SPECIFICATION
| Size | 16-inch type | 17-inch type | ||
|---|---|---|---|---|
| Front disc brake | Type | Disc (Floating type, ventilated) | ||
| Effective disc diameter | Mm (in) | 244 (4.61) | 261 (10.28) | |
| Disc thickness x Diameter | Mm (in) | 24 x 294 (0.94 x 11.57) | 30 x 316 (1.18 x 12.44) | |
| Effective cylinder diameter | 42.8 (1.685) x 2 | |||
| Pad dimensions (Length x Width x Thickness) | Mm (in) | 117.8 x 50.5 x 11.0 (4.638 x 1.988 x 0.433) | 130.0 x 53.5 x 11.0 (5.118 x 2.106 x 0.433) | |
| Clearance adjustment | Automatic adjustment | |||
| Rear disc brake | Size | 16-inch type | ||
| Type | Disc (Floating type, solid) | Disc (Floating type, ventilated) | ||
| Effective disc diameter | Mm (in) | 250 (9.84) | 255 (10.0) | |
| Disc thickness x Diameter | Mm (in) | 10 x 286 (0.39 x 11.26) | 18 x 290 (0.71 x 11.42) | |
| Effective cylinder diameter | Mm (in) | 38.1 (1.500) | 40.4 (1.591) | |
| Pad dimensions (Length x Width x Thickness) | Mm (in) | 92.0 x 33.0 x 9.0 (3.622 x 1.299 x 0.354) | 95.5 x 34.8 x 11.0 (3.759 x 1.370 x 0.433) | |
| Clearance adjustment | Automatic adjustment | |||
| Master cylinder | Type | Tandem | ||
| Effective diameter | Mm (in) | 23.8 (15/16) | ||
| Reservoir type | Sealed type | |||
| Brake fluid reservoir capacity | Cm 3 (cu in) | 205 (12.51) | ||
| Brake booster | Type | Vacuum suspended | ||
| Effective diameter | Mm (in) | 208 + 229 (8.19 + 9.02) | ||
| Brake line | Dual circuit system | |||
| Brake fluid CAUTION: Avoid mixing brake fluid of different brands to prevent fluid performance from degrading. When filling with brake fluid, be careful not to allow any dust to enter the reservoir. Use new SUBARU genuine brake fluid when replacing or refilling the fluid. | FMVSS No. 116, DOT3, or DOT4 | |||
| CAUTION |
|---|
| Avoid mixing brake fluid of different brands to prevent fluid performance from degrading. When filling with brake fluid, be careful not to allow any dust to enter the reservoir. Use new SUBARU genuine brake fluid when replacing or refilling the fluid. |
SPECIFICATION CHART
Note. Refer to "PB" article for parking brake specifications. Ref. to SPECIFICATION , General Description.
| Contents | Specification | Service limit | ||
|---|---|---|---|---|
| Front brake | Pad thickness mm (in) | 16-inch type | 11 (0.43) | 1.5 (0.059) |
| 17-inch type | 11 (0.43) | 1.5 (0.059) | ||
| Disc thickness mm (in) | 16-inch type | 24 (0.94) | 22 (0.87) | |
| 17-inch type | 30 (1.18) | 28 (1.10) | ||
| Disc runout | Mm (in) | 0.05 (0.0020) | ||
| Rear brake (disc type) | Pad thickness mm (in) | Solid disc | 9.0 (0.354) | 1.5 (0.059) |
| Ventilated disc | 11 (0.43) | 1.5 (0.059) | ||
| Disc thickness mm (in) | Solid disc | 10 (0.39) | 8.5 (0.335) | |
| Ventilated disc | 18 (0.71) | 16 (0.63) | ||
| Disc runout | Mm (in) | 0.05 (0.0020) | ||
| Parking brake | Inside diameter | Mm (in) | 190 (7.48) | 191 (7.52) |
| Lining thickness | Mm (in) | 2.8 (0.11) | 1.5 (0.059) | |
SPECIFICATION CHART
| Brake pedal force N (kgf, lbf) | Fluid pressure kPa (kgf/cm 2 , psi) | ||
|---|---|---|---|
| Brake booster | Brake fluid pressure with engine stopped | 147 (15,33) | 533 (5, 77) |
| 294 (30, 66) | 1,551 (16,225) | ||
| Brake fluid pressure with engine running and vacuum pressure at 66.7 kPa (500 mmHg, 19.69 inHg) | 147 (15,33) | 6,177 (63,896) | |
| 294 (30, 66) | 11,273 (115, 1,635) | ||
SPECIFICATION CHART
| Brake pedal | Free play | Mm (in) | 2 - 5 (0.079 - 0.197) [When pulling the brake pedal upward with a force of less than 10 N (1 kgf, 2 lbf)] |
SPECIFICATION CHART
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
- AT model
- MT model
