Wiring Diagrams for Subaru Outback BT facelift (2022-2024)

Active bodyworks circuit

Automatic a/c circuit

Anti-lock brakes circuit

Forced entry circuit, w/ keyless access system Forced entry circuit, w/o keyless access system Immobilizer circuit

Body control modules circuit

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Mirror heater & rear defogger circuit Wiper deicer circuit

Electronic power steering circuit

Wiring diagram engine performance 2.4l turbo

Wiring diagram engine performance 2.5l

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit

Headlamps circuit Headlamps leveling circuit

Horn circuit

Instrument cluster circuit

Courtesy lamps circuit Instrument illumination circuit

Memory mirrors circuit Memory seat circuit

Driver monitoring circuit Eyesight circuit Front view camera circuit Navigation circuit, w/ audio amplifier Navigation circuit, w/o audio amplifier & telematics Navigation circuit, w/o audio amplifier w/ telematics Rear vehicle detection circuit Rear view camera circuit Reverse automatic braking system circuit

Power distribution circuit

Power door locks circuit, w/ keyless access system Power door locks circuit, w/o keyless access system

Automatic day/night mirror circuit, w/o smart rear view camera & automatic anti-glare Automatic day/night mirror circuit, w/o smart rear view camera w/ automatic anti-glare Automatic day/night mirror circuit, w/ smart rear view camera Power mirror circuit

Driver power seat circuit Front heated seats circuit, w/o seat ventilation Front heated seats circuit, w/ seat ventilation Heated steering wheel circuit Passenger power seat circuit Rear heated seats circuit

Power top/sunroof circuit

Power windows circuit, w/ all seat auto function Power windows circuit, w/ front seat auto function

Radio circuit, w/ audio amplifier Radio circuit, w/o audio amplifier & telematics Radio circuit, w/o audio amplifier w/ telematics

Park brake release circuit Shift interlock circuit

Charging circuit Starting circuit, w/o push button start Starting circuit, w/ push button start

Supplemental restraints circuit

2.4l turbo, transmission circuit

2.5l, transmission circuit

Power door closer circuit Trunk/tailgate release circuit

Chime circuit Tire pressure monitoring circuit

Front wiper/washer circuit Rear wiper/washer circuit

ANTI-LOCK BRAKES SYSTEM AUDIO AMPLIFIER CAN TRANSCEIVER I/F TRANSCEIVER IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LEFT HORN LOCK SW LOCK-UP DUTY RIGHT HORN W/ AUDIO AMPLIFIER W/O AUDIO AMPLIFIER

(RIGHT SIDE OF ENGINE AIR MIX DOOR ACTUATOR BLOWER MOTOR CLOSE MOTOR ENGINE CONTROLS SYSTEM ENGINE CONTROLS, ANTI-THEFT SYSTEMS ENGINE COOLANT TEMP. GAUGE FRONT WIPER MOTOR FUEL LID LOCK ACTUATOR INTAKE DOOR ACTUATOR LEFT AIR MIX DOOR ACTUATOR LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT POWER WINDOW MOTOR LEFT REAR DOOR LOCK ACTUATOR LEFT REAR POWER WINDOW MOTOR LEFT TUMBLE GENERATOR VALVE ACTUATOR LEVEL ACTUATOR LIFTER MOTOR LIFTER MOTOR SLIDE MOTOR LOWER RIGHT FRONT OF ENGINE) LUMBAR MOTOR MAIN FAN MOTOR MODE DOOR ACTUATOR OPEN MOTOR REAR WIPER MOTOR RECLINING MOTOR RIGHT AIR MIX DOOR ACTUATOR RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT POWER WINDOW MOTOR RIGHT REAR DOOR LOCK ACTUATOR RIGHT REAR POWER WINDOW MOTOR RIGHT TUMBLE GENERATOR VALVE ACTUATOR SLIDE MOTOR SLIDE MOTOR LIFTER MOTOR SRH ACTUATOR SRH ACTUATOR CONTROLLER STARTER MOTOR STARTER MOTOR SHIELD SUB FAN MOTOR TILT MOTOR WASHER MOTOR

