Servicing - A/t: Other Subaru SVX I

Automatic Trans 2 illustrations ~372 words

Transaxle

  1. Warm engine to normal operating temperature. Park vehicle on level floor. Engage transaxle in all gear positions.
  2. Set transmission selector lever in Park with engine idling. Remove dipstick and clean with lint-free cloth. Check fluid level. Fluid level should be between upper and lower marks on dipstick. Add fluid if necessary. DO NOT overfill.

Differential

Use dipstick marked DIFF OIL on top of differential to check fluid level. Level should be between "L" and "F" marks. Add fluid if necessary.

Dexron-II ATF.

API GL-5.

  1. Remove drain plug. If cleaning oil screen, remove oil pan. Install NEW gaskets when reassembling. Tighten all bolts to specification. See the «TORQUE SPECIFICATIONS»(ref-56434-S08492975902001032600000) table.
  2. Fill transmission with fluid. Start and warm engine to normal operating temperature. Check fluid level with engine idling. Add fluid as necessary. DO NOT overfill.

Differential has separate drain plug. Remove differential drain plug to drain fluid.

BAND

Band adjustment screw is located on left side of transmission housing. Hold band adjustment screw, and loosen lock nut. Tighten adjustment screw to 80 INCH lbs. (9 N.m), and back screw off exactly 3 turns. Hold adjustment screw, and tighten lock nut to 18-21 ft. lbs. (25-28 N.m).

KICKDOWN SWITCH & DOWNSHIFT SOLENOID

  1. With ignition on, press accelerator pedal to stop. A click should be heard just as accelerator bottoms. If adjustment is necessary, loosen adjustment nut and adjust switch position for proper operation. Tighten nut.
  2. If kickdown failure occurs infrequently, solenoid may be malfunctioning because of contamination. Remove and clean inside of solenoid while moving push rod. After cleaning, carefully check solenoid operation. Install with NEW "O" ring.

NEUTRAL SAFETY SWITCH

  1. Loosen neutral safety switch mounting screws. Move gear selector lever to Neutral.
  2. Insert Stopper Pin (499267300) as vertically as possible into holes in neutral safety switch lever and switch body. (Scheme 76) Tighten mounting bolts and recheck adjustment.

Scheme 76

Scheme 76

SHIFT LINKAGE

  1. Adjust shift cable at lower end of selector lever. Set selector lever in Neutral. Loosen lock nuts on both sides of inner cable. (Scheme 77)
  2. Lightly push selector lever away from lock nut "B". Tighten lock nut "A" until it contacts selector lever trunnion. Tighten lock nut "B" to 80-151 INCH lbs. (9-17 N.m).

Scheme 77

Scheme 77
