SPECIFICATION
Refer to "SPECIFICATIONS" in "FRONT SUSPENSION" information for rear suspension specifications. < Refer to SPECIFICATION , General Description. >
Note. Front toe-in, rear toe-in and front camber can be adjusted. Adjust if the value of toe-in or camber exceeds the tolerance range of the specification chart. Other items except for front toe-in, rear toe-in and front camber that are described in the specification chart cannot be adjusted. If other items exceed the tolerance range of the specification chart, check the suspension parts and connections for deformation. If defective, replace with new parts.
A - B = Positive: Toe-in, Negative: Toe-out
α = Individual toe angles
Scheme 10
Tightening torque: N.m (kgf-m, ft-lb)
T1: 33 (3.36, 24.3)
T2: 38 (3.87, 28.0)
T3: 70 (7.14, 51.6)
T4: 80 (8.16, 59)
T5: 120 (12.24, 88.5)
T6: 145 (14.79, 106.9)
Scheme 11
Tightening torque: N.m (kgf-m, ft-lb)
T1: 60 (6.12, 44.3)
T2: 80 (8.16, 59)
T3: 120 (12.24, 88.5)
Scheme 12
Tightening torque: N.m (kgf-m, ft-lb)
T1: 25 (2.55, 18.4)
T2: 30 (3.06, 22.1)
