Starting/charging — Starting circuit, w/ push button start Subaru Outback BT facelift
All systems — 35 systems
- Active bodyworks
- Air conditioning
- Anti-lock brakes
- Anti-theft 3
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering
- Engine performance 2.4l turbo
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 9
- Power distribution
- Power door locks 2
- Power mirrors 4
- Power seats 6
- Power top/sunroof
- Power windows 2
- Radio 3
- Shift interlock 2
- Starting/charging 3
- Supplemental restraints
- Transmission 2.4l turbo
- Transmission 2.5l
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 28
Click a component to highlight it on every diagram it appears on.
