Air Bag System (Diagnostics): Diagnosis Subaru Outback BS

INSPECTION

Measure the battery voltage and check electrolyte.

Standard voltage: 12 V

Specific gravity: 1.260 or more

DTC DETECTING CONDITION

Defective harness connector

TROUBLE SYMPTOM

Communication is impossible between the airbag control module and the Subaru Select Monitor.

Turn the ignition switch to ON, and confirm that the airbag warning light remains on for approx. 6 seconds then turns off afterwards.

Scheme 213

Airbag control module is faulty.

DIAGNOSTIC PROCEDURE

DTC B11E0 ROLLOVER IGNITION

This DTC is indicated when the curtain airbag module and the seat belt pretensioner are deployed.

Once this DTC is displayed, the memory cannot be cleared. Replace the following parts.

1. Airbag control module Refer to «AIRBAG CONTROL MODULE»(ref-646016-S33983969252014072500000) .
2. Curtain airbag module (operating side) Refer to «CURTAIN AIRBAG MODULE»(ref-646016-S42795853612014072500000) .
3. Curtain airbag sensor (operating side) Refer to «CURTAIN AIRBAG SENSOR»(ref-646016-S35772580132014072500000) .
4. Front outer seat belt with pretensioner (operating side) Refer to «FRONT SEAT BELT»(ref-646029-S16585988272014072500000) .

This DTC is indicated when the front airbag module and the pretensioner are deployed.

Once this DTC is displayed, the memory cannot be cleared. Therefore replace the following parts.

1. Airbag control module Refer to «AIRBAG CONTROL MODULE»(ref-646016-S33983969252014072500000) .
2. Driver's airbag module Refer to «DRIVER'S AIRBAG MODULE»(ref-646016-S07229533632014072500000) .
3. Passenger's airbag module Refer to «PASSENGER'S AIRBAG MODULE»(ref-646016-S39100263672014072500000) .
4. Front sub sensor of both sides. Refer to «FRONT SUB SENSOR»(ref-646016-S01579941592014072500000) .
5. Front outer seat belt with pretensioner of both sides. Refer to «FRONT SEAT BELT»(ref-646029-S16585988272014072500000) .
6. Steering roll connector Refer to «ROLL CONNECTOR»(ref-646016-S36415582332014072500000) .
7. Occupant detection system (passenger's seat cushion & frame assembly) Refer to «FRONT SEAT»(ref-646024-S31530492062014072500000) .
8. Curtain airbag module (operating side) Refer to «CURTAIN AIRBAG MODULE»(ref-646016-S42795853612014072500000) .

DTC B11F3 FRONT IMPACT IGNITION

Note. For details on DTC B11F3, refer to DTC B11F2 FRONT IMPACT IGNITION .

DTC B11F4 FRONT IMPACT IGNITION

Note. For details on DTC B11F4, refer to DTC B11F2 FRONT IMPACT IGNITION .

DTC B11F5 FRONT IMPACT IGNITION

Note. For details on DTC B11F5, refer to DTC B11F2 FRONT IMPACT IGNITION .

DTC B11F7 SIDE IMPACT IGNITION

This DTC is displayed when the side airbag module and curtain airbag module are deployed.

Once this DTC is displayed, the memory cannot be cleared. Replace the following parts.

1. Airbag control module Refer to «AIRBAG CONTROL MODULE»(ref-646016-S33983969252014072500000) .
2. Side airbag module (operating side) Refer to «SIDE AIRBAG MODULE»(ref-646016-S30337717972014072500000) .
3. Side airbag sensor (operating side) Refer to «SIDE AIRBAG SENSOR»(ref-646016-S40746042162014072500000) .
4. Curtain airbag module (operating side) Refer to «CURTAIN AIRBAG MODULE»(ref-646016-S42795853612014072500000) .
5. Curtain airbag sensor (operating side) Refer to «CURTAIN AIRBAG SENSOR»(ref-646016-S35772580132014072500000) .

DTC B11F8 SIDE IMPACT IGNITION

Note. For details on DTC B11F8. refer to DTC B11F7 SIDE IMPACT IGNITION .

