COMPONENT DESCRIPTION
The variable valve lift system optimizes the intake valve lift by switching between the low lift cam and the high lift cam according to the engine speed. The amount of intake valve lift is varied by controlling the oil switching solenoid valve duty according to signals from the ECM.
Scheme 72
Drain valve controls the ambient air to be introduced to the canister.
Scheme 73
Vehicle speed signals are taken in to the VDC control module and hydraulic control unit, and normal/erroneous data of the ABS wheel speed sensor is received by CAN communication from the VDC control module and hydraulic control unit.
The barometric pressure sensor is built into the ECM.
The barometric pressure sensor is built into the ECM.
The barometric pressure sensor is built into the ECM.
ECM, TCM, VDC CM and body integrated unit are connected by high speed CAN.
(Common Specifications)
CAN Protocol 2.0 B (Active)
Frame Format: 11 Bit ID Frame (Standard Frame)
(High speed CAN)
Conforms to ISO11898
Communication Speed: 500 kbps