CENTER KEYLESS ACCESS INTERIOR ANTENNA FRONT KEYLESS ACCESS INTERIOR ANTENNA GPS ANTENNA IMMOBILIZER ANTENNA REAR KEYLESS ACCESS EXTERIOR ANTENNA REAR KEYLESS ACCESS INTERIOR ANTENNA SATELLITE ANTENNA TEL SUB ANTENNA TELEMATICS ANTENNA

BUTTON RS BUTTON SOS POWER REAR GATE LOCK BUTTON PUSH BUTTON IGNITION SWITCH REAR GATE OPENER BUTTON REAR GATE OPENER BUTTON, REAR LOCK BUTTON REAR GATE OPENER, LOCK BUTTON TELEMATICS BUTTON TRUNK OPENER BUTTON VIEW BUTTON

FRONT VIEW MONITOR CAMERA REAR VIEW CAMERA SMART REAR VIEW CAMERA STEREO CAMERA WIDE ANGLE MONO CAMERA

DATA LINK CONNECTOR FRONT ACCESSORY POWER SUPPLY SOCKET ROLL CONNECTOR

A/C CONTROL MODULE AIR BAG CONTROL MODULE AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE BSTR CONTROL MODULE CAMERA CONTROL MODULE CAMERA CONTROL MODULE SHIELD CENTRAL GATEWAY CONTROL MODULE COCKPIT CONTROL MODULE FRONT RELAY CONTROL MODULE FUEL PUMP CONTROL MODULE FUEL PUMP CONTROL MODULE SHIELD IMMOBILIZER CONTROL MODULE KEYLESS ACCESS CONTROL MODULE KEYLESS ENTRY CONTROL MODULE LEFT OUTER MIRROR CONTROL MODULE POWER REAR GATE CONTROL MODULE POWER STEERING CONTROL MODULE RAB CONTROL MODULE REAR SEAT HEATER CONTROL MODULE RIGHT OUTER MIRROR CONTROL MODULE SEAT POSITION MEMORY CONTROL MODULE SEAT VENTILATION CONTROL MODULE STEERING CONTROL MODULE STEERING LOCK CONTROL MODULE TIRE PRESSURE MONITORING SYSTEM CONTROL MODULE TPMS CONTROL MODULE TPMS, KEYLESS ENTRY CONTROL MODULE VDC CONTROL MODULE W/ FUEL PUMP CONTROL MODULE W/ IMMOBILIZER CONTROL MODULE W/O FUEL PUMP CONTROL MODULE W/O IMMOBILIZER CONTROL MODULE

BODY INTEGRATED UNIT COCKPIT CONTROL UNIT CONTROL UNIT) DOOR LOCK BACKUP UNIT DRIVER MONITORING UNIT DRIVING UNIT POWER REAR GATE DRIVE UNIT SUNROOF UNIT

DELIVERY MODE FUSE 42 FUSE 1 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 6 FUSE 22 FUSE 7 FUSE 8 FUSE 9 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 30 FUSE 30 FUSE 26 FUSE 31 FUSE 32 FUSE 33 FUSE 34 FUSE 35 FUSE 36 FUSE 37 FUSE 38 FUSE 39 FUSE 40 FUSE 41 FUSE HOLDER MAIN SBF FUSE SBF 10 FUSE SBF 12 FUSE SBF FUSE SBF-1 FUSE SBF-2 FUSE SBF-3 FUSE SBF-4 FUSE SBF-5 FUSE SBF-6 FUSE SBF-7 FUSE SBF-8 FUSE SBF-9 FUSE SBF-11 FUSE TERMINAL MAIN FUSE