DTC B11F9 SIDE IMPACT IGNITION

Note. For details on DTC B11F9, refer to DTC B11F7 SIDE IMPACT IGNITION .

DTC B11FA SIDE IMPACT IGNITION

Note. For details on DTC B11FA, refer to DTC B11F7 SIDE IMPACT IGNITION .

DTC B11FB SIDE IMPACT IGNITION

Note. For details on DTC B11FB, refer to DTC B11F7 SIDE IMPACT IGNITION .

DTC B11FC SIDE IMPACT IGNITION

Note. For details on DTC B11FC, refer to DTC B11F7 SIDE IMPACT IGNITION .

Front sub sensor (RH) is faulty.

If DTC B1610 is displayed, the circuit within the front sub sensor (RH) is faulty.

Replace the front sub sensor (RH). Refer to FRONT SUB SENSOR .

1. Open or short circuit in harness of front sensor bus (RH).
2. Front sub sensor (RH) is faulty.
3. Airbag control module is faulty.

Front sub sensor (LH) is faulty.

If DTC B1615 is displayed, the circuit within the front sub sensor (LH) is faulty.

Replace the front sub sensor (LH). Refer to FRONT SUB SENSOR .

1. Open or short circuit in harness of front sensor bus (LH).
2. Front sub sensor (LH) is faulty.
3. Airbag control module is faulty.

Front sub sensor (RH) is misinstalled.

DIAGNOSTIC PROCEDURE

Front sub sensor (LH) is misinstalled.

DIAGNOSTIC PROCEDURE

Side airbag sensor (RH) is faulty.

When DTC B1620 is displayed, the circuit within the side airbag sensor (RH) is faulty.

Replace the side airbag sensor (RH). Refer to SIDE AIRBAG SENSOR .

1. Open or short circuit in harness of side sensor bus (RH).
2. Side airbag sensor (RH) and curtain airbag sensor (RH) are faulty.
3. Airbag control module is faulty.

Side airbag sensor (LH) is faulty.

When DTC B1625 is displayed, the circuit within the side airbag sensor (LH) is faulty.

Replace the side airbag sensor (LH). Refer to SIDE AIRBAG SENSOR .

1. Open or short circuit in harness of side sensor bus (LH).
2. Side airbag sensor (LH) and curtain airbag sensor (LH) are faulty.
3. Airbag control module is faulty.

Curtain airbag sensor (RH) is faulty.

If DTC B1630 is displayed, the circuit within the curtain airbag sensor (RH) is faulty.

Replace the curtain airbag sensor (RH). Refer to CURTAIN AIRBAG SENSOR .

1. Open or short circuit in harness of side sensor bus (RH).
2. Side airbag sensor (RH) and curtain airbag sensor (RH) are faulty.
3. Airbag control module is faulty.

Curtain airbag sensor (LH) is faulty.

If DTC B1635 is displayed, the circuit within the curtain airbag sensor (LH) is faulty.

Replace the curtain airbag sensor (LH). Refer to CURTAIN AIRBAG SENSOR .

1. Open or short circuit in harness of side sensor bus (LH).
2. Side airbag sensor (LH) and curtain airbag sensor (LH) are faulty.
3. Airbag control module is faulty.

1. Open or short circuit in harness of side sensor bus (RH).
2. Side airbag sensor (RH) is faulty.
3. Curtain airbag sensor (RH) is faulty.
4. Front door impact sensor (RH) is faulty.
5. Airbag control module is faulty.

1. Open or short circuit in harness of side sensor bus (LH).
2. Side airbag sensor (LH) is faulty.
3. Curtain airbag sensor (LH) is faulty.
4. Front door impact sensor (LH) is faulty.
5. Airbag control module is faulty.

1. Side airbag sensor RH is misinstalled.
2. Airbag CM is faulty.

DIAGNOSTIC PROCEDURE

1. Side airbag sensor LH is misinstalled.
2. Airbag CM is faulty.

DIAGNOSTIC PROCEDURE

1. Curtain airbag sensor RH is misinstalled.
2. Airbag CM is faulty.

DIAGNOSTIC PROCEDURE

1. Curtain airbag sensor LH is misinstalled.
2. Airbag CM is faulty.

DIAGNOSTIC PROCEDURE

DTC B16EF ODS SYSTEM WRONG PARTS

Note. Refer to DTC B16EF ODS SYSTEM WRONG PARTS .

