Engine Ignition System - Ignition (H4SO - 2.5L SOHC): Removal & Installation Subaru Outback BR

Ignition System 4 illustrations ~144 words

REMOVAL

Spark plug

Refer to "SPECIFICATION" for the spark plug. Ref. to SPECIFICATION , General Description.

Scheme 2

Scheme 2: RH SIDE
Scheme 2: RH SIDE

Scheme 3

Scheme 3
Scheme 3
  1. Disconnect the ground cable from battery.
  2. Remove the air cleaner case. Ref. to «REMOVAL»(ref-371894-S40543507982010091900000) , Air Cleaner Case.
  3. Disconnect the connector (A) from ignition coil.
  4. Remove the bolt (B), and remove the ignition coil.
  5. Remove the spark plug with a spark plug socket.

Scheme 4

Scheme 4: LH SIDE
Scheme 4: LH SIDE

Scheme 5

Scheme 5
Scheme 5
  1. Disconnect the ground cable from battery.
  2. Disconnect the connector (A) from ignition coil.
  3. Remove the bolt (B), and remove the ignition coil.
  4. Remove the spark plug with a spark plug socket.

Direct ignition type is adopted. Refer to "Spark Plug" for removal procedure. Ref. to REMOVAL , Spark Plug.

INSTALLATION

Install in the reverse order of removal.

Tightening torque

9 N.m (0.9 kgf-m, 6.6 ft-lb)
