Starting/charging — Starting circuit, w/ push button start Subaru Outback BS facelift
All systems — 36 systems
- Air conditioning 2.5l 2
- Air conditioning 3.6l
- Anti-lock brakes
- Anti-theft 3
- Body control modules
- Computer data lines
- Cooling fan 2.5l
- Cooling fan 3.6l
- Cruise control
- Defoggers 3
- Electronic power steering
- Engine performance 2.5l
- Engine performance 3.6l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems
- Navigation 7
- Power distribution
- Power door locks 2
- Power mirrors 5
- Power seats 4
- Power top/sunroof
- Power windows 2
- Radio 4
- Shift interlock 2
- Starting/charging 4
- Supplemental restraints
- Transmission 2.5l
- Transmission 3.6l
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 11
Click a component to highlight it on every diagram it appears on.