1. Passenger's airbag indicator is faulty.
2. Airbag control module is faulty.
3. Airbag main harness circuit is open or shorted.
4. Body harness circuit is open.

1. Front door impact sensor (RH) is misinstalled.
2. Airbag control module is faulty.

DIAGNOSTIC PROCEDURE

Front door impact sensor (RH) is faulty.

If DTC B1690 is displayed, the circuit within the front door impact sensor (RH) is faulty.

Replace the front door impact sensor (RH). Refer to REMOVAL .

1. Open or short circuit in harness of side sensor bus (RH).
2. Front door impact sensor (RH) is faulty.
3. Curtain airbag sensor (RH) is faulty.
4. Airbag control module is faulty.

1. Front door impact sensor (LH) is misinstalled.
2. Airbag control module is faulty.

DIAGNOSTIC PROCEDURE

Front door impact sensor (LH) is faulty.

If DTC AB is displayed, the circuit within the front door impact sensor (LH) is faulty.

Replace the front door impact sensor (LH). Refer to REMOVAL .

1. Open or short circuit in harness of side sensor bus (LH).
2. Front door impact sensor (LH) is faulty.
3. Curtain airbag sensor (LH) is faulty.
4. Airbag control module is faulty.

1. Harness between airbag control module and front sub sensor is open or shorted.
2. Front sub sensor is faulty.
3. Airbag control module is faulty.

1. Airbag control module is faulty.
2. Body integrated unit is faulty.
3. Harness circuits between body integrated unit and airbag control module are open, shorted or shorted to ground.

DTC B16F0 PASSENGER'S AIRBAG OFF INDICATOR FAILURE

Note. For details on DTC B16F0, refer to DTC B1660 PASSENGER'S AIRBAG ON INDICATOR FAILURE .

1. Airbag main harness circuit is shorted.
2. Airbag module harness (driver's side) circuit is shorted.
3. Roll connector circuit is shorted.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is open.
2. Airbag module harness (driver's side) circuit is open.
3. Roll connector is open.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to ground.
2. Airbag module harness (driver's side) circuit is shorted to ground.
3. Roll connector circuit is shorted to ground.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to power supply.
2. Airbag module harness (driver's side) circuit is shorted to power supply.
3. Roll connector circuit is shorted to power supply.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted.
2. Airbag module harness circuit (passenger's side) is shorted.
3. Roll connector circuit is shorted.
4. Passenger's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is open.
2. Airbag module harness (passenger's side) circuit is open.
3. Roll connector circuit is shorted.
4. Passenger's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to ground.
2. Airbag module harness (passenger's side) circuit is shorted to ground.
3. Passenger's airbag module is faulty.
4. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to power supply.
2. Airbag module harness (passenger's side) circuit is shorted to power supply.
3. Passenger's airbag module is faulty.
4. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted.
2. Airbag module harness (driver's side) circuit is shorted.
3. Roll connector circuit is shorted.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is open.
2. Airbag module harness (driver's side) circuit is open.
3. Roll connector circuit is open.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to ground.
2. Airbag module harness (driver's side) circuit is shorted to ground.
3. Roll connector circuit is shorted to ground.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to power supply.
2. Airbag module harness (driver's side) circuit is shorted to power supply.
3. Roll connector is shorted to power supply.
4. Driver's airbag module is faulty.
5. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted.
2. Airbag module harness (passenger's side) circuit is shorted.
3. Passenger's airbag module is faulty.
4. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is open.
2. Airbag module harness (passenger's side) circuit is open.
3. Passenger's airbag module is faulty.
4. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to ground.
2. Airbag module harness (passenger's side) circuit is shorted to ground.
3. Passenger's airbag module is faulty.
4. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Airbag main harness circuit is shorted to power supply.
2. Airbag module harness (passenger's side) circuit is shorted to power supply.
3. Passenger's airbag module is faulty.
4. Airbag control module is faulty.