FB HEATER FC HEATER LEFT FRONT SEAT HEATER LEFT RC HEATER MAIN PTC HEATER MIRROR HEATER RIGHT FRONT SEAT HEATER RIGHT RC HEATER

INDICATOR NEEDLE ILLUMINATION LIGHT SHIFT POSITION INDICATOR

HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS INTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM LEFT VANITY MIRROR LAMP RIGHT VANITY MIRROR LAMP TRUNK, TAILGATE, FUEL DOORS, EXTERIOR LIGHTS SYSTEMS

ELECTRIC FLUID PUMP FUEL PUMP FUEL PUMP ASSEMBLY HIGH PRESSURE FUEL PUMP OIL PUMP ON/ PUMP H PUMP L VACUUM PUMP

ACCESSORY RELAY ACCESSORY RELAY 1 ACCESSORY RELAY 2 BLOWER MOTOR RELAY DAYTIME RUNNING LIGHT RELAY ELECTRIC FLUID PUMP RELAY ELECTRIC THROTTLE CONTROL RELAY ELECTRONIC THROTTLE CONTROL RELAY FRONT FOG LIGHT RELAY FRONT LOCK RELAY FRONT UNLOCK RELAY FUEL PUMP RELAY HEATER RELAY HORN RELAY HOT W/ ACCESSORY RELAY 2 ENERGIZED HOT W/ ACCESSORY RELAY-1 ENERGIZED HOT W/ IG 1 RELAY ENERGIZED HOT W/ IG 1 RELAY RELAY ENERGIZED HOT W/ IG 2 RELAY ENERGIZED HOT W/ MAIN RELAY ENERGIZED HOT W/ MB-IG RELAY ENERGIZED HOT W/ MB-IG RELAY ENERGIZED ENERGIZED ICR RELAY ICR RELAY SHIELD IG 1 RELAY IG 1 RELAY ENERGIZED IG 2 RELAY MAIN FAN RELAY MAIN FAN RELAY 1 MAIN FAN RELAY 2 MAIN RELAY MB-IG RELAY MIRROR HEATER RELAY POWER WINDOW RELAY PTC HEATER RELAY A PTC HEATER RELAY B PTC HEATER RELAY C REAR DEFOGGER RELAY REAR GATE UNLOCK RELAY REAR GATE/ TRUNK UNLOCK RELAY REAR WIPER RELAY RELAY ENERGIZED STARTER CUT RELAY STARTER RELAY STOP LIGHT RELAY SUB FAN RELAY WIPER DEICER RELAY

ACCELERATOR PEDAL POSITION SENSOR AMBIENT SENSOR AUTO LIGHT SENSOR BATTERY SENSOR CRANKSHAFT POSITION SENSOR DIAGNOSIS CPC PRESSURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR INLET ENGINE COOLANT TEMPERATURE SENSOR OUTLET ENGINE OIL TEMPERATURE SENSOR EVAPORATOR SENSOR FLOW SENSOR FRONT WHEEL SPEED SENSOR FUEL LEVEL SENSOR FUEL PRESSURE SENSOR FUEL SUB LEVEL SENSOR HANDS FREE SENSOR HANDSFREE SENSOR HEATER CORE SENSOR IN-VEHICLE SENSOR LEFT CORNER SONAR SENSOR LEFT EXHAUST CAMSHAFT POSITION SENSOR LEFT FRONT ABS WHEEL SPEED SENSOR LEFT FRONT IMPACT SENSOR LEFT FRONT LOAD SENSOR 1 LEFT INNER SONAR SENSOR LEFT INTAKE CAMSHAFT POSITION SENSOR LEFT KNOCK SENSOR LEFT POWER REAR GATE TOUCH SENSOR LEFT REAR ABS WHEEL SPEED SENSOR LEFT REAR LOAD SENSOR 3 LEFT SEAT POSITION SENSOR LINE PRESSURE SENSOR MANIFOLD ABSOLUTE PRESSURE SENSOR MANIFOLD ABSOLUTE PRESSURE, INTAKE AIR TEMPERATURE SENSOR MASS AIR FLOW/ INTAKE AIR TEMPERATURE SENSOR PEDAL TRAVEL SENSOR PRESSURE SENSOR PRESSURE SENSOR LEAK CHECK VALVE ASSEMBLY PRIMARY SPEED SENSOR REAR OXYGEN SENSOR RIGHT CORNER SONAR SENSOR RIGHT EXHAUST CAMSHAFT POSITION SENSOR RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT FRONT IMPACT SENSOR RIGHT FRONT LOAD SENSOR 2 RIGHT INNER SONAR SENSOR RIGHT INTAKE CAMSHAFT POSITION SENSOR RIGHT KNOCK SENSOR RIGHT POWER REAR GATE TOUCH SENSOR RIGHT REAR ABS WHEEL SPEED SENSOR RIGHT REAR LOAD SENSOR 4 RIGHT SEAT POSITION SENSOR SECONDARY PRESSURE SENSOR SECONDARY SPEED SENSOR STEERING ANGLE SENSOR SUNLOAD SENSOR TEMPERATURE/ HUMIDITY SENSOR TORQUE SENSOR TURBINE SPEED SENSOR WASHER FLUID LEVEL SENSOR

LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER SPEAKER DRIVE CIRCUIT

AUTO SWITCH BRAKE FLUID LEVEL SWITCH BRIGHT SWITCH CHANGE OVER SWITCH COMBINATION SWITCH CRUISE MAIN SWITCH DIMMER, PASSING SWITCH DISTANCE SWITCH EPB CONTROL SWITCH FOG LIGHT SWITCH FRONT POWER WINDOW SUB SWITCH FRONT WASHER SWITCH FRONT WIPER SWITCH FULL LATCH SWITCH HANDSFREE OFF SWITCH HAZARD SWITCH HOOD SWITCH HORN SWITCH IGNITION SWITCH ILLUMINATION CONTROL SWITCH INHIBITOR SWITCH KEY WARNING SWITCH LANE CENTERING SWITCH LEFT FRONT DOOR SWITCH LEFT FRONT SEAT BELT SWITCH LEFT POWER SEAT SWITCH LEFT REAR DOOR SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT BELT SWITCH LEFT REAR SEAT HEATER SWITCH LEFT REAR SEATING SWITCH LEFT SATELLITE SWITCH LEFT SATELLITE SWITCH ILLUMINATION LIGHT LEFT SEAT BELT SWITCH LIFTER SWITCH LIGHTING SWITCH LUMBAR SWITCH MANUAL MODE SWITCH OIL LEVEL SWITCH OIL PRESSURE SWITCH P RANGE SWITCH PADDLE SHIFT SWITCH PASSENGERS DOOR LOCK SWITCH POWER REAR GATE DRIVER'S SWITCH POWER REAR GATE INNER SWITCH POWER WINDOW LOCK SWITCH POWER WINDOW MAIN SWITCH POWER WINDOW SWITCH CONTROLLER REAR GATE LOCK ACTUATOR, LATCH SWITCH REAR SEAT BELT SWITCH CENTER REAR WIPER/ WASHER SWITCH RECLINING SWITCH REMOTE CONTROL MIRROR SWITCH REMOTE CONTROL SWITCH RES/+ SWITCH RIGHT BUCKLE SWITCH RIGHT FRONT DOOR SWITCH RIGHT POWER SEAT SWITCH RIGHT REAR DOOR SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SEAT BELT SWITCH RIGHT REAR SEAT HEATER SWITCH RIGHT REAR SEATING SWITCH RIGHT SATELLITE SWITCH RIGHT SATELLITE SWITCH ILLUMINATION LIGHT SEAT POSITION MEMORY SWITCH SET SWITCH SLIDE SWITCH STEERING HEATER SWITCH STEERING HEATER SWITCH ILLUMINATION LIGHT STOP LIGHT, BRAKE SWITCH SWITCH ILLUMINATION LIGHT TILT SWITCH TRIP SWITCH TRUNK LID LOCK ACTUATOR, SWITCH TRUNK LID OPENER SWITCH TURN SIGNAL SWITCH

