CAUTION
- Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
- Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
- Adjust parts to the given specifications.
- Connect the connectors securely during reassembly.
- After reassembly, make sure that the functional parts operate normally.
- Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions for the airbag system in this case. Refer to «CAUTION»(ref-565203-S06105343772013071000000) .
- Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.
- If the steering wheel and steering angle sensor (steering roll connector) are removed, adjust the steering angle sensor. Refer to «ADJUSTMENT»(ref-565186-S16232332342013071000000) .
PREPARATION TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance and voltage. |
| Steering wheel puller | Used for removing the steering wheel. |
Scheme 23
| Relay & fuse box | Fuse 7.5A (ECM, stop light & brake switch, clutch switch) | (A) |
|---|---|---|
| Fuse 15A (stop light & brake switch) | (B) |
Note. For other related fuses, refer to the wiring diagram. See appropriate SYSTEM WIRING DIAGRAM article.
CHECK FUSE
- Remove the fuse and inspect visually.
- If the fuse is blown out, replace the fuse. NOTE: If the fuse is blown again, check the system wiring harness.
NOTE
For operation procedures of each component of the cruise control system, refer to the appropriate article.
- Cruise control unit: Refer to «CRUISE CONTROL MODULE»(ref-565219-S22255814662013071000000) .
- Cruise control command switch: Refer to «CRUISE CONTROL COMMAND SWITCH»(ref-565219-S30722621122013071000000) .
- Combination meter: Refer to «COMBINATION METER»(ref-565219-S32919983062013071000000) .
- Stop light & brake switch: Refer to «STOP LIGHT & BRAKE SWITCH»(ref-565219-S28430859222013071000000) .
- Clutch switch: Refer to «CLUTCH SWITCH»(ref-565219-S35256091632013071000000) .
- Inhibitor switch: Refer to «INHIBITOR SWITCH»(ref-565219-S03296884862013071000000) .
- Transmission control module (TCM): Refer to «TRANSMISSION CONTROL MODULE (TCM)»(ref-565219-S01991408962013071000000) .
- Neutral position switch: Refer to «NEUTRAL POSITION SWITCH»(ref-565219-S11508740922013071000000) .
The control of cruise control system is carried out in engine control module (ECM).
For the combination meter, refer to COMBINATION METER .
For stop light and brake switch, refer to INSPECTION .
For clutch switch, refer to CLUTCH SWITCH .
CVT MODEL
For inhibitor switch, refer to INHIBITOR SWITCH .
5AT MODEL
Inhibitor switch cannot be removed and checked, because the inhibitor switch is installed on control valve assembly.
When a malfunction occurs, refer to DTC P0705 TRANSMISSION RANGE SENSOR CIRCUIT (PRNDL INPUT) .
For transmission control module (TCM), refer to following articles.
- CVT model: Refer to «TRANSMISSION CONTROL MODULE (TCM)»(ref-565171-S17163826582013071000000) .
- 5AT model: Refer to «TRANSMISSION CONTROL MODULE (TCM)»(ref-565170-S00443603182013071000000) .
For neutral position switch, refer to SWITCHES AND HARNESS .
