SEDAN MODEL Subaru Outback BS

Air Bag System 2 illustrations

SEDAN MODEL

CAUTION

Refer to CAUTION before handling the airbag module.

Scheme 196

Scheme 196

Scheme 196

Scheme 197

Scheme 197

Scheme 197

Turn the ignition switch to OFF.
Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
Remove the roof trim. Refer to «SEDAN MODEL»(ref-646002-S01916587292014072500000) .
Remove the curtain airbag module assembly. CAUTION: Be careful not to damage the curtain airbag module during removal. Never open the curtain airbag module before activation. Never reuse the deployed curtain airbag module. Remove the modules in order starting from the vehicle front. Remove all bolts and clips, and remove the curtain airbag module assembly. Disconnect the curtain airbag module connector.