AWD SOLENOID COMPRESSOR SOLENOID EGR CONTROL VALVE ELCM VALVE ELECTRIC AIR BYPASS VALVE ELECTRIC WASTE GATE VALVE KEY LOCK SOLENOID LEAK CHECK VALVE ASSEMBLY LEFT EXHAUST OIL CONTROL SOLENOID LEFT INTAKE OIL CONTROL SOLENOID OFF SOLENOID PURGE CONTROL SOLENOID VALVE RIGHT EXHAUST OIL CONTROL SOLENOID RIGHT INTAKE OIL CONTROL SOLENOID SHIFT LOCK SOLENOID SWITCHING VALVE THERMO CONTROL VALVE ASSEMBLY TRANSMISSION CONTROL VALVE BODY

(OR RED/ WIRE +B BACKUP PNK FR- WIRE AVCCCRA PNK WIRE BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU (OR WHT/ WIRE BLU WIRE BLU) RED/GRN WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE F WIP HI PNK F WIP LO WIRE FL- PNK FR+ WIRE GREEN IND GREEN/YELLOW LED DIMMING CIRCUIT GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE KEY IN/ACC SW PNK P SW WIRE LED GREEN LED RED WIRE LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/BLU WIRE LT GRN/RED WIRE NCA WIRE ORG/ BLU WIRE ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE PNK +B WIRE PNK DEICER WIRE PNK PNK WIRE PNK VCC WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE RED LH WIRE RED RH WIRE RED WIRE RED/ BLK WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE REV PNK STRG SW 1+ WIRE RUN WIRE TAN WIRE VIO WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WF+ PNK TWR+ WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE YELLOW LH YELLOW RH YELLOW)

