Starting/charging 2.5l — 2.5l, starting circuit, with push button start Subaru Outback BR facelift
All systems — 34 systems
- Air conditioning 2.5l 2
- Air conditioning 3.6l 2
- Anti-lock brakes
- Anti-theft 5
- Body control modules
- Computer data lines
- Cooling fan 2.5l
- Cooling fan 3.6l
- Cruise control
- Defoggers 3
- Engine performance 2.5l
- Engine performance 3.6l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems
- Navigation 8
- Power distribution
- Power door locks 4
- Power mirrors 10
- Power seats 2
- Power top/sunroof
- Power windows 4
- Radio 4
- Shift interlock 2
- Starting/charging 2.5l 9
- Starting/charging 3.6l 9
- Supplemental restraints
- Transmission 2
- Warning systems 2
- Wiper/washer 2
Starting/charging 2.5l
# 2.5l, starting circuit, with push button start
Components on the diagram
Components on these wiring diagrams 8
Click a component to highlight it on every diagram it appears on.
