, the following message is displayed on the screen. When operation ends abnormally during the learning, AT OIL TEMP light blinks at a cycle of 4 Hz.
- AT simple learning is complete when the message "AT learning normally ended" is displayed. NOTE: If a communication error occurs during learning, restart the «AT learning mode» over from the beginning. If the message "Execute AT learning again after fixing troubles of the vehicle" appears, select [OK] and display the DTC list. After repairing the locations indicated by the DTC, start the "AT learning mode" over from the beginning. If the message "AT learning ended abnormally" is displayed, start the "AT learning mode" over from the beginning. MALFUNCTION CHART Message Main cause of abnormal incompletion "AT learning ended abnormally" A malfunction was detected during AT learning The accelerator pedal was pressed during AT learning An unspecified operation was performed during AT learning Brake pedal not stepped on firmly enough. Parking brake not applied strongly enough. Abnormal idle speed increase, etc. For details concerning the operation procedure, refer to «SUBARU SELECT MONITOR»(ref-356722-S32609844612010022700000) .
DRIVING CHECK
Drive actually and check for shifting shock or faults. If shifting shock is felt, perform the learning operation again.
If reducing of shifting shock is not felt, recheck that other parts are normal.
LIST
| DTC | Item | Content of Diagnosis | Reference target |
|---|---|---|---|
| P0705 | Transmission Range Sensor Circuit (PRNDL Input) | Inhibitor switch malfunction, open or short circuit | Ref. to DTC P0705 TRANSMISSION RANGE SENSOR CIRCUIT (PRNDL INPUT) , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0712 | Transmission Fluid Temperature Sensor Circuit Low Input | ATF temperature sensor 1 malfunction, or open input signal circuit | Ref. to DTC P0712 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT LOW INPUT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0713 | Transmission Fluid Temperature Sensor Circuit High Input | ATF temperature sensor 1 malfunction, short input signal circuit | Ref. to DTC P0713 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT HIGH INPUT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0715 | Input/Turbine Speed Sensor Circuit | Turbine speed sensor 1 malfunction, short input signal circuit | Ref. to DTC P0715 INPUT/TURBINE SPEED SENSOR CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0719 | Brake Switch Circuit Low | Brake switch malfunction, open input signal circuit, body integrated unit malfunction, CAN communication failure | Ref. to DTC P0719 BRAKE SWITCH CIRCUIT LOW , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0720 | Output Speed Sensor Circuit | Front wheel speed sensor is faulty or input signal circuit, ground, power supply is open or shorted. | Ref. to DTC P0720 OUTPUT SPEED SENSOR CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0724 | Brake Switch Circuit High | Brake switch malfunction, short circuit of input signal, body integrated unit, CAN communication failure | Ref. to DTC P0724 BRAKE SWITCH CIRCUIT HIGH , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0731 | Gear 1 Incorrect Ratio | Vehicle sensor, turbine speed sensor, control valve malfunction or shift clutch malfunction | Ref. to DTC P0731 GEAR 1 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0732 | Gear 2 Incorrect Ratio | Vehicle sensor, turbine speed sensor, control valve malfunction or shift clutch malfunction | Ref. to DTC P0732 GEAR 2 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0733 | Gear 3 Incorrect Ratio | Vehicle sensor, turbine speed sensor or shift clutch malfunction | Ref. to DTC P0733 GEAR 3 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0734 | Gear 4 Incorrect Ratio | Vehicle sensor, turbine speed sensor or shift clutch malfunction | Ref. to DTC P0734 GEAR 4 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0735 | Gear 5 Incorrect Ratio | Vehicle sensor, turbine speed sensor or shift clutch malfunction | Ref. to DTC P0735 GEAR 5 INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0736 | Reverse Incorrect Ratio | Vehicle sensor, turbine speed sensor or shift clutch malfunction | Ref. to DTC P0736 REVERSE INCORRECT RATIO , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0741 | Torque Converter Clutch Circuit Performance or Stuck Off | Lock-up clutch is faulty or valve is stuck. | Ref. to DTC P0741 TORQUE CONVERTER CLUTCH CIRCUIT PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0743 | Torque Converter Clutch Circuit Electrical | L/U solenoid circuit malfunction or L/U solenoid body malfunction | Ref. to DTC P0743 TORQUE CONVERTER CLUTCH CIRCUIT ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0748 | Pressure Control Solenoid "A" Electrical | Line pressure solenoid circuit malfunction or line pressure solenoid body malfunction | Ref. to DTC P0748 PRESSURE CONTROL SOLENOID "A" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0751 | Shift Solenoid "A" Performance or Stuck Off | Fr/B Solenoid Function Malfunction | Ref. to DTC P0751 SHIFT SOLENOID "A" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0753 | Shift Solenoid "A" Electrical | Fr/B solenoid circuit malfunction or Fr/B solenoid body malfunction | Ref. to DTC P0753 SHIFT SOLENOID "A" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0756 | Shift Solenoid "B" Performance or Stuck Off | Shift Solenoid "B" Performance malfunction | Ref. to DTC P0756 SHIFT SOLENOID "B" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0758 | Shift Solenoid "B" Electrical | I/C solenoid circuit malfunction or I/C solenoid body malfunction | Ref. to DTC P0758 SHIFT SOLENOID "B" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0761 | Shift Solenoid "C" Performance or Stuck Off | H&LR/C solenoid malfunction | Ref. to DTC P0761 SHIFT SOLENOID "C" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0763 | Shift Solenoid "C" Electrical | H&LR/C solenoid circuit malfunction or H&LR/C solenoid body malfunction | Ref. to DTC P0763 SHIFT SOLENOID "C" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0766 | Shift Solenoid "D" Performance or Stuck Off | D/C solenoid malfunction | Ref. to DTC P0766 SHIFT SOLENOID "D" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0768 | Shift Solenoid "D" Electrical | D/C solenoid circuit malfunction or D/C solenoid body malfunction | Ref. to DTC P0768 SHIFT SOLENOID "D" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0771 | Shift Solenoid "E" Performance or Stuck Off | Fwd/B solenoid malfunction | Ref. to DTC P0771 SHIFT SOLENOID "E" PERFORMANCE OR STUCK OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0773 | Shift Solenoid "E" Electrical | Fwd/B solenoid circuit malfunction or Fwd/B solenoid body malfunction | Ref. to DTC P0773 SHIFT SOLENOID "E" ELECTRICAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0801 | Reverse Inhibit Control Circuit | Shift lock solenoid is faulty or output signal circuit is open or shorted. Blown out of TCM+B fuse | Ref. to DTC P0801 REVERSE INHIBIT CONTROL CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0817 | Starter Disable Circuit | PN signal output circuit is open or shorted. ECM Source Voltage Is Abnormal Blown out of TCM+B fuse | Ref. to DTC P0817 STARTER DISABLE CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0957 | Backup Light Relay Circuit Low | Back-up relay output circuit is open, shorted or relay OFF malfunction | Ref. to DTC P0957 BACKUP LIGHT RELAY CIRCUIT LOW , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P0958 | Backup Light Relay Circuit High | Back-up relay output circuit is open, shorted or relay ON malfunction | Ref. to DTC P0958 BACKUP LIGHT RELAY CIRCUIT HIGH , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1706 | AT Vehicle Speed Sensor Circuit Malfunction (Rear Wheel) | Rear wheel speed sensor is faulty or input circuit, ground, power supply is open or shorted. | Ref. to DTC P1706 AT VEHICLE SPEED SENSOR CIRCUIT MALFUNCTION (REAR WHEEL) , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1707 | AT AWD Solenoid Valve Circuit Malfunction | AWD solenoid circuit malfunction or AWD solenoid body malfunction | Ref. to DTC P1707 AT AWD SOLENOID VALVE CIRCUIT MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1710 | Torque Converter Turbine 2 Speed Signal Circuit 2 Malfunction | Torque converter sensor 2 malfunction, input circuit, ground, power open, short circuit | Ref. to DTC P1710 TORQUE CONVERTER TURBINE 2 SPEED SIGNAL CIRCUIT 2 MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1718 | AT CAN Communication Circuit | CAN communication line bus off is open, ECM short circuit, ABS/VDCCM, integrated CU malfunction | Ref. to DTC P1718 AT CAN COMMUNICATION CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1817 | SPORT Mode Switch Circuit (Manual Switch) | Manual mode switch is open or shorted, or switch malfunction | Ref. to DTC P1817 SPORT MODE SWITCH CIRCUIT (MANUAL SWITCH) , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1840 | Transmission Fluid Pressure Sensor/Switch A Circuit | Fr/B oil pressure switch is open or shorted, or switch malfunction | Ref. to DTC P1840 TRANSMISSION FLUID PRESSURE SENSOR/SWITCH A CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1841 | Transmission Fluid Pressure Sensor/Switch B Circuit | Fwd/B oil pressure switch is open or shorted, or switch malfunction | Ref. to DTC P1841 TRANSMISSION FLUID PRESSURE SENSOR/SWITCH B CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1842 | Transmission Fluid Pressure Sensor/Switch C Circuit | I/C oil pressure switch is open or shorted, or switch malfunction. | Ref. to DTC P1842 TRANSMISSION FLUID PRESSURE SENSOR/SWITCH C CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1843 | Transmission Fluid Pressure Sensor/Switch D Circuit | D/C oil pressure switch is open or shorted, or switch malfunction. | Ref. to DTC P1843 TRANSMISSION FLUID PRESSURE SENSOR/SWITCH D CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
| P1844 | Transmission Fluid Pressure Sensor/Switch E Circuit | H&LR/C oil pressure switch is open or shorted, or switch malfunction. | Ref. to DTC P1844 TRANSMISSION FLUID PRESSURE SENSOR/SWITCH E CIRCUIT , Diagnostic Procedure with Diagnostic Trouble Code (DTC). |
DIAGNOSTIC TROUBLE CODE