2.5L (IF (OR (RIGHT SIDE OF TRANSMISSION +B BACKUP +B DIRECT +BB A/S CAN-H A/S CAN-L A/S CAN-L PRI CAN-L ABS IND. ACTIVE GRILLE SHUTTER AFR- AIR BAG AIR BAG IND AIR CONDITIONER AMP MUTE ANT B+ ANTI-THEFT SYSTEM ASS SW ATF TEMPERATURE AUDIO CASE GROUND AUTO UP AUX D- AUX D- SHIELD AUX DET AUX L + AUX R + AVCSEL+ AVCSER+ AVCSL+ AVCSR+ AVH ON/ACT IND AWD DUTY SOL AWD LIN SOL B-CAN H B-CAN H B-CAN L B-CAN L B/U PWR BACKUP LIGHT BAT (S LK/ BAT SIG BATT +BB BER- BER- DSR+ BLOWBY DIAGNOSIS BRAKE MASTER CYLINDER) BSM ICON BSTR ECM BSTR MODULE CONTROL BT DATA BUZ RTN BW FW BW UP C-CAN HIGH C-CAN LOW CAM GND CAM L CAM R CAN 2 H CAN 2-L CAN DRIVE CAN DRIVER CAN I/F DRIVER I/F CAN L CAN L SHIELD AUX GND CAN-H CAN-H- CAN-L- CD DECK CD/DVD DECK CENTER INFORMATION DISPLAY CENTER TWEETER CHARGE IND CHARGING CIRCUIT CID DATA+ CKP GND CLOSE LATCH CLOSE OPEN COMBINATION METER COMPUTER DATA LINES SYSTEM CONTROL CIRCUIT COOL SIG COOLING FANS SYSTEM COURTESY FULL SW CPC PRES CRUISE CONTROL SYSTEM CRUISE MAIN CSL- CSR- CTR + CUTRM ST RLY DIAG CUTRM ST RLY DIAG ST CT RLY D RNG SW DATA COMMUNICATION MODULE DC/DC CONVERTER 1 DC/DC CONVERTER 2 DCM D- DCM GND DCM LC CAN H DCM LC CAN L DCM MUTE DCM VBUS DECK D+ DECK GND DECK VBUS DEFOGGER SYSTEM DIAG CAN H DIAG CAN L DIAL PLATE ILLUMI LIGHT IND DIAL PLATE ILLUMINATION LIGHT DIM H SW DK+ DN LH DN SW DOOR LOCKS DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DOOR LOCKS, HEADLIGHTS SYSTEMS DOOR LOCKS, HEADLIGHTS, POWER DISTRIBUTION SYSTEMS DOOR LOCKS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DOWN UP DRIVE CIRCUIT DRIVE CIRCUIT LIGHT CONTROL DRIVER CIRCUIT DRIVER'S DRIVER'S KNEE AIR BAG MODULE DRIVER'S SEAT BELT IND DRV FAN E/C CAN-H E/C CAN-H T E/C CAN-L E/C CAN-L T EL ABV EL W/G DC- EL W/G SEN ELCM PMP ELCM PRES ELECTRONIC THROTTLE CONTROL EOP COM EOP OPE EOP RLY EPB ON IND EXCEPT OUTBACK WILDERNESS EXT INT- EXT L- EXT-R- EYESIGHT ASSIST MONITOR F FOG F PR F WASH F WASH SW F WIP HI SW F WIP L SW F WIP RTN F, R F/R LIN SOL FL TURN FLUID LEVEL FOG SW FPH+ FR CMR GND SHIELD RR CMR GND FR CMR PWR FR CMR V+ FR TURN FR WHL SPD SSR FRONT FOG LIGHT IND FT LH+ OUT FT LH- IN FT RH+ OUT FT RH- IN FUEL GAUGE FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL LID UL FUEL SENDER FUEL SENDER GND FULL LATCH FW DOWN GAP- GB-1 GB-2 GB-3 GB-4 GB-5 GE-1 GE-2 GG-1 GG-2 GLOVE BOX LIGHT GND 2 GND MR GPS DATA GPS RF GR (LOWER LEFT GT-1 GT-2 GT-3 GW 2 GW 3 H/L HI LH H/L HI RH H/L LO LH HALF LATCH HALL 1 HALL 2 HALL FEED HALL RTN HAZ SW HAZARD OUT HAZARD SHIFT HEADLIGHTS SYSTEM HF PRG HF PRG OFF SW HI-BEAM IND HIGH MOUNTED STOP LIGHT HL LO RH HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START HOT W/ I/F CAN DRIVER I/F I/F I/F ICL- ICR+ ID CODE BOX IGN GND IGN PWR IGN SW INJ 1 INJ 2 INJ 3 INJ 4 INSTRUMENT CLUSTER SYSTEM KEY ILLUMINATION KEY ILU L KEY LK KEY LK/TURN) KEY-IN/ACC SW KEYLESS BUZZER L-DIAG L/U DUTY SOL LANE DEPARTURE LANE DEPARTURE WARNING OFF IND LATCH HALF SW LED 2 LED DRIVER MODULE LEFT ADAPTIVE BELT LEFT CURTAIN AIR BAG MODULE LEFT DRIVER MODULE LEFT FB BLOWER LEFT FC BLOWER LEFT FRONT COMBINATION LIGHT LEFT FRONT DOOR STEP LIGHT LEFT FRONT FOG LIGHT LEFT FRONT SEAT BELT PRETENSIONER LEFT LAP BELT PRETENSIONER LEFT LICENSE PLATE LIGHT LEFT OUTER HANDLE LEFT OUTER MIRROR ASSEMBLY LEFT POWER SEAT LEFT REAR COMBINATION LIGHT LEFT REAR FINISHER LIGHT LEFT REAR SEAT BELT PRETENSIONER LEFT SIDE AIR BAG MODULE LEFT SIDE TWEETER LEFT TURN IND LEFT TURN SIG IND LEFT VANITY MIRROR LIGHT LEGACY, OUTBACK W/O WILDERNESS LEVEL IND LFT -SW LFT SEN LFT- LGT SSR LGT SW LGT SW 1 LIFT LICENSE PLATE LIGHT LIFTER PULSE LIGHT 2 LIGHT CONTROL LIGHTING IND LIN 1 LIN 2 LIN PRS LIN SOL LINE PRESSURE LINE PRS LIN SOL LINE PRS SSR GND LINE PRS SSR PWR LINE PRS SSR SIG LO HI LO HI OFF LO OFF LO AUTO LOW FUEL LOW FUEL LEVEL IND LSP + LTE RF LUGGAGE COMPT FLOOR) LUGGAGE ROOM LIGHT M LK SW M MODE SW M UL SW MAIN ANT MAIN PWR 1 MAIN PWR 2 MAIN PWR 3 MAL- MALFUNCTION IND MEMORY 1 MEMORY 2 METER DATA MIC GND OUT MIC SIG OUT MICRO COMPUTER MIST HI MR- N RNG SW NAVIGATION SYSTEM NEUT GND NEUT GND GND NOISE SUPPRESSION CAPACITOR NOISE SUPPRESSOR OFF AUTO OFF SW OIL PRESSURE IND OIL TEMP SSR GND OIL TEMP SSR SIG ON OFF ON+WASH ON+WASH WASH ONE STEP OP ON/OFF SOL OPEN LATCH OPEN SW OPN SW OUTBACK W/ WILDERNESS P RNG SW P-GNDDR P-GNDPA P-SW PARKING BRAKE/ BRAKE FLUID LEVEL IND PARKING BRAKE/BRAKE FLUID LEVEL IND PAS FAN PASS SW PASSENGER'S AIR BAG MODULE PAV+ PFL+ PFL- POCKET LIGHT POWER CIRCUIT POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION, HEADLIGHTS SYSTEMS POWER FOLDING POWER REAR GATE AUTO CLOSER POWER REAR GATE BUZZER POWER SUPPLY CIRCUIT POWER TOPS SYSTEM POWER TRANSISTOR POWER WINDOW CIRCUIT BREAKER POWER WINDOWS SYSTEM PRE-COLLISION BRAKE OFF IND PRESSURE IND PRG DSW PRI CAN H PRI CAN L PRI DN DUTY SOL PRI SPD SSR PRI UP DUTY SOL PRIMARY DOWN PRIMARY UP PRR- PTS GND PTS VS PW LIN R CAM DATA R CAM GND R CAM PWR R CAM SLD R DEF R RNG SW R WASH R WASH SW R WIP ON R WIP RTN R WIP SW R+ SHIELD SLD R-DIAG RAIN GND RAIN SIG RATCHET SW RCL -SW RCL SEN RCL- REAR DEFOGGER REAR FOG LIGHT IND REAR VIEW MIRROR) REARVIEW MIRROR) RECLINING PULSE RES+ RG INR SW RIGHT ADAPTIVE BELT RIGHT CURTAIN AIR BAG MODULE RIGHT