Entertainment System - Entertainment: Overview Subaru Outback BR

Entertainment Systems 2 illustrations ~356 words

CHECK NAVIGATION OPERATION

Start the engine and check that the opening screen is displayed.

Standard: Opening screen is displayed.

OK: Normal.

NG: If the screen is not displayed, check the following items.

  1. The map disk (DVD-ROM) is set in the navigation system unit
  2. Check the connection of the power supply connector at the backside of the navigation unit. If wire connection is correct or has got repaired, check again that the opening screen is displayed.

If it is not displayed at this time, it indicates the navigation unit trouble.

Scheme 1

Scheme 1: CHECK EACH CONNECTION
Scheme 1: CHECK EACH CONNECTION

Scheme 2

Scheme 2
Scheme 2
  1. Press the « Audio» key to display the AUDIO OFF screen.
  2. Touch the screen in the order of (1) to (6) shown in the figure.
  3. The display will switch to the Dealer Diag Menu screen.
  1. CHECK MICROPHONE, AUX AND REARVIEW CAMERA NOTE: Before starting inspections, check the safety around the rear end of the vehicle and then turn the ignition switch to ON. Touch {Connection Info.} on the « Dealer Diag Menu» screen. Check that "Connect" is displayed in all the MIC, AUX and Camera items. NOTE: {AUX} item is not displayed, if the suitable mini jack is not inserted in the AUX terminal in the console box. Connect: Normal. NC: Abnormal. Check the signal line connection. If there are no problems, the unit could be faulty.
  2. CHECK GPS ANTENNA NOTE: When checking the GPS antenna, perform the check operation outdoors to improve the receiver sensitivity. Touch {Vehicle Signal Info.} on the « Dealer Diag Menu» screen. Check that "Connect" is displayed in the GPS Antenna item. Connect: Normal. NC: Abnormal. Check the GPS antenna connection.
  3. CHECK UART COMMUNICATION NOTE: When checking the GPS antenna, perform the check operation outdoors to improve the receiver sensitivity. Touch {Vehicle Signal Info.} on the « Dealer Diag Menu» screen. Check that "ON" is displayed in the UART signal item. OK: Normal. NG: Abnormal. Check the signal line connection. If there are no problems, the unit could be faulty. NOTE: If the UART signal line connector is not connected, the marker line is not displayed when the rearview camera image is displayed.
