SPECIFICATION
| Model | H4 model | H6 model | |||
|---|---|---|---|---|---|
| Whole system | Minimum turning radius | M (ft) | 5.6 (18.4) | ||
| Steering angle | Inner wheel | P225/50R17 tire: 37.4°±1.5° P225/45R18 tire: 37.4°±1.5° P215/50R17 tire: 37.6°±1.5° P205/60R16 tire: 37.6°±1.5° P225/60R17 tire: 38.4°±1.5° P215/70R16 tire: 38.4°±1.5° | |||
| Outer wheel | P225/50R17 tire: 33.0°±1.5° P225/45R18 tire: 33.0°±1.5° P215/50R17 tire: 33.3°±1.5° P205/60R16 tire: 33.3°±1.5° P225/60R17 tire: 34.1°±1.5° P215/70R16 tire: 34.1°±1.5° | ||||
| Steering wheel diameter | Mm (in) | 375 (14.76) | |||
| Lock-to-lock revolution number | OUTBACK: 3.2 Except for OUTBACK: 2.8 | ||||
| Gearbox | Type | Rack and Pinion, Integral | |||
| Backlash | 0 (Automatic adjusting) | ||||
| Valve (Power steering system) | Rotary valve | ||||
| Pump (Power steering system) | Type | Vane pump | |||
| Oil tank | Installed on body | ||||
| Specific output | Cm 3 (cu in)/rev. | 8.5 (0.519) | 8.5 (0.519) | ||
| Relief pressure | KPa (kgf/cm 2 , psi) | 8, 300 - 9, 000 (85 - 92, 1, 203 - 1, 305) | 8, 900 - 9, 600 (91 - 98, 1, 290 - 1, 392) | ||
| Hydraulic fluid control | Engine speed sensitive | ||||
| Hydraulic fluid | L (US qt, lmp qt) | 1, 000 rpm: 6.5 (6.9, 5.7) 3, 000 rpm: 5.3 (5.6, 4.7) | 1, 000 rpm: 6.8 (7.2, 6) 3, 000 rpm: 5.8 (6.1, 5.1) | ||
| RPM range | Rpm | 500 - 9, 600 | 645 - 9, 675 | ||
| Direction of rotation | Clockwise | ||||
| Hydraulic oil (Power steering system) | Capacity L (US qt, lmp qt) | Oil tank | 0.2 (0.2, 0.2) | ||
| Whole system | 0.7 (0.7, 0.6) | ||||
| Steering wheel | Free play | Mm (in) | 17 (0.67) | ||
| Steering shaft | Clearance between the steering wheel and column cover | Mm (in) | 4 - 6 (0.16 - 0.24) | ||
| Steering gearbox (Power steering system) | Sliding resistance | N (kgf, lbf) | 650 (66.2, 146) or less Difference between right and left sliding resistance: 20% | ||
| Rack shaft play in the radial direction | Right-turn steering | Mm (in) | Horizontal play: 0.6 (0.024) or less Vertical play: 0.4 (0.016) or less | ||
| Left-turn steering | Mm (in) | 0.4 (0.016) or less | |||
| Input shaft play | In radial direction | Mm (in) | 0.18 (0.0071) or less | ||
| In axial direction | Mm (in) | 0.27 (0.0106) or less | |||
| Rotational resistance | N (kgf, lbf) | Maximum allowable value: 30 (3.1, 6.7) or less Difference between right and left sliding resistance: 20% | |||
| Oil pump (Power steering system) | Pulley shaft | Radial play | Mm (in) | 0.2 (0.008) or less | |
| Axial play | Mm (in) | 0.9 (0.035) or less | |||
| Pulley | Ditch deflection | Mm (in) | 1.0 (0.039) or less | ||
| Rotational resistance | N (kgf, lbf) | 9.22 (0.94, 2.07) or less | |||
| Regular pressure (Unloaded) | KPa (kgf/cm 2 , psi) | 981 (10, 142) or less | |||
| Steering wheel effort (Power steering system) | At standstill with engine idling on paved road | N (kgf, lbf) | 29.4 (3.0, 6.6) or less | ||
| At standstill with engine stalled on paved road | N (kgf, lbf) | 294.2 (30, 66.2) or less | |||
| Recommended power steering fluid | SUBARU PS fluid or DEXRON III |
Scheme 17
Tightening torque: N.m (kgf-m, ft-lb)
T1: 3.4 (0.35, 2.5)
T2: 20 (2.04, 14.8)
T3: 39 (3.98, 28.8)
Scheme 18
Tightening torque: N.m (kgf-m, ft-lb)
T1: 7.5 (0.76, 5.5)
T2: 10 (1.02, 7.4)
T3: 13 (1.33, 9.6)
T4: 40 (4.08, 29.5)
Scheme 19
Tightening torque: N.m (kgf-m, ft-lb)
T1: 15 (1.53, 11.1)
T2: 20 (2.04, 14.8)
T3: 24 (2.45, 17.7)
T4: 27 (2.75, 19.9)
T5: 39 (3.98, 28.8)
T6: 45 (4.59, 33.2)
T7: 60 (6.12, 44.3)
T8: 64 (6.53, 47.2)
T9: 75 (7.65, 55.3)
T10: 85 (8.67, 62.7)
T11: 90 (9.18, 66.4)
Scheme 20
- H4 model
Tightening torque: N.m (kgf-m, ft-lb)
T1: 16 (1.63, 11.8)
T2: 36 (3.67, 26.6)
Scheme 21
- H6 model
Tightening torque: N.m (kgf-m, ft-lb)
T1: 16 (1.63, 11.8)
T2: 21 (2.14, 15.5)
T3: 33 (3.36, 24.3)
T4: 36 (3.67, 26.6)
Recommended power steering fluid
SUBARU PS fluid or DEXRON III
Scheme 22
- Check the power steering fluid for deterioration or contamination. If the fluid is highly deteriorated or contaminated, drain it and refill with new fluid.
- Check the joints and units for oil leakage. If any oil leaks are found, repair or replace the applicable part.
- Inspect the fluid level of reservoir tank with vehicle on level surface and engine stopped. If the level is at "MIN." point or below, add fluid to keep the level in the specified range of the indicator. If at "MAX". point or above, drain fluid by using a syringe or the like. Check at power steering fluid temperature 20°C (68°F); read the fluid level on the "COLD" side. Check at power steering fluid temperature 80°C (176°F); read the fluid level on the "HOT" side.