DRIVER MODULE RIGHT FB BLOWER RIGHT FC BLOWER RIGHT FRONT COMBINATION LIGHT RIGHT FRONT DOOR STEP LIGHT RIGHT FRONT FOG LIGHT RIGHT FRONT SEAT BELT PRETENSIONER RIGHT LICENSE PLATE LIGHT RIGHT OUTER HANDLE RIGHT OUTER MIRROR ASSEMBLY RIGHT OUTER MIRROR CONTROL RIGHT POWER SEAT RIGHT REAR COMBINATION LIGHT RIGHT REAR FINISHER LIGHT RIGHT REAR SEAT BELT PRETENSIONER RIGHT SEAT CUSHION AIR BAG MODULE RIGHT SIDE AIR BAG MODULE RIGHT SIDE OF FRONT GRILLE) RIGHT SIDE OF RADIATOR) RIGHT SIDE TWEETER RIGHT TURN IND RIGHT TURN SIG IND RIGHT VANITY MIRROR LIGHT RL INDH RL INDL RL SW RL TURN RL- RRC- ROOM LIGHT RR CMR PWR RR CMR V- RR INDH RR INDL RR SW RR TURN RRC+ RSP+ S LK SCR IND SEAT BELT SEAT DR SEAT PA SEATS SYSTEM SEC PRS LIN SOL SEC PRS SSR GND SEC PRS SSR PWR SEC PRS SSR SIG SEC SPD SSR SECTOR SW SECURITY IND SEDAN WAGON SELECT LEVER SET- SFL- SFR- SHIELD R CAM GND SHIELD SLD 2 SHIFT INTERLOCK SYSTEM SIDE MARKER SIDE MARKER LIGHT SL- SLD -SW SLD SEN SLIDE PULSE SOL + SOUND SYSTEMS SPOT MAP LIGHT SR- SSL- SSR +B SSR+ ST CT RLY ST RLY ST SW STARTING CIRCUIT STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STAT COM STEERING COLUMN) STEERING IND STEERING WHEEL) STL SW STOP LIGHT STOP LIGHT CONDENSER STP SW STR SW STR+ STRG SW 2+ STRG SW GND SUB ANT SUPPLEMENTAL RESTRAINTS SYSTEM SUPPLY CIRCUIT/ SW 1 SW 2 SW 3 SW 4 TAIL LIGHT/STOP LIGHT TFT BACK TFT BACK LIGHT TFT DRIVE TFT DRIVE CIRCUIT TGVR POS THM- THROTTLE BODY ASSEMBLY TILT PULSE TIRE INFLATION TIRE INFLATION PRESSURE IND TLT -SW TLT SEN TOP OF TRANSMISSION) TRANSMISSIONS SYSTEM TRUNK ROOM LIGHT TRUNK, TAILGATE, FUEL DOORS SYSTEM TSW 5 TUR SPD SSR TUR SPD SSR FR WHL SPD SSR TURN L SW TURN LIGHT TURN R SW TURN SIGNAL LIGHT TW IN TW OUT TWL- TWR+ UP DRIVER'S SIDE UP LEFT REAR UP RH UP RIGHT REAR UP SW USB ACC USB D- USB GND USB VBUS VDC OFF VDC OFF IND VDC WARNING/ VDC OPERATION IND VVTCAM L VVTCAM R W/ BSD/ RCTA W/ BSD/RCTA W/ FRONT VIEW MONITOR W/ ID CODE BOX W/ KEYLESS ACCESS SYSTEM W/ L/R INDEPENDENT W/ L/R INDEPENDENT AIR CONDITIONER W/ MEMORY W/ MIRROR TURN W/ NAVIGATION W/ POWER FOLDING W/ POWER REAR GATE, OUTBACK W/ MEMORY SEDAN W/ MEMORY W/ RAB W/ SEAT VENTILATION W/ SUNROOF W/ TELEMATICS W/ TPMS W/ TURN MIRROR W/O CUSHION LENGTH ADJUSTER W/O FRONT VIEW MONITOR W/O ID CODE BOX W/O L/R INDEPENDENT W/O L/R INDEPENDENT AIR CONDITIONER W/O MEMORY W/O POWER REAR GATE, MEMORY W/O RAB W/O SEAT VENTILATION W/O SMART REARVIEW MIRROR W/O TPMS W/O TURN MIRROR WARNING OFF IND WARNING SYSTEMS WASH LEV WASHER FLUID RESERVOIR) WF- WIFI DATA WIPER DEICER WIPER/WASHER SYSTEM WIPER/WASHER, HEADLIGHTS SYSTEMS XM DATA
