POWER MIRROR SWITCH

Pry mirror switch from instrument panel using a small screwdriver. Disconnect switch connector. Check continuity between specified terminals of switch connector with switch button in specified position. (Scheme 4), (Scheme 5) or (Scheme 6). Also, refer to the appropriate POWER MIRROR SWITCH CONTINUITY SPECIFICATIONS. Replace switch if continuity is not as specified.

POWER MIRROR MOTOR

Remove door panel. Disconnect mirror motor connector. Using 12-volt power supply and 2 jumper wires, apply voltage to specified terminal and ground specified terminal. See POWER MIRROR MOTOR TEST. (Scheme 1), (Scheme 2) or (Scheme 3).

MovementTerminal No. (+)Terminal No. (-)
Impreza
Up13
Down31
Left12
Right21
Legacy
Up13
Down31
Left23
Right32
SVX
Up42
Down24
Left12
Right21

POWER MIRROR MOTOR TEST

Scheme 1

Scheme 1

Scheme 2

Scheme 2

Scheme 3

Scheme 3

IMPREZA

Switch PositionTerminal Nos.
Left Mirror
Up4 & 7, 2 & 1
Down2 & 7, 4 & 1
Left4 & 9, 2 & 1
Right2 & 9, 4 & 1
Right Mirror
Up4 & 6, 2 & 1
Down2 & 6, 4 & 1
Left4 & 8, 2 & 1
Right2 & 8, 4 & 1

IMPREZA POWER MIRROR SWITCH CONTINUITY TEST

LEGACY

Switch PositionTerminal Nos.
Left Mirror
Up4 & 7, 10 & 11
Down4 & 10, 7 & 11
Left2 & 4, 10 & 11
Right4 & 10, 2 & 11
Right Mirror
Up4 & 6, 10 & 11
Down4 & 10, 6 & 11
Left1 & 4, 10 & 11
Right4 & 10, 1 & 11

LEGACY POWER MIRROR SWITCH CONTINUITY TEST

SVX

Switch PositionTerminal Nos.
Left Mirror
Up4 & 10, 11 & 1
Down4 & 1, 11 & 10
Left4 & 10, 11 & 6
Right11 & 10, 4 & 6
Right Mirror
Up4 & 10, 11 & 9
Down4 & 9, 11 & 10
Left4 & 10, 11 & 8
Right4 & 8, 11 & 10

SVX POWER MIRROR SWITCH CONTINUITY TEST

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6