Note. Prior to starting work, prepare two AIRBAG RESISTORs (98299PA040).

1. Side airbag harness (RH) circuit is shorted.
2. Side airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Side airbag harness (RH) circuit is open.
2. Side airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Side airbag harness (RH) circuit is shorted to ground.
2. Side airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Side airbag harness (RH) is shorted to power supply.
2. Side airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Side airbag harness (LH) circuit is shorted.
2. Side airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Side airbag harness (LH) circuit is open.
2. Side airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Side airbag harness (LH) circuit is shorted to ground.
2. Side airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Side airbag harness (LH) is shorted to power supply.
2. Side airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (RH) circuit is shorted.
2. Curtain airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (RH) circuit is open.
2. Curtain airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (RH) circuit is shorted to ground.
2. Curtain airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (RH) is shorted to power supply.
2. Curtain airbag module (RH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (LH) circuit is shorted.
2. Curtain airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (LH) circuit is open.
2. Curtain airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (LH) circuit is shorted to ground.
2. Curtain airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Curtain airbag harness (LH) is shorted to power supply.
2. Curtain airbag module (LH) is faulty.
3. Airbag control module is faulty.

1. Seat belt pretensioner (RH) circuit is shorted.
2. Pretensioner (RH) is faulty.
3. Pretensioner harness (RH) is faulty.
4. Airbag control module is faulty.

1. Seat belt pretensioner (RH) circuit is open.
2. Pretensioner (RH) is faulty.
3. Pretensioner harness (RH) is faulty.
4. Airbag control module is faulty.

1. Seat belt pretensioner (RH) circuit is shorted to ground.
2. Pretensioner (RH) is faulty.
3. Pretensioner harness (RH) is faulty.
4. Airbag control module is faulty.

1. Seat belt pretensioner (RH) circuit is shorted to power supply.
2. Pretensioner (RH) is faulty.
3. Pretensioner harness (RH) is faulty.
4. Airbag control module is faulty.

1. Seat belt pretensioner (LH) circuit is shorted.
2. Pretensioner (LH) is faulty.
3. Pretensioner harness (LH) is faulty.
4. Airbag control module is faulty.

1. Seat belt pretensioner (LH) circuit is open.
2. Pretensioner (LH) is faulty.
3. Pretensioner harness (LH) is faulty.
4. Airbag control module is faulty.

1. Seat belt pretensioner (LH) circuit is shorted to ground.
2. Pretensioner (LH) is faulty.
3. Pretensioner harness (LH) is faulty.
4. Airbag control module is faulty.

1. Seat belt pretensioner (LH) circuit is shorted to power supply.
2. Pretensioner (LH) is faulty.
3. Pretensioner harness (LH) is faulty.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (RH) circuit is shorted.
2. Lap seat belt pretensioner (RH) is faulty.
3. Lap seat belt pretensioner harness (RH) is shorted.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (RH) circuit is open.
2. Lap seat belt pretensioner (RH) is faulty.
3. Lap seat belt pretensioner harness (RH) is open.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (RH) circuit is shorted to ground.
2. Lap seat belt pretensioner (RH) is faulty.
3. Lap seat belt pretensioner harness (RH) is shorted to ground.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (RH) circuit is shorted to power supply.
2. Lap seat belt pretensioner (RH) is faulty.
3. Lap seat belt pretensioner harness (RH) is shorted to power supply.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (LH) circuit is shorted.
2. Lap seat belt pretensioner (LH) is faulty.
3. Lap seat belt pretensioner harness (LH) is shorted.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (LH) circuit is open.
2. Lap seat belt pretensioner (LH) is faulty.
3. Lap seat belt pretensioner harness (LH) is open.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (LH) circuit is shorted to ground.
2. Lap seat belt pretensioner (LH) is faulty.
3. Lap seat belt pretensioner harness (LH) is shorted to ground.
4. Airbag control module is faulty.

1. Lap seat belt pretensioner (LH) circuit is shorted to power supply.
2. Lap seat belt pretensioner (LH) is faulty.
3. Lap seat belt pretensioner harness (LH) is shorted to power supply.
4. Airbag control module is faulty.
