Subaru Eyesight System (Driver Assist): Adjustments Subaru Outback BR рестайлинг

ADJUSTMENT

For adjustment and inspection of the stereo camera, < Refer to CAMERA ADJUSTMENT, INSPECTION . >

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Position the front wheels straight ahead. (After moving a vehicle 5 m (16 ft) or more with front wheels positioned straight ahead, make sure that the vehicle moves straight ahead.)
2. Turn the ignition switch to OFF.
3. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
4. Remove the driver's airbag module assembly. CAUTION: Before handling the airbag module, < Refer to «CAUTION»(ref-565203-S06105343772013071000000) , General Description. > Using a hexagon wrench etc. wrapped by protective tape, insert the snap pins and release the locks (3 locations). Disconnect the horn harness and airbag connector and remove the airbag module assembly. < Refer to «DRIVER' AIRBAG MODULE, CURTAIN AIRBAG MODULE, PRETENSIONER & LAP SEAT BELT PRETENSIONER»(ref-565203-S37682674332013071000000) , PROCEDURE, Airbag Connector. >
5. Remove the steering wheel. CAUTION: Always use the steering wheel puller for removal to avoid deforming the steering wheel. If the steering wheel has been removed, make sure that the roll connector is not turned from the original position. Disconnect the connector and remove the nut. Put alignment marks and remove the steering wheel using a steering wheel puller. Preparation tool: Steering wheel puller
6. Remove the cruise control command switch. Remove the screw, disconnect the connector and remove the paddle shift switch. Remove the steering switch connector and screw. Disconnect the claws and then remove the lower cover. Remove the screw to remove the cruise control command switch assembly.
